Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SLP331M450H5P3CAP ALUM 330UF 20% 450V SNAP TH |
3,141 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 330 µF | ±20% | 450 V | 1.005Ohm | 3000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | - | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
MAL212016222E3CAP ALUM 2200UF 20% 25V AXIAL TH |
816 |
|
Datasheet |
120 ATC | Bulk | Active | 2200 µF | ±20% | 25 V | 43mOhm | 8000 Hrs @ 125°C | -40°C ~ 125°C | - | AEC-Q200 | Automotive | - | 3.31 A @ 10 kHz | 44 mOhms | - | 0.709" Dia x 1.181" L (18.00mm x 30.00mm) | - | - | Through Hole | |
|
MAL211892689E3CAP ALUM 68UF 20% 200V AXIAL TH |
810 |
|
Datasheet |
118 AHT | Bulk | Active | 68 µF | ±20% | 200 V | 1.02Ohm | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | - | 700 mA @ 10 kHz | 420 mOhms | - | 0.709" Dia x 1.496" L (18.00mm x 38.00mm) | - | - | Through Hole | |
|
MAL205655103E3CAP ALUM 10000UF 20% 16V SNAP TH |
422 |
|
Datasheet |
056 PSM-SI | Bulk | Active | 10000 µF | ±20% | 16 V | 47mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 3.02 A @ 100 Hz | - | 39 mOhms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
B43548B5337M060CAP ALUM 330UF 20% 450V SNAP TH |
368 |
|
Datasheet |
B43548 | Bulk | Active | 330 µF | ±20% | 450 V | 240mOhm @ 100Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.65 A @ 100 Hz | - | 360 mOhms | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
381LR102M250K052CAP ALUM 1000UF 20% 250V SNAP TH |
11,091 |
|
Datasheet |
381LR | Bulk | Active | 1000 µF | ±20% | 250 V | 149mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.84 A @ 120 Hz | 4.06 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
B43644B9337M000CAP ALUM 330UF 20% 400V SNAP TH |
416 |
|
Datasheet |
B43644 | Bulk | Active | 330 µF | ±20% | 400 V | 280mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.49 A @ 100 Hz | - | 410 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
ESMR401VSN821MA45SCAP ALUM 820UF 20% 400V SNAP TH |
261 |
|
Datasheet |
SMR | Bulk | Active | 820 µF | ±20% | 400 V | - | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3.25 A @ 120 Hz | 4.6475 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.870" (47.50mm) | - | Through Hole | |
|
LGX2D122MELC35CAP ALUM 1200UF 20% 200V SNAP TH |
208 |
|
Datasheet |
LGX | Bulk | Active | 1200 µF | ±20% | 200 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.88 A @ 120 Hz | 4.32 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
LGN2D222MELC45CAP ALUM 2200UF 20% 200V SNAP TH |
233 |
|
Datasheet |
LGN | Bulk | Active | 2200 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.48 A @ 120 Hz | 5.22 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
LGW2D102MELB35CAP ALUM 1000UF 20% 200V SNAP TH |
125 |
|
Datasheet |
LGW | Bulk | Active | 1000 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.98 A @ 120 Hz | 5.97 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
LGG2E152MELC40CAP ALUM 1500UF 20% 250V SNAP TH |
556 |
|
Datasheet |
LGG | Bulk | Active | 1500 µF | ±20% | 250 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.3 A @ 120 Hz | 3.45 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
ALP20A472CB040CAP ALUM 4700UF 40V SOLDER LUG |
374 |
|
Datasheet |
ALP20 | Box | Active | 4700 µF | -10%, +30% | 40 V | - | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.591" (15.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
MAL219367121E3CAP ALUM 120UF 20% 450V SNAP TH |
274 |
|
Datasheet |
193 PUR-SI | Bulk | Active | 120 µF | ±20% | 450 V | 630mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.01 A @ 100 Hz | 1.515 A @ 10 kHz | 350 mOhms | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL213818152E3CAP ALUM 1500UF 20% 63V AXIAL TH |
440 |
|
Datasheet |
138 AML | Bulk | Active | 1500 µF | ±20% | 63 V | 100mOhm @ 100Hz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | Automotive | 1.68 A @ 100 Hz | 2.352 A @ 10 kHz | 72 mOhms | - | 0.827" Dia x 1.496" L (21.00mm x 38.00mm) | - | - | Through Hole | |
|
LGX2D152MELC40CAP ALUM 1500UF 20% 200V SNAP TH |
165 |
|
Datasheet |
LGX | Bulk | Active | 1500 µF | ±20% | 200 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3.08 A @ 120 Hz | 4.62 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
EKMZ421VSN561MR40SCAP ALUM 560UF 20% 420V SNAP TH |
525 |
|
Datasheet |
KMZ | Box | Active | 560 µF | ±20% | 420 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.96 A @ 120 Hz | 2.803 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.673" (42.50mm) | - | Through Hole | |
|
ETXH451VSN331MA40SCAP ALUM 330UF 20% 450V SNAP TH |
200 |
|
Datasheet |
TXH | Bulk | Active | 330 µF | ±20% | 450 V | - | 10000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.32 A @ 120 Hz | 1.8876 A @ 100 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
25MXG15000MEFCSN30X30CAP ALUM 15000UF 20% 25V SNAP TH |
191 |
|
Datasheet |
MXG | Bulk | Active | 15000 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.13 A @ 120 Hz | 3.5995 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
LGNW6471MELC40CAP ALUM 470UF 20% 420V SNAP TH |
161 |
|
Datasheet |
LGN | Bulk | Active | 470 µF | ±20% | 420 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.86 A @ 120 Hz | 2.6598 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole |
