Wireless Charging Coils
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Function | Type | Inductance | Tolerance | DC Resistance (DCR) | Q @ Freq | Current Rating (Amps) | Current - Saturation (Isat) | Frequency - Self Resonant | Operating Temperature | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
WT252512-8F2-SMTX 1 COIL 1 LYR 2.76UH |
1,645 |
|
Datasheet |
WT | Tray | Active | Transmitter | 1 Coil, 1 Layer | 2.76µH | ±5% | 70mOhm | - | - | - | - | - | 0.98" Dia x 0.08" H (25.0mm x 2.1mm) |
|
WT242490-30F2-GTX 1 COIL 2 LYR 12.9UH |
275 |
|
Datasheet |
WT | Tray | Active | Transmitter | 1 Coil, 2 Layer | 12.9µH | ±10% | 165mOhm | - | - | - | - | - | 0.97" Dia x 0.09" H (24.5mm x 2.4mm) |
|
WR282840-37K2-LR3RX 1 COIL 1 LYR 46UH |
608 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 46µH | - | 1.25Ohm | - | - | - | - | - | - |
|
WR424245-13K2-GRX 1 COIL, 1 LYR 11.9UH |
10,269 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 11.9µH | - | 220mOhm | - | - | - | - | - | 1.65" L x 1.65" W x 0.04" H (42.0mm x 42.0mm x 0.9mm) |
|
WRSC-13R0K-26WIRELESS CHARGE COIL 13.0UH 2.0A |
114 |
|
Datasheet |
WRSC | Bulk | Active | Transmitter | 1 Coil, 4 Layer | 13µH | ±10% | 500mOhm | 17 @ 125kHz | 800mA | 2A | - | -25°C ~ 105°C | 0.41" Dia x 0.07" H (10.3mm x 1.9mm) |
|
|
WRSC-7R2K-32WIRELESS CHARGE COIL 7.2UH 0.80A |
121 |
|
Datasheet |
WRSC | Bulk | Active | Transmitter | 1 Coil, 4 Layer | 7.2µH | ±10% | 440mOhm Max | 10 @ 125kHz | 500mA | 1A | - | -25°C ~ 105°C | 0.24" Dia x 0.08" H (6.0mm x 2.0mm) |
|
WT505090-10F2-A11-G1TX 1 COIL, 1 LYR 6.3UH |
133 |
|
Datasheet |
WT | Bulk | Active | Transmitter | 1 Coil, 1 Layer | 6.3µH | - | 60mOhm | - | - | - | - | - | 2.02" Dia x 0.13" H (51.4mm x 3.4mm) |
|
WR483265-15F5-GRX 1 COIL 1 LYR 13.3UH |
664 |
|
Datasheet |
WR | Tray | Active | Receiver | 1 Coil, 1 Layer | 13.3µH | - | 200mOhm | - | 1.87A | - | - | - | 1.89" L x 1.27" W x 0.04" H (48.2mm x 32.2mm x 1.2mm) |
|
760308103204RX 1 COIL 1 LAYER 16.7UH 1A |
201 |
|
Datasheet |
WE-WPCC | Tray | Active | Receiver | 1 Coil, 1 Layer | 16.7µH | ±10% | 430mOhm | 32 @ 125kHz | 1A | 4A | 11MHz | -20°C ~ 105°C | 1.52" L x 1.20" W x 0.03" H (38.5mm x 30.5mm x 0.83mm) |
|
|
WRSC-26R0K-11WIRELESS CHARGE COIL 26.0UH 2.0A |
126 |
|
Datasheet |
WRSC | Bulk | Active | Transmitter | 1 Coil, 3 Layer | 26µH | ±10% | 520mOhm | 25 @ 125kHz | 1.1A | 2A | - | -25°C ~ 105°C | 0.75" Dia x 0.03" H (19.0mm x 0.8mm) |
|
760308101219RX 1 COIL 1 LAYER 11.8UH 700MA |
139 |
|
