Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LGU2Z561MELACAP ALUM 560UF 20% 180V SNAP TH |
255 |
|
Datasheet |
LGU | Bulk | Active | 560 µF | ±20% | 180 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.67 A @ 120 Hz | 2.505 A @ 50 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.181" (30.00mm) | - | Through Hole | |
|
UVY2W680MHDCAP ALUM 68UF 20% 450V RADIAL TH |
231 |
|
Datasheet |
UVY | Bulk | Active | 68 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 185 mA @ 120 Hz | 212.75 mA @ 10 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.476" (37.50mm) | - | Through Hole | |
|
EKZN500ELL272MMP1SCAP ALUM 2700UF 20% 50V RADIAL |
190 |
|
Datasheet |
KZN | Bulk | Active | 2700 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.2025 A @ 120 Hz | 4.27 A @ 100 kHz | 13 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
MAL202124332E3CAP ALUM 3300UF 20% 10V AXIAL TH |
1,457 |
|
Datasheet |
021 ASM | Tape & Reel (TR) | Active | 3300 µF | ±20% | 10 V | 128mOhm @ 100Hz | 8000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.09 A @ 100 Hz | - | 95 mOhms | - | 0.492" Dia x 1.181" L (12.50mm x 30.00mm) | - | - | Through Hole | |
|
EMVH630GTR721MMN0SCAP ALUM 720UF 20% 63V SMD |
290 |
|
Datasheet |
Alchip™- MVH | Tray | Active | 720 µF | ±20% | 63 V | - | 5000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | - | - | - | - | 0.709" Dia (18.00mm) | 0.906" (23.00mm) | 0.748" L x 0.748" W (19.00mm x 19.00mm) | Surface Mount | |
|
UCZ1E332MNS1MSCAP ALUM 3300UF 20% 25V SMD |
5,085 |
|
Datasheet |
UCZ | Tape & Reel (TR) | Active | 3300 µF | ±20% | 25 V | 32mOhm @ 100kHz | 4000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | General Purpose | 1.625 A @ 120 Hz | 3.25 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.886" (22.50mm) | 0.752" L x 0.752" W (19.10mm x 19.10mm) | Surface Mount | |
|
860010781028CAP ALUM 2200UF 20% 63V RADIAL |
104 |
|
Datasheet |
WCAP-ATG8 | Cut Tape (CT) | Active | 2200 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.475 A @ 120 Hz | 3.168 A @ 100 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.476" (37.50mm) | - | Through Hole | |
|
UCX1V222MNQ1MSCAP ALUM 2200UF 20% 35V SMD |
374 |
|
Datasheet |
UCX | Tape & Reel (TR) | Not For New Designs | 2200 µF | ±20% | 35 V | 35mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | - | General Purpose | 1.1 A @ 120 Hz | 2.2 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.886" (22.50mm) | 0.752" L x 0.752" W (19.10mm x 19.10mm) | Surface Mount | |
|
35MXG5600MEFCSN20X40CAP ALUM 5600UF 20% 35V SNAP TH |
190 |
|
Datasheet |
MXG | Bulk | Active | 5600 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.13 A @ 120 Hz | 2.4495 A @ 10 kHz | - | 0.394" (10.00mm) | 0.787" Dia (20.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
UHW1J182MHDCAP ALUM 1800UF 20% 63V RADIAL |
296 |
|
Datasheet |
UHW | Bulk | Active | 1800 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.106 A @ 120 Hz | 3.51 A @ 100 kHz | 21 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
400HXW150MEFR14.5X50CAP ALUM 150UF 20% 400V RADIAL |
484 |
|
Datasheet |
HXW | Bulk | Active | 150 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.06 A @ 120 Hz | 1.665 A @ 10 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 2.047" (52.00mm) | - | Through Hole | |
|
LGU1V822MELACAP ALUM 8200UF 20% 35V SNAP TH |
250 |
|
Datasheet |
LGU | Bulk | Active | 8200 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.73 A @ 120 Hz | 3.1395 A @ 50 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
UCX1V182MNJ1MSCAP ALUM 1800UF 20% 35V SMD |
220 |
|
Datasheet |
UCX | Tape & Reel (TR) | Active | 1800 µF | ±20% | 35 V | 35mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | AEC-Q200 | General Purpose | 1.1 A @ 120 Hz | 2.2 A @ 100 kHz | - | - | 0.709" Dia (18.00mm) | 0.886" (22.50mm) | 0.752" L x 0.752" W (19.10mm x 19.10mm) | Surface Mount | |
|
B43508A9277M000CAP ALUM 270UF 20% 400V SNAP TH |
201 |
|
Datasheet |
B43508 | Bulk | Not For New Designs | 270 µF | ±20% | 400 V | 460mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.16 A @ 100 Hz | - | 640 mOhms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
UHW2A681MHD6CAP ALUM 680UF 20% 100V RADIAL |
296 |
|
Datasheet |
UHW | Bulk | Active | 680 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.716 A @ 120 Hz | 2.86 A @ 100 kHz | 31 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
400LXW120MEFR14.5X40CAP ALUM 120UF 20% 400V RADIAL |
493 |
|
Datasheet |
LXW | Bulk | Active | 120 µF | ±20% | 400 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 890 mA @ 120 Hz | 1.78 A @ 100 kHz | - | 0.295" (7.50mm) | 0.571" Dia (14.50mm) | 1.654" (42.00mm) | - | Through Hole | |
|
B43504A9826M000CAP ALUM 82UF 20% 400V SNAP TH |
483 |
|
Datasheet |
B43504 | Bulk | Not For New Designs | 82 µF | ±20% | 400 V | 1.07Ohm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 550 mA @ 100 Hz | - | 1.32 Ohms | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
MAL224658471E3CAP ALUM 470UF 20% 63V RADIAL TH |
634 |
|
Datasheet |
246 RTI-V | Box | Active | 470 µF | ±20% | 63 V | - | 4000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 750 mA @ 100 Hz | 1.5 A @ 100 kHz | 55 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 0.866" (22.00mm) | - | Through Hole | |
|
LGU1E153MELCCAP ALUM 15000UF 20% 25V SNAP TH |
199 |
|
Datasheet |
LGU | Bulk | Active | 15000 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.26 A @ 120 Hz | 3.749 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
LGU1C183MELBCAP ALUM 18000UF 20% 16V SNAP TH |
192 |
|
Datasheet |
LGU | Bulk | Active | 18000 µF | ±20% | 16 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3 A @ 120 Hz | 3.45 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole |
