BOM Upload
RF Antennas
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
70431508 ELEMENT YAGI 145-165 MHZ |
0 |
|
Datasheet |
- | Box | Active | - | VHF (f < 300MHz) | 155MHz | 145MHz ~ 165MHz | Yagi, 8-Element | 1 | 1.5 | - | 10dBd | 150 W | Cable - 3m | N Type Female | - | - | - | Bracket Mount | 134.252" (341.00cm) | - |
|
6GK57956DC000AA0IWLAN ANTENNA ANT795-6DN |
0 |
|
Datasheet |
- | Box | Active | WiFi | Wide Band | 2.45GHz, 5.5125GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.875GHz | Module | 2 | 2 | - | 9dBi, 9dBi | - | - | N Type Female | IP66, IP67 | - | - | Panel Mount | 3.976" (101.00mm) | WLAN |
|
|
ANT-2216M-G2E16 DBI 2.4G MIMO PATCH ANTENNNA |
0 |
|
Datasheet |
- | Bulk | Not For New Designs | - | UHF (2GHz ~ 3GHz) | 2.5GHz | 2.3GHz ~ 2.7GHz | Ceramic Patch | 1 | 2 | - | 16dBi | 6 W | - | N Type | IP67 | - | - | Surface Mount | - | General Purpose |
|
|
FM51058ANTENNA TYPE N JACK 800 MHZ-3 GH |
0 |
|
Datasheet |
- | Bag | Active | Cellular, WiFi | Wide Band | 1.9GHz | 800MHz ~ 3GHz | Dome | 1 | 2 | - | 7.5dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female | - | - | - | Panel Mount | 3.780" (96.00mm) | 3G, 4G, LTE, Wi-Fi |
|
|
HG5822EG-5PKANTGRID 5.8GHZ 22DBI |
0 |
|
- |
HG | Bag | Obsolete | General ISM, WiFi | SHF (f > 4GHz) | 5.8GHz | - | Parabolic Grid | 1 | - | - | 23dBi | - | - | Screw-Mount | - | - | - | Mast Mount | 10.000" (254.00mm) | 802.11a/n, ISM, WLAN |
|
|
HG4450-14DP-0904400 MHZ TO 5000 MHZ V/H DUAL PO |
0 |
|
- |
HG | Bag | Active | Cellular | SHF (f > 4GHz) | 4.7GHz | 4.4GHz ~ 5GHz | Sector | 1 | 2 | - | 14dBi | 50 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female (2) | - | - | - | Bracket Mount | 2.400" (60.96mm) | 5G |
|
|
FMWAN137-20WG ANTENNA WR-137 5.85-8.2 GHZ |
0 |
|
Datasheet |
- | Bag | Active | General ISM | SHF (f > 4GHz) | 7.025GHz | 5.85GHz ~ 8.2GHz | Horn | 1 | 1.3 | - | 20dBi | - | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | Screw-Mount | - | - | - | Waveguide Mount | 4.960" (125.98mm) | General Purpose |
|
|
9221000392210003 |
0 |
|
Datasheet |
- | Bulk | Active | - | Wide Band | 390MHz, 425MHz, 460MHz, 720MHz, 853MHz, 1.95GHz, 3.55GHz | 380MHz ~ 400MHz, 400MHz ~ 450MHz, 450MHz ~ 470MHz, 694MHz ~ 746MHz, 746MHz ~ 960MHz, 1.2GHz ~ 2.7GHz, 3.3GHz ~ 3.8GHz | Whip, Straight | 7 | 1.7 | - | 3dBi, 4dBi, 5dBi, 6dBi, 7dBi, 8dBi, 8.5dBi | - | - | 4.3/10 - Female | - | - | - | Connector Mount | 21.260" (540.00mm) | General Purpose |
|
|
FM51OM1008ANTENNA TYPE N JACK 2.4 MHZ-5.8 |
0 |
|
Datasheet |
- | Bag | Active | WiFi | Wide Band | 4.1GHz | 2.4GHz ~ 5.8GHz | Whip, Straight | 1 | 1.6 | - | 6dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female | - | - | - | Bracket Mount | 50.300" (127.76cm) | 802.11a/b/g/ac, Wi-Fi, WiMax™ |
|
|
GPS-LB12GL-MAGGPS L1/L2 L BAND GLONASS ACTIVE, |
0 |
|
- |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
HG74207XXPPR-4310FINDOOR PANEL ANTENNA, 7 DBI, 698 |
0 |
|
- |
