Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
80ZLJ820M18X31.5CAP ALUM 820UF 20% 80V RADIAL TH |
189 |
|
Datasheet |
ZLJ | Bulk | Active | 820 µF | ±20% | 80 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.716 A @ 120 Hz | 2.86 A @ 100 kHz | 30 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
EPAG401ELL820MU35SCAP ALUM 82UF 20% 400V RADIAL TH |
500 |
|
Datasheet |
PAG | Bulk | Active | 82 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 530 mA @ 120 Hz | 954 mA @ 100 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 1.457" (37.00mm) | - | Through Hole | |
|
ELXZ250ELL472MM35SCAP ALUM 4700UF 20% 25V RADIAL |
250 |
|
Datasheet |
LXZ | Bulk | Active | 4700 µF | ±20% | 25 V | - | 8000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 3.128 A @ 120 Hz | 3.68 A @ 100 kHz | 16 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.437" (36.50mm) | - | Through Hole | |
|
UCX1V102MNS1MSCAP ALUM 1000UF 20% 35V SMD |
225 |
|
Datasheet |
UCX | Tape & Reel (TR) | Not For New Designs | 1000 µF | ±20% | 35 V | 50mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | AEC-Q200 | General Purpose | 600 mA @ 120 Hz | 1.2 A @ 100 kHz | - | - | 0.630" Dia (16.00mm) | 0.669" (17.00mm) | 0.673" L x 0.673" W (17.10mm x 17.10mm) | Surface Mount | |
|
860160481038CAP ALUM 3300UF 20% 25V RADIAL |
161 |
|
Datasheet |
WCAP-ATLL | Cut Tape (CT) | Active | 3300 µF | ±20% | 25 V | - | 7000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | - | 3.156 A @ 100 kHz | 41 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.043" (26.50mm) | - | Through Hole | |
|
UPW1C822MHDCAP ALUM 8200UF 20% 16V RADIAL |
151 |
|
Datasheet |
UPW | Bulk | Not For New Designs | 8200 µF | ±20% | 16 V | - | 8000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | General Purpose | 3.128 A @ 120 Hz | 3.68 A @ 100 kHz | 15 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.398" (35.50mm) | - | Through Hole | |
|
450HXW68MEFR12.5X35CAP ALUM 68UF 20% 450V RADIAL TH |
498 |
|
Datasheet |
HXW | Bulk | Active | 68 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 600 mA @ 120 Hz | 900 mA @ 10 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.457" (37.00mm) | - | Through Hole | |
|
EEE-TP1E272VCAP ALUM 2700UF 20% 25V SMD |
375 |
|
Datasheet |
TP, Anti-Vibration | Tape & Reel (TR) | Active | 2700 µF | ±20% | 25 V | 45mOhm @ 100kHz | 3000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 1.95 A @ 120 Hz | 2.6 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.669" (17.00mm) | 0.748" L x 0.748" W (19.00mm x 19.00mm) | Surface Mount | |
|
|
UPW0J153MHDCAP ALUM 15000UF 20% 6.3V RADIAL |
234 |
|
Datasheet |
UPW | Bulk | Not For New Designs | 15000 µF | ±20% | 6.3 V | - | 8000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | General Purpose | 3.128 A @ 120 Hz | 3.68 A @ 100 kHz | 15 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.398" (35.50mm) | - | Through Hole | |
|
UBX1C102MHL1TNCAP ALUM 1000UF 20% 16V RADIAL |
195 |
|
Datasheet |
UBX | Cut Tape (CT) | Active | 1000 µF | ±20% | 16 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | - | Automotive | 536 mA @ 120 Hz | 800 mA @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.043" (26.50mm) | - | Through Hole | |
|
|
UCX1E152MNS1MSCAP ALUM 1500UF 20% 25V SMD |
324 |
|
Datasheet |
UCX | Tape & Reel (TR) | Not For New Designs | 1500 µF | ±20% | 25 V | 50mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | AEC-Q200 | General Purpose | 600 mA @ 120 Hz | 1.2 A @ 100 kHz | - | - | 0.630" Dia (16.00mm) | 0.669" (17.00mm) | 0.673" L x 0.673" W (17.10mm x 17.10mm) | Surface Mount | |
|
EKMH160VSN123MQ30SCAP ALUM 12000UF 20% 16V SNAP TH |
199 |
|
Datasheet |
KMH | Bulk | Active | 12000 µF | ±20% | 16 V | 55mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.24 A @ 120 Hz | 2.4192 A @ 100 kHz | - | 0.394" (10.00mm) | 1.000" Dia (25.40mm) | 1.260" (32.00mm) | - | Through Hole | |
|
UCYW6680MHDCAP ALUM 68UF 20% 420V RADIAL TH |
198 |
|
Datasheet |
UCY | Bulk | Active | 68 µF | ±20% | 420 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | General Purpose | 645 mA @ 120 Hz | 1.29 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.299" (33.00mm) | - | Through Hole | |
|
UBY1J112MHLCAP ALUM 1100UF 20% 63V RADIAL |
134 |
|
Datasheet |
UBY | Bulk | Active | 1100 µF | ±20% | 63 V | 31mOhm @ 100kHz | 3000 Hrs @ 135°C | -40°C ~ 135°C | Polar | AEC-Q200 | Automotive | 2.766 A @ 120 Hz | 4.61 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.634" (41.50mm) | - | Through Hole | |
|
UPT2E181MHD6CAP ALUM 180UF 20% 250V RADIAL |
118 |
|
Datasheet |
UPT | Bulk | Active | 180 µF | ±20% | 250 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 720 mA @ 120 Hz | 1.152 A @ 10 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.299" (33.00mm) | - | Through Hole | |
|
|
420LXW56MEFR12.5X30CAP ALUM 56UF 20% 420V RADIAL TH |
494 |
|
Datasheet |
LXW | Bulk | Active | 56 µF | ±20% | 420 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 1.1 A @ 100 kHz | - | 0.197" (5.00mm) | 0.492" Dia (12.50mm) | 1.260" (32.00mm) | - | Through Hole | |
|
UCX1V152MNQ1MSCAP ALUM 1500UF 20% 35V SMD |
216 |
|
Datasheet |
UCX | Tape & Reel (TR) | Not For New Designs | 1500 µF | ±20% | 35 V | 50mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | - | General Purpose | 700 mA @ 120 Hz | 1.4 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.689" (17.50mm) | 0.752" L x 0.752" W (19.10mm x 19.10mm) | Surface Mount | |
|
450BXW100MEFR16X40CAP ALUM 100UF 20% 450V RADIAL |
1,507 |
|
Datasheet |
BXW | Bulk | Active | 100 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 770 mA @ 120 Hz | 1.733 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
400HXW100MEFR14.5X35CAP ALUM 100UF 20% 400V RADIAL |
452 |
|
Datasheet |
HXW | Bulk | Active | 100 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 820 mA @ 120 Hz | 1.23 A @ 100 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 1.457" (37.00mm) | - | Through Hole | |
|
420LXW56MEFR16X20CAP ALUM 56UF 20% 420V RADIAL TH |
199 |
|
Datasheet |
LXW | Bulk | Active | 56 µF | ±20% | 420 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 480 mA @ 120 Hz | 1.056 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 0.866" (22.00mm) | - | Through Hole |
Aluminum Electrolytic Capacitors Electronic Components
Explore Aluminum Electrolytic Capacitors electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
