Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-FK1A752SVCAP ALUM 7500UF 20% 10V SMD |
449 |
|
Datasheet |
FKS, Anti-Vibration | Tape & Reel (TR) | Active | 7500 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.545 A @ 120 Hz | 2.06 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.669" (17.00mm) | 0.748" L x 0.748" W (19.00mm x 19.00mm) | Surface Mount | |
|
UHW2A391MHD3CAP ALUM 390UF 20% 100V RADIAL |
398 |
|
Datasheet |
UHW | Bulk | Active | 390 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.135 A @ 120 Hz | 2.27 A @ 100 kHz | 47 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 0.846" (21.50mm) | - | Through Hole | |
|
EEU-FK1A562LCAP ALUM 5600UF 20% 10V RADIAL |
919 |
|
Datasheet |
FK | Bulk | Active | 5600 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.352 A @ 120 Hz | 2.94 A @ 100 kHz | 16 mOhms | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL226056471E3CAP ALUM 470UF 20% 25V RADIAL TH |
709 |
|
Datasheet |
260 RLA-V | Box | Active | 470 µF | ±20% | 25 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 560 mA @ 100 Hz | 800 mA @ 100 kHz | 29 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
ELXS3B1VSN181MP25SCAP ALUM 180UF 20% 315V SNAP TH |
584 |
|
Datasheet |
LXS | Bulk | Active | 180 µF | ±20% | 315 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 950 mA @ 120 Hz | 1.3585 A @ 50 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.083" (27.50mm) | - | Through Hole | |
|
EKXJ451ELL680MU40SCAP ALUM 68UF 20% 450V RADIAL TH |
217 |
|
Datasheet |
KXJ | Bulk | Active | 68 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 660 mA @ 120 Hz | 1.65 A @ 100 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 1.634" (41.50mm) | - | Through Hole | |
|
EEE-TP1E332MCAP ALUM 3300UF 20% 25V SMD |
215 |
|
Datasheet |
TP | Tape & Reel (TR) | Active | 3300 µF | ±20% | 25 V | 32mOhm @ 100kHz | 4000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 2.4375 A @ 120 Hz | 3.25 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.866" (22.00mm) | 0.748" L x 0.748" W (19.00mm x 19.00mm) | Surface Mount | |
|
LGN2Z391MELZ25CAP ALUM 390UF 20% 180V SNAP TH |
170 |
|
Datasheet |
LGN | Bulk | Active | 390 µF | ±20% | 180 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.28 A @ 120 Hz | 1.92 A @ 50 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
SLP331M250A7P3CAP ALUM 330UF 20% 250V SNAP TH |
2,505 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 330 µF | ±20% | 250 V | 603mOhm | 3000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | - | - | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.575" (40.00mm) | - | Through Hole | |
|
EKWA421ELL121MU45SCAP ALUM 120UF 20% 420V RADIAL |
300 |
|
Datasheet |
KWA | Bulk | Active | 120 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 790 mA @ 120 Hz | 1.185 A @ 100 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 1.850" (47.00mm) | - | Through Hole | |
|
UCY2G680MHD9TNCAP ALUM 68UF 20% 400V RADIAL TH |
248 |
|
Datasheet |
UCY | Cut Tape (CT) | Active | 68 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 640 mA @ 120 Hz | 1.28 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.043" (26.50mm) | - | Through Hole | |
|
UUE1A472MNS1MSCAP ALUM 4700UF 20% 10V SMD |
226 |
|
Datasheet |
UUE | Tape & Reel (TR) | Active | 4700 µF | ±20% | 10 V | - | 5000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | 1.349 A @ 120 Hz | 1.55 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.886" (22.50mm) | 0.752" L x 0.752" W (19.10mm x 19.10mm) | Surface Mount | |
|
EKZE101ELL471MLN3SCAP ALUM 470UF 20% 100V RADIAL |
500 |
|
Datasheet |
KZE | Bulk | Active | 470 µF | ±20% | 100 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 925 mA @ 120 Hz | 1.85 A @ 100 kHz | 32 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.299" (33.00mm) | - | Through Hole | |
|
400HXW82MEFR10X55CAP ALUM 82UF 20% 400V RADIAL TH |
390 |
|
Datasheet |
HXW | Bulk | Active | 82 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 720 mA @ 120 Hz | 1.584 A @ 10 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 2.244" (57.00mm) | - | Through Hole | |
|
400MXG150MEFCSN22X35CAP ALUM 150UF 20% 400V SNAP TH |
117 |
|
Datasheet |
MXG | Bulk | Active | 150 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.13 A @ 120 Hz | 1.582 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
EDH108M035S9TAACAP ALUM 1000UF 20% 35V SMD |
1,439 |
|
Datasheet |
EDH | Tape & Reel (TR) | Active | 1000 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 800 mA @ 120 Hz | 1 A @ 10 kHz | - | - | 0.630" Dia (16.00mm) | 0.689" (17.50mm) | 0.642" L x 0.642" W (16.30mm x 16.30mm) | Surface Mount | |
.jpg)
|
B43305A9686M000CAP ALUM 68UF 20% 400V SNAP TH |
995 |
|
Datasheet |
B43305 | Bulk | Not For New Designs | 68 µF | ±20% | 400 V | 1.99Ohm @ 100Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 650 mA @ 100 Hz | - | 2.69 Ohms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
228RZM050MCAP ALUM 2200UF 20% 50V RADIAL |
845 |
|
Datasheet |
RZM | Bulk | Active | 2200 µF | ±20% | 50 V | 121mOhm @ 120Hz | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | - | 135 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.476" (37.50mm) | - | Through Hole | |
|
|
UBY2A361MHLCAP ALUM 360UF 20% 100V RADIAL |
500 |
|
Datasheet |
UBY | Bulk | Active | 360 µF | ±20% | 100 V | 38mOhm @ 100kHz | 3000 Hrs @ 135°C | -40°C ~ 135°C | Polar | AEC-Q200 | Automotive | 1.88 A @ 120 Hz | 3.76 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.457" (37.00mm) | - | Through Hole | |
|
400LXW68MEFR12.5X30CAP ALUM 68UF 20% 400V RADIAL TH |
420 |
|
Datasheet |
LXW | Bulk | Active | 68 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 580 mA @ 120 Hz | 1.276 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.260" (32.00mm) | - | Through Hole |
