Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PG1265NLTCMC 20A 2LN SMD |
1,125 |
|
Datasheet |
Horizontal, 4 PC Pad | - | 2 | - | - | 20A | 4.1mOhm | - | - | -40°C ~ 130°C | - | - | - | - | - |
|
P0469NLTCMC 11.6A 2LN SMD |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | - | 11.6A | 10mOhm | - | - | -40°C ~ 120°C | - | - | - | - | - |
|
S14100038CMC 560UH 20A 2LN TH |
1,544 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 560 µH @ 10 kHz | 20A | 2.8mOhm | - | 250V | -40°C ~ 125°C | - | - | - | - | - |
|
744212221CMC 220UH 300MA 2LN 1.2K OHM SMD |
4,072 |
|
Datasheet |
Horizontal, 4 J-Lead | Signal Line | 2 | 1.2 kOhms @ 35 MHz | 220 µH @ 100 kHz | 300mA | 280mOhm | 80V | - | -40°C ~ 105°C | - | - | - | - | - |
|
|
744212510CMC 51UH 300MA 2LN 300 OHM SMD |
3,276 |
|
Datasheet |
Horizontal, 4 J-Lead | Signal Line | 2 | 300 Ohms @ 300 MHz | 51 µH @ 100 kHz | 300mA | 160mOhm | 80V | - | -40°C ~ 105°C | - | - | - | - | - |
|
744290321CMC 320UH 3.25A 2LN SMD |
4,542 |
|
Datasheet |
Horizontal, 4 Flat Lead | Power, Signal Line | 2 | - | 320 µH @ 10 kHz | 3.25A | 29mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
|
744290121CMC 120UH 5.5A 2LN SMD |
1,357 |
|
Datasheet |
Horizontal, 4 Flat Lead | Power, Signal Line | 2 | - | 120 µH @ 10 kHz | 5.5A | 10.5mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
|
744290152CMC 1.5MH 1.5A 2LN SMD |
750 |
|
Datasheet |
Horizontal, 4 Flat Lead | Power, Signal Line | 2 | - | 1.5 mH @ 10 kHz | 1.5A | 120mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
|
744290130CMC 13UH 10A 2LN SMD |
124 |
|
Datasheet |
Horizontal, 4 Flat Lead | Signal Line | 2 | - | 13 µH @ 10 kHz | 10A | 2.7mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
|
CC1812C513R-10CMC 51UH 200MA 2LN 3.5KOHM SMD |
18,639 |
|
Datasheet |
Horizontal, 4 Flat Lead | Signal Line | 2 | 3.5 kOhms @ 40 MHz | 51 µH @ 100 kHz | 200mA | 500mOhm | 80V | 42V | -40°C ~ 125°C | - | - | - | - | - |
|
CC2824E513R-10CMC 51UH 800MA 2LN 3.8KOHM SMD |
6,372 |
|
Datasheet |
Horizontal, 4 Flat Lead | Signal Line | 2 | 3.8 kOhms @ 50 MHz | 51 µH @ 100 kHz | 800mA | 300mOhm | 80V | 42V | -40°C ~ 125°C | - | - | - | - | - |
|
B82792C2105N365CMC 1MH 500MA 4LN SMD |
2,013 |
|
Datasheet |
Horizontal, 8 Gull Wing | Signal Line | 4 | - | 1 mH @ 100 kHz | 500mA | 170mOhm (Typ) | 80V | 42V | -40°C ~ 125°C | - | - | - | - | - |
|
|
B82792C0685N365CMC 6.8MH 600MA 2LN SMD |
1,252 |
|
Datasheet |
Horizontal, 8 Gull Wing | Signal Line | 2 | - | 6.8 mH @ 10 kHz | 600mA | 500mOhm (Typ) | 80V | 42V | -40°C ~ 125°C | - | - | - | - | - |
|
CMS1-1-RCMC 4.5UH 7A 2LN SMD |
2,397 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 4.5 µH @ 100 kHz | 7A | 2.7mOhm (Typ) | - | - | -40°C ~ 160°C | - | - | - | - | - |
|
CM3032V301R-10CMC 8A 4LN 300 OHM SMD |
4,459 |
|
Datasheet |
Vertical, 8 Flat Lead | Power Line | 4 | 300 Ohms @ 100 MHz | - | 8A | 10mOhm | 30V | - | -40°C ~ 125°C | - | - | - | - | - |
|
PLT10HH1026R0PNLCMC 6A 2LN 1K OHM SMD AEC-Q200 |
5,681 |
|
Datasheet |
Vertical, 4 PC Pad | Power Line | 2 | 1 kOhms @ 10 MHz | - | 6A | 8mOhm (Typ) | 100V | - | -55°C ~ 105°C | AEC-Q200 | - | - | - | - |
|
|
PLT10HH9016R0PNLCMC 6A 2LN 900 OHM SMD AEC-Q200 |
5,393 |
|
Datasheet |
Vertical, 4 PC Pad | Power Line | 2 | 900 Ohms @ 10 MHz | - | 6A | 8.5mOhm | 100V | - | -55°C ~ 125°C | AEC-Q200 | - | - | - | - |
|
|
PLT10HH501100PNLCMC 10A 2LN 500 OHM SMD AEC-Q200 |
3,741 |
|
Datasheet |
Vertical, 4 PC Pad | Power Line | 2 | 500 Ohms @ 10 MHz | - | 10A | 4.1mOhm | 100V | - | -55°C ~ 105°C | AEC-Q200 | - | - | - | - |
|
|
CMS1-2-RCMC 8UH 5.7A 2LN SMD |
892 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 8 µH @ 100 kHz | 5.7A | 4mOhm (Typ) | - | - | -40°C ~ 160°C | - | - | - | - | - |
|
744824101CMC 1MH 10A 2LN TH |
936 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | 1 mH @ 10 kHz | 10A | 7mOhm | - | 250V | -40°C ~ 125°C | - | - | - | - | - |
Common Mode Chokes Electronic Components
Explore Common Mode Chokes electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