Datasheet |
WE-WPCC | Box | Active | Receiver | 1 Coil, 1 Layer | 11.8µH | ±10% | 750mOhm Max | 13 @ 125kHz | 700mA | 1.5A | 22MHz | -20°C ~ 105°C | 0.59" Dia x 0.02" H (15.0mm x 0.6mm) |
|
760308101208ARX 1 COIL 3 LAYER 18UH 700MA |
158 |
|
Datasheet |
WE-WPCC | Tray | Active | Receiver | 1 Coil, 3 Layer | 18µH | ±10% | 650mOhm Max | 18 @ 125kHz | 700mA | 2A | 24MHz | -20°C ~ 105°C | 0.39" Dia x 0.07" H (10.0mm x 1.7mm) |
|
|
WRSC-47R0K-08WIRELESS CHARGE COIL 47.0UH 3.0A |
205 |
|
Datasheet |
WRSC | Bulk | Active | Transmitter | 1 Coil, 3 Layer | 47µH | ±10% | 500mOhm | 25 @ 125kHz | 1.5A | 3A | - | -25°C ~ 105°C | 1.02" Dia x 0.05" H (26.0mm x 1.3mm) |
|
WT525225-12F2-MA2-GTX 1 COIL, 1 LYR 10.5UH |
349 |
|
Datasheet |
WT | Tray | Active | Transmitter | 1 Coil, 1 Layer | 10.5µH | - | 60mOhm | - | - | - | - | - | 2.05" L x 2.05" W x 0.15" H (52.0mm x 52.0mm x 3.7mm) |
|
760308101309WE-WPCC WIRELESS POWER CHARGING |
339 |
|
Datasheet |
WE-WPCC | Bulk | Active | Receiver | 1 Coil, 1 Layer | 10µH | ±10% | 450mOhm | 20 @ 125kHz | 1.5A | 5A | 19MHz | -20°C ~ 105°C | 1.035" Dia x 0.019" H (26.30mm x 0.49mm) |
|
760308102207RX 1 COIL 1 LYR BIFILAR 8UH 5A |
342 |
|
Datasheet |
WE-WPCC | Box | Active | Receiver | 1 Coil, 1 Layer, Bifilar | 8µH | ±10% | 60mOhm | 30 @ 125kHz | 5A | 10A | 16MHz | -20°C ~ 105°C | 1.57" L x 1.57" W x 0.13" H (40.0mm x 40.0mm x 3.3mm) |
|
760308101208RX 1 COIL 3 LAYER 13UH 0.8A |
154 |
|
Datasheet |
WE-WPCC | Box | Active | Receiver | 1 Coil, 3 Layer | 13µH | ±10% | 400mOhm | 17 @ 125kHz | 0.8A | 2A | 26MHz | -20°C ~ 105°C | 0.39" Dia x 0.07" H (10.0mm x 1.7mm) |
|
760308101103TX 1 COIL 1 LAYER 6.5UH 3A |
1,858 |
|
Datasheet |
WE-WPCC | Box | Active | Transmitter | 1 Coil, 1 Layer | 6.5µH | ±10% | 180mOhm Max | 35 @ 125kHz | 3A | 8A | 20MHz | -20°C ~ 105°C | 1.18" L x 1.18" W x 0.07" H (30.0mm x 30.0mm x 1.9mm) |
|
760308101303RX 1 COIL 3 LYR BIFILAR 47UH |
1,286 |
|
Datasheet |
WE-WPCC | Box | Active | Receiver | 1 Coil, 3 Layer, Bifilar | 47µH | ±10% | 460mOhm | 25 @ 125kHz | 1.5A | 3A | 8MHz | -20°C ~ 105°C | 1.02" L x 1.02" W x 0.05" H (26.0mm x 26.0mm x 1.3mm) |
|
760308100110TX 1 COIL 2 LAYER 24UH 6A |
554 |
|
Datasheet |
WE-WPCC | Box | Active | Transmitter | 1 Coil, 2 Layer | 24µH | ±10% | 70mOhm | 180 @ 125kHz | 6A | 10A | 5MHz | -20°C ~ 105°C | 1.97" Dia x 0.24" H (50.0mm x 6.0mm) |
Wireless Charging Coils Electronic Components
Explore Wireless Charging Coils electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
