Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
-A7.jpg)
|
DT-2RV-A7SWITCH SNAP ACTION DPDT 10A 125V |
0 |
|
Datasheet |
DT | Bulk | Active | DPDT | On-Mom | 10A (AC), 300mA (DC) | 125 V | 125 V | Lever, Straight | Chassis Mount | Screw Terminal | - | - | 99 ~ 170gf | 28gf | 0.859" (21.8mm) | 1.000" (25.4mm) | 0.755" (19.2mm) | 0.062" (1.6mm) | -55°C ~ 85°C |
|
LSV1ASWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Adjustable Plunger | Chassis Mount | Plug In | - | - | 1814gf | - | - | 0.071" (1.8mm) | 0.016" (0.4mm) | 0.190" (4.8mm) | -12°C ~ 93°C |
|
LSP5ASWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Plug In | - | Status Indicator | 46gfm | - | - | 9° | 3° | 66° | -12°C ~ 121°C |
|
|
LSXYPB3KSWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
LSX | Bulk | Obsolete | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Explosion Proof | 46gfm | - | - | 9° | 3° | 66° | -40°C ~ 121°C |
|
LSYAC1ASWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Plug In | - | - | 46gfm | - | - | 15° | 5° | 60° | -12°C ~ 121°C |
|
LSYAB2BSWITCH SNAP ACTION DPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Plug In | - | - | 46gfm | - | - | 15° | 7° | 60° | -40°C ~ 121°C |
|
BZLN-2-LHSWITCH SNAP ACTION SPDT 15A 125V |
0 |
|
Datasheet |
LN | Bulk | Obsolete | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Wire Leads | - | Actuator Mounted Left Side | 1360gf | 113gf | - | 0.078" (2.0mm) | 0.014" (0.35mm) | 0.469" (11.9mm) | -32°C ~ 71°C |
|
BZLN-2-RHSWITCH SNAP ACTION SPDT 15A 125V |
0 |
|
Datasheet |
LN | Bulk | Obsolete | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Wire Leads | - | Actuator Mounted Right Side | 1360gf | 113gf | - | 0.078" (2.0mm) | 0.014" (0.35mm) | 0.469" (11.9mm) | -32°C ~ 71°C |
|
|
LSH1A-2DSWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary, Adjustable Roller | Chassis Mount | Plug In | - | Steel Roller, Front Mounted | 19gfm | - | - | 9° | 3° | 66° | -1°C ~ 121°C |
|
|
610.8050.034SWITCH LIMIT 5 PCS MIN |
0 |
|
Datasheet |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EX-AR230SWITCH SNAP ACTION SPDT 15A 125V |
0 |
|
Datasheet |
EX | Bulk | Obsolete | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Explosion Proof | 9.001 ~ 23gfm | 4.500gfm | - | 0.219" (5.6mm) | 0.007" (0.18mm) | 90° | -40°C ~ 71°C |
|
LSXA7LSWITCH SNAP ACTION DPDT 10A 120V |
0 |
|
Datasheet |
LSX | Bulk | Obsolete | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Explosion Proof | 46gfm | - | - | 15° | 7° | 60° | -12°C ~ 121°C |
|
|
L1452MSWITCH LIMIT SPST 20A 120V |
0 |
|
Datasheet |
- | Box | Obsolete | SPST-NC (DB) | On-Mom | 20A (AC), 5A (DC) | 120 V | 120 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -29°C ~ 49°C |
|
|
9007AW12M11SWITCH LIMIT SPDT 15A 120V |
0 |
|
Datasheet |
9007 | Box | Active | SPDT (DB/DM) | On-On | 15A (AC) | 120 V | - | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | - | - | - | - | - | - | -51°C ~ 85°C |
|
DTE6-2RQ2SWITCH SNAP ACTION DPDT 10A 125V |
0 |
|
Datasheet |
E6 | Bulk | Active | DPDT | On-Mom | 10A (AC), 300mA (DC) | 125 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | Steel Roller | 283 ~ 567gf | - | - | 0.266" (6.75mm) | 0.165" (4.2mm) | 0.219" (5.6mm) | -32°C ~ 71°C |
|
|
LSH9ASWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Plug In | - | Status Indicator | 19gfm | - | - | 9° | 3° | 66° | -1°C ~ 121°C |
|
|
51.201RFOOT SWITCHFS2U1(2X)STDCLR 1NO/1 |
0 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
1LS23SWITCH SNAP ACTION SPDT 10A 120V |
0 |
|
Datasheet |
LS | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | 21gfm | 2.880gf | 20° | 20° | 12° | 30° | -29°C ~ 71°C |
|
L100WS2M3SWITCH LIMIT DPST 20A 120V |
0 |
|
Datasheet |
Square D L100 | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 20A (AC), 5A (DC) | 120 V | 120 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -23°C ~ 85°C |
|
|
51.156RFOOT SWITCHFS1SU1RUSTDCLRGD 1NO/ |
0 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
