Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SS5M0002DBASIC SWITCH |
5,083 |
|
Datasheet |
SS | - | Active | SPDT | On-Mom | 5A (AC) | 125 V | - | Round (Pin Plunger) | Chassis Mount | Quick Connect - 0.110" (2.8mm) | IP40 | - | 150gf | 25gf | 0.331" (8.40mm) | 0.020" (0.5mm) | 0.004" (0.1mm) | 0.020" (0.5mm) | -25°C ~ 85°C |
|
|
D2FN9005MBASIC SWITCH |
5,183 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Lever, Straight | Chassis Mount | Solder Lug | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
D2FN9205CBASIC SWITCH |
2,132 |
|
Datasheet |
D2F | - | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Lever, Straight | Through Hole | PC Pin | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
SS5M0007ESWITCH SNAP ACTION SPDT 5A 125V |
6,725 |
|
Datasheet |
SS | - | Active | SPDT | On-Mom | 5A (AC) | 125 V | - | Lever, Simulated Roller | Chassis Mount | Solder Lug | IP40 | - | 50gf | 6.118gf | 0.421" (10.70mm) | - | 0.031" (0.80mm) | 0.047" (1.2mm) | -25°C ~ 85°C |
|
|
D2FN9007GBASIC SWITCH |
3,972 |
|
Datasheet |
D2F | - | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Lever, Straight | Chassis Mount | Solder Lug | IP40 | - | 25gf | 2.039gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
SS5M0069EBASIC SWITCH |
5,785 |
|
Datasheet |
SS | - | Active | SPDT | On-Mom | 5A (AC) | 125 V | - | Lever, Simulated Roller | Chassis Mount | Solder Lug | IP40 | - | 16gf | 2.039gf | 0.421" (10.70mm) | - | 0.031" (0.80mm) | 0.047" (1.2mm) | -25°C ~ 85°C |
|
|
D2FN1048MBASIC SWITCH |
4,718 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 1A (AC), 500mA (DC) | 125 V | 30 V | Lever, Simulated Roller | Chassis Mount | Solder Lug | IP40 | - | 40gf | 2.039gf | 0.335" (8.5mm) | - | 0.018" (0.45mm) | 0.020" (0.5mm) | -40°C ~ 85°C |
|
|
D2FN4148CBASIC SWITCH |
1,553 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Lever, Straight | Chassis Mount | Solder Lug | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
DG23-B1AASWITCH SNAP SPDT 50MA PC MNT |
4,000 |
|
Datasheet |
DG | Bulk | Active | SPDT | On-Mom | 50mA (DC) | - | 30 V | Round (Pin Plunger) | Through Hole | PC Pin | - | - | - | - | - | - | - | - | -25°C ~ 85°C |
|
|
SS5M0013MSWITCH SNAP ACTION SPDT 5A 125V |
1,468 |
|
Datasheet |
SS | - | Active | SPDT | On-Mom | 5A (AC) | 125 V | - | Lever, Roller | Chassis Mount | Solder Lug | IP40 | - | 50gf | 6.118gf | 0.571" (14.50mm) | - | 0.031" (0.80mm) | 0.047" (1.2mm) | -25°C ~ 85°C |
|
|
D2FD0016BSUBMINATURE BASIC SWITCH |
4,500 |
|
Datasheet |
D2FD | Bulk | Active | SPDT | On-Mom | 100mA (AC/DC) | 125 V | 30 V | Round (Pin Plunger) | Chassis Mount | Solder Lug | IP60 - Dust Tight | - | 204gf | 25gf | 0.276" (7.0mm) | 0.024" (0.6mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -20°C ~ 70°C |
|
|
D2MQ1122MBASIC SWITCH |
6,750 |
|
Datasheet |
D2MQ | - | Active | - | - | - | - | - | - | - | PC Pin | IP40 | - | - | - | - | - | - | - | -15°C ~ 70°C |
|
|
D2FN2040MBASIC SWITCH |
4,020 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Lever, Straight | Through Hole, Right Angle | PC Pin | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
MJG--MV-3000A-NC--T35A SPST-NC Mini Snap Switch |
72,000 |
|
- |
MV | Bulk | Active | SPST-NC | On-Mom | 5A (AC), 0.5A (DC) | 250 V | 125 V | Round (Pin Plunger) | Chassis Mount | Quick Connect - 0.187" (4.7mm) | IP40 | - | 250gf | 50gf | - | 0.047" (1.2mm) | 0.016" (0.4mm) | 0.039" (1.0mm) | -20°C ~ 80°C |
|
|
MJG--MV-3000A-NO--T35A SPST-NO Mini Snap Switch |
72,000 |
|
- |
MV | Bulk | Active | SPST-NO | On-Mom | 5A (AC), 0.5A (DC) | 250 V | 125 V | Round (Pin Plunger) | Chassis Mount | Quick Connect - 0.187" (4.7mm) | IP40 | - | 250gf | 50gf | - | 0.047" (1.2mm) | 0.016" (0.4mm) | 0.039" (1.0mm) | -20°C ~ 80°C |
|
D459-B8AASWITCH SNAP ACTION N.O./N.C. SPD |
8,700 |
|
- |
D4 | Bulk | Active | SPDT | On-On | 16A (AC) | 250 V | - | Round (Pin Plunger) | Through Hole | PC Pin | IP40 | - | 400gf | 100gf | 0.579" (14.7mm) | 0.047" (1.2mm) | 0.012" (0.3mm) | 0.051" (1.3mm) | -40°C ~ 105°C |
|
|
DB1C-A1LCSWITCH SNAP ACTION SPDT 5A 125V |
10,544 |
|
Datasheet |
DB | Bulk | Active | SPDT | On-Mom | 5A (AC), 1A (DC) | 125 V | 48 V | Lever, Straight | Chassis Mount | Solder Lug | IP50 - Dust Protected | - | 50gf | - | 0.437" (11.1mm) | 0.178" (4.5mm) | 0.025" (0.6mm) | 0.081" (2.05mm) | -40°C ~ 120°C |
|
|
DB1C-B1LBSWITCH SNAP ACTION SPDT 5A 125V |
9,520 |
|
Datasheet |
DB | Bulk | Active | SPDT | On-Mom | 5A (AC), 1A (DC) | 125 V | 48 V | Lever, Straight | Chassis Mount | Quick Connect - 0.110" (2.8mm) | IP50 - Dust Protected | - | 60gf | - | 0.420" (10.7mm) | 0.157" (4.0mm) | 0.020" (0.51mm) | 0.081" (2.05mm) | -40°C ~ 120°C |
|
|
DB1C-A1SBSWITCH SNAP ACTION SUBMINI |
7,562 |
|
- |
DB | Bulk | Active | SPDT | On-On | 5A (AC) | 125 V | - | Lever, Simulated Roller | Panel Mount | Solder Lug | IP50 - Dust Protected | - | 150gf | - | 0.331" (8.40mm) | 0.040" (1.0mm) | 0.004" (0.1mm) | 0.004" (0.1mm) | -40°C ~ 120°C |
|
|
DB1C-B1LCSWITCH SNAP ACTION SPDT 5A 125V |
6,720 |
|
Datasheet |
DB | Bulk | Active | SPDT | On-Mom | 5A (AC), 1A (DC) | 125 V | 48 V | Lever, Straight | Chassis Mount | Quick Connect - 0.110" (2.8mm) | IP50 - Dust Protected | - | 50gf | - | 0.437" (11.1mm) | 0.178" (4.5mm) | 0.025" (0.6mm) | 0.081" (2.05mm) | -40°C ~ 120°C |