HG | Bag | Active | Cellular | Wide Band | 2.349GHz | 698MHz ~ 4GHz | Panel | 1 | 1.8 | - | 6.5dBi | 50 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | 4.3/10 - Female (4) | - | - | - | Bracket Mount | 3.310" (84.07mm) | 5G, CBRS, CDMA, DAS, GSM, LTE, LPWAN, LoRA, LTE-M, NB-IoT, IoT, M2M |
|
2867791RF ANT 900MHZ WHIP STR N FEM |
0 |
|
Datasheet |
- | Bulk | Obsolete | - | UHF (300MHz ~ 1GHz) | 900MHz | 902MHz ~ 928MHz | Whip, Straight | 1 | - | - | 5.15dBi | - | - | N Type Female | IP65 | - | - | Bracket Mount | 44.250" (112.40cm) | - |
|
|
FM51246ANTENNA 4.3-10 JACK 698 MHZ-4 GH |
0 |
|
Datasheet |
- | Bag | Active | Cellular | Wide Band | 2.349GHz | 698MHz ~ 4GHz | Panel | 1 | 1.8 | - | 6.5dBi | 50 W | Cable - 299.72mm | 4.3/10 - Female | - | - | - | Bracket Mount | 0.980" (24.89mm) | 5G, CDMA, GSM, LTE, LPWAN, LoRA, LTE-M, NB-IoT, IoT, M2M |
|
EAN0906WB902-928 MHZ 8.15 DBI 65" OMNIDIR |
0 |
|
Datasheet |
- | Box | Active | - | UHF (300MHz ~ 1GHz) | 915MHz | 902MHz ~ 928MHz | Whip, Straight | 1 | - | - | 6dBi | - | - | N Type Female | - | - | - | Bracket Mount | - | - |
|
|
76002090GNSS WITH UNTETHERED DEAD RECKON |
0 |
|
Datasheet |
Digi TX54 | Bulk | Active | Navigation | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Roof Mount | - | GNSS |
|
|
HG4964-16DP-904.9 GHZ TO 6.4 GHZ, 2-PORT, 90 D |
0 |
|
- |
HG | Bag | Active | WiFi | SHF (f > 4GHz) | 5.15GHz, 5.65GHz, 6.15GHz | 4.9GHz ~ 5.4GHz, 5.4GHz ~ 5.9GHz, 5.9GHz ~ 6.4GHz | Sector | 1 | 1.5 | - | 16.5dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female (2) | - | - | - | Bracket Mount | 2.500" (63.50mm) | 802.11n, WiMax™, WLAN |
|
|
FMWAN159-20WG ANTENNA WR-159 4.9-7.05 GHZ |
0 |
|
Datasheet |
- | Bag | Active | General ISM | SHF (f > 4GHz) | 5.975GHz | 4.9GHz ~ 7.05GHz | Horn | 1 | 1.3 | - | 20dBi | - | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | Screw-Mount | - | - | - | Waveguide Mount | 5.770" (146.56mm) | General Purpose |
|
|
HG3342DP-065-NF3.3-4.2 GHZ 18 DBI MIMO SECTOR A |
0 |
|
Datasheet |
HG | Bulk | Active | Cellular | Wide Band | 3.75GHz | 3.3GHz ~ 4.2GHz | Sector | 1 | 2 | - | 18dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female (2) | - | - | - | Mast Mount | 3.480" (88.39mm) | 5G, CBRS, LTE, WISP |
|
|
HG5971-17XP-090-2NF5925-7125MHZ, 17DBI, 90-DEGREE + |
0 |
|
- |
HG | Bag | Active | Cellular, WiFi | SHF (f > 4GHz) | 6.525GHz | 5.925GHz ~ 7.125GHz | Sector | 1 | 2 | - | 17dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female (2) | - | - | - | Bracket Mount | 3.500" (88.90mm) | 802.16ax, IoT, OFDMA, Wi-Fi, WLAN |
|
|
HG3513DPU-453300-3800 MHZ 13 DBI SLANT 45 MI |
0 |
|
- |
HG | Bag | Active | Cellular | UHF (3GHz ~ 4GHz) | 3.55GHz | 3.3GHz ~ 3.8GHz | Whip, Straight | 1 | 2 | - | 14dBi | 100 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female | - | - | - | Mast Mount | 35.600" (904.24mm) | LTE |
RF Antennas Electronic Components
Explore RF Antennas electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
