Wireless Charging Coils
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Function | Type | Inductance | Tolerance | DC Resistance (DCR) | Q @ Freq | Current Rating (Amps) | Current - Saturation (Isat) | Frequency - Self Resonant | Operating Temperature | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RWC5050AK060-500TX 1 COIL 1 LAYER 6.5UH |
97 |
|
Datasheet |
RWC | Box | Active | Transmitter | 1 Coil, 1 Layer | 6.5µH | ±10% | 50mOhm Max | 70 @ 100kHz | - | - | - | -40°C ~ 125°C | 1.97" Dia x 0.12" H (50.0mm x 3.0mm) |
|
RWC5353EJ240-501TX 1 COIL 2 LAYER 24UH 5.5A |
89 |
|
Datasheet |
RWC | Box | Active | Transmitter | 1 Coil, 2 Layer | 24µH | ±10% | 75mOhm Max | 90 @ 100kHz | 5.5A | 10A | - | -40°C ~ 125°C | 2.09" L x 2.09" W x 0.26" H (53.0mm x 53.0mm x 6.7mm) |
|
WT-505060-20K2-A10-GTX 1 COIL 2 LYR 24UH |
50 |
|
Datasheet |
WT | Tray | Obsolete | Transmitter | 1 Coil, 2 Layer | 24µH | ±10% | 100mOhm Max | 80 @ 100kHz | - | - | - | -30°C ~ 70°C | 1.97" Dia x 0.13" H (50.0mm x 3.4mm) |
|
QPR-0108RECEIVER |
22 |
|
Datasheet |
- | Box | Active | Receiver | 1 Coil, 1 Layer | 8.5µH | ±10% | 130mOhm | 20 @ 100kHz | - | - | - | - | 1.97" L x 1.57" W x 0.03" H (50.0mm x 40.0mm x 0.8mm) |
|
QPT-0036A10W TRANSMITTER MODULE |
9 |
|
Datasheet |
- | Box | Active | Transmitter | 1 Coil, 1 Layer | 3.8µH | ±10% | - | - | - | - | - | - | 2.83" L x 1.97" W x 0.04" H (72.0mm x 50.0mm x 1.0mm) |
|
QPT-002310W TRANSMITTER MODULE |
6 |
|
Datasheet |
- | Box | Active | Transmitter | 1 Coil, 1 Layer | 3.8µH | ±10% | - | - | - | - | - | - | 2.83" L x 1.97" W x 0.04" H (72.0mm x 50.0mm x 1.0mm) |
|
SWC10056AA120-500TRANSMITTER 3 COIL 1 LAYER |
88 |
|
Datasheet |
SWC | Box | Active | Transmitter | 3 Coil, 1 Layer | 12.5µH, 11.5µH, 12.5µH | ±10% | 65mOhm Max | 90 @ 100kHz | - | - | - | -40°C ~ 125°C | 3.94" L x 2.20" W x 0.18" H (100.0mm x 56mm x 4.5mm) |
|
QPR-6011RECEIVER |
10 |
|
- |
- | Bulk | Active | Receiver | 1 Coil, 1 Layer | 5µH | ±10% | 130mOhm | 10 @ 100kHz | - | - | - | - | 2.01" L x 1.57" W x 0.09" H (51.0mm x 40.0mm x 2.2mm) |
|
WT505090-10K2-A11-GTX 1 COIL 1 LYR 6.3UH |
0 |
|
- |
WT | Tray | Not For New Designs | Transmitter | 1 Coil, 1 Layer | 6.3µH | - | 60mOhm | - | - | - | - | - | 1.97" Dia x 0.15" H (50.0mm x 3.8mm) |
|
WR483245-15F5-GRX 1 COIL 1 LYR 13UH |
0 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 13µH | - | 200mOhm | - | - | - | - | - | 1.89" L x 1.27" W x 0.03" H (48.2mm x 32.2mm x 1.0mm) |
|
760308111TX 1 COIL 2 LYR BIFIL 6.3UH 13A |
0 |
|
Datasheet |
WE-WPCC | Tray | Active | Transmitter | 1 Coil, 2 Layer, Bifilar | 6.3µH | ±10% | 24mOhm Max | 80 @ 125kHz | 13A | 16A | 20MHz | -20°C ~ 105°C | 2.10" L x 2.10" W x 0.24" H (53.3mm x 53.3mm x 6.0mm) |
|
|
IWTX5050CZEB6R3KF1WIRELESS CHARGING TRANSMIT COIL |
0 |
|
Datasheet |
- | Tray | Active | Transmitter | 1 Coil, 1 Layer | 6.3µH | ±10% | 45mOhm Max | 120 @ 100kHz | 5A | - | - | -40°C ~ 85°C | 1.97" Dia x 0.12" H (50.0mm x 3.0mm) |
|
IWAS4832AEEB120KF1WIRELESS CHARGING RECEIVE COIL |
0 |
|
Datasheet |
- | Tray | Active | Receiver | 1 Coil, 1 Layer | 12µH | ±10% | 200mOhm Max | 33 @ 100kHz | 3A | - | - | -40°C ~ 85°C | 1.89" L x 1.26" W x 0.04" H (48.0mm x 32.0mm x 1.0mm) |
|
WTSC-6R3K-A11BSINGLE-COIL WIRELESS CHARGING CO |
0 |
|
Datasheet |
WCC | Box | Active | Transmitter | 1 Coil, 1 Layer | 6.3µH | ±10% | 40mOhm Max | - | 6A | 10A | - | -20°C ~ 85°C | 1.97" Dia x 0.12" H (50.0mm x 3.0mm) |
|
WR202020-18M8-GRX 1 COIL, 1 LYR 9.9UH |
0 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 9.9µH | - | 520mOhm | - | - | - | - | - | 0.79" Dia x 0.02" H (20.0mm x 0.6mm) |
|
|
WRSR-11R0K-16WIRELESE CHARGE COIL 11.0UH 2.5A |
0 |
|
Datasheet |
WRSR | Bulk | Active | Receiver | 1 Coil, 1 Layer | 11µH | ±10% | 200mOhm Max | 30 @ 125kHz | 2.5A | 4A | - | -25°C ~ 105°C | 1.34" L x 1.05" W x 0.04" H (34.0mm x 26.7mm x 0.9mm) |
|
WR303050-12F5-IDRX 1 COIL 1 LYR 8.23UH |
0 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 8.23µH | ±5% | 260mOhm | - | - | - | - | - | 1.18" L x 1.17" W x 0.03" H (30.0mm x 29.6mm x 0.9mm) |
|
760308105214WE-WPCC WIRELESS POWER CHARGING |
18 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - |
|
760308102213RX 1 COIL 1 LAYER 7.9UH 1.7A |
3 |
|
Datasheet |
WE-WPCC | Tray | Active | Receiver | 1 Coil, 1 Layer | 7.9µH | ±10% | 330mOhm Max | 18 @ 125kHz | 1.7A | 4A | 21MHz | -20°C ~ 105°C | 1.14" L x 1.14" W x 0.04" H (29.0mm x 29.0mm x 0.9mm) |
|
WT505090-20K2-A10-GTX 1 COIL 2 LYR 24UH |
0 |
|
Datasheet |
WT | Tray | Active | Transmitter | 1 Coil, 2 Layer | 24µH | - | 100mOhm | - | - | - | - | - | 1.97" Dia x 0.15" H (50.0mm x 3.8mm) |
Wireless Charging Coils Electronic Components
Explore Wireless Charging Coils electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
