Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DTV6-2RN2SWITCH SNAP ACTION DPDT 10A 125V |
0 |
|
Datasheet |
V6 | Bulk | Active | DPDT | On-Mom | 10A (AC), 300mA (DC) | 125 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP66 - Dust Tight, Water Resistant | Actuator Seal Boot | 283 ~ 850gf | 170gf | - | 0.266" (6.75mm) | 0.165" (4.2mm) | 0.219" (5.6mm) | -32°C ~ 71°C |
|
LSYJC3KP-7AFPSWITCH SNAP ACTION SPDT 10A 120V |
57 |
|
- |
HDLS | Bulk | Obsolete | SPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Spring, Rod | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | Cable Length 12' | 283gf | - | - | 1.000" (25.4mm) | - | - | -12°C ~ 105°C |
|
|
LSL4M4SWITCH SNAP ACTION DPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Side Rotary - No Lever | Chassis Mount | Screw Terminal | - | Sequence Action | 46gfm | - | - | 15° | 5° | 48° | -12°C ~ 121°C |
|
|
LSYKB4L-8CSWITCH SNAP ACTION DPDT 10A 120V |
0 |
|
Datasheet |
HDLS | Bulk | Active | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Spring, Coil | Chassis Mount | Screw Terminal | - | - | 198gf | - | - | 2.000" (50.8mm) | - | - | -29°C ~ 121°C |
|
BNS026RSWITCH SNAP ACTION DPST 6A 250V |
32 |
|
Datasheet |
- | Bag | Active | DPST-NO/NC x 2 | On-Mom, Off-Mom | 6A (AC) | 250 V | - | Bevel Plunger | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | 2039gf | - | 0.472" (12.0mm) | - | - | - | -5°C ~ 85°C |
|
|
2HM18-3SWITCH SNAP ACTION SPDT 2A 115V |
0 |
|
Datasheet |
HM | Bulk | Obsolete | SPDT | On-Mom | 2A (AC), 4A (DC) | 115 V | 28 V | Lever, Straight | Chassis Mount | Cable Leads | - | - | 198gf | 28gf | 0.330" (8.4mm) | 0.030" (0.8mm) | 0.006" (0.15mm) | 0.003" (0.076mm) | -65°C ~ 121°C |
|
BNS00EYSWITCH SNAP ACTION DPST 6A 250V |
30 |
|
Datasheet |
- | Bag | Active | DPST-NO/NC x 3 | On-Mom, Off-Mom | 6A (AC) | 250 V | - | Bevel Plunger | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | 2039gf | - | 1.180" (30.0mm) | - | - | - | -5°C ~ 85°C |
|
|
LSXD4L6SWITCH SNAP ACTION DPDT 10A 120V |
0 |
|
Datasheet |
LSX | Bulk | Active | DPDT (DB/DM) | On-Mom | 10A (AC), 800mA (DC) | 120 V | 115 V | Roller Plunger | Chassis Mount | Screw Terminal | - | Roller Perpendicular to Mounting Surface | 1814gf | - | 2.700" (68.6mm) | 0.070" (1.78mm) | 0.020" (0.5mm) | 0.190" (4.8mm) | -12°C ~ 93°C |
|
|
4HS143-120SWITCH SNAP ACT SPDT 0.5A 125V |
0 |
|
Datasheet |
HS | Bulk | Active | SPDT | On-Mom | 500mA (AC), 10A (DC) | 125 V | 28 V | Lever, Straight | Chassis Mount | Wire Leads | - | - | 425 ~ 922gf | 113gf | 0.615" (15.6mm) | 0.085" (2.16mm) | 0.020" (0.5mm) | 0.010" (0.25mm) | -54°C ~ 121°C |
|
|
38HM10SWITCH SNAP ACTION SPDT 1A 28V |
0 |
|
Datasheet |
HM | Bulk | Active | SPDT | On-Mom | 1A (DC) | - | 28 V | Lever, Roller | Chassis Mount | Cable Leads | - | - | 1360gf | 170gf | - | 0.012" (0.3mm) | 0.030" (0.76mm) | 0.050" (1.27mm) | - |
|
|
D2FN1000FSWITCH SNAP ACTION SPDT 3A 125V |
2,546 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Round (Pin Plunger) | Through Hole | PC Pin | IP40 | - | 150gf | 20gf | 0.217" (5.5mm) | 0.020" (0.5mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -40°C ~ 85°C |
|
|
D2FN9204EBASIC SWITCH |
17,523 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Lever, Straight | Through Hole | PC Pin | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
D2FN1001DSWITCH SNAP ACTION SPDT 1A 125V |
34,962 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 1A (AC), 500mA (DC) | 125 V | 30 V | Round (Pin Plunger) | Through Hole | PC Pin | IP40 | - | 75gf | 5.099gf | 0.217" (5.5mm) | 0.020" (0.5mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -40°C ~ 85°C |
|
|
D2FN2000ABASIC SWITCH |
4,236 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Round (Pin Plunger) | Through Hole | PC Pin | IP40 | - | 150gf | 20gf | 0.217" (5.5mm) | 0.020" (0.5mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -40°C ~ 85°C |
|
SDS002RSW SDS N.C. DET ROHS SMT T/R |
15,000 |
|
Datasheet |
SDS | Bulk | Active | SPST-NC | On-Mom | 100mA (DC) | - | 12 V | Overtravel Plunger | Surface Mount, Right Angle | SMD (SMT) Tab | - | - | 75gf | - | - | - | - | 0.081" (2.05mm) | -40°C ~ 85°C |
|
|
D2FN9001HBASIC SWITCH |
3,611 |
|
Datasheet |
D2F | - | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Round (Pin Plunger) | Chassis Mount | Solder Lug | IP40 | - | 150gf | 20gf | 0.217" (5.5mm) | 0.020" (0.5mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -40°C ~ 85°C |
|
|
D2FN2001MBASIC SWITCH |
1,551 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 100mA (DC) | - | 30 V | Round (Pin Plunger) | Through Hole | PC Pin | IP40 | - | 75gf | 5.099gf | 0.217" (5.5mm) | 0.020" (0.5mm) | 0.005" (0.13mm) | 0.010" (0.25mm) | -40°C ~ 85°C |
|
|
D2FN1003MSWITCH SNAP ACTION SPDT 1A 125V |
12,325 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 1A (AC), 500mA (DC) | 125 V | 30 V | Lever, Straight | Through Hole | PC Pin | IP40 | - | 25gf | 2.039gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
D2FN9004BBASIC SWITCH |
2,455 |
|
Datasheet |
D2F | Bulk | Active | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Lever, Straight | Chassis Mount | Solder Lug | IP40 | - | 80gf | 5.099gf | 0.268" (6.80mm) | - | 0.020" (0.5mm) | 0.022" (0.55mm) | -40°C ~ 85°C |
|
|
D3VM0359MMiniature Basic |
2,718 |
|
Datasheet |
D3V | Bulk | Active | SPST-NO | Off-Mom | 16A (AC), 10A (DC) | 250 V | 30 V | Lever, Simulated Roller | Chassis Mount | Quick Connect - 0.250" (6.3mm) | IP40 | - | 125gf | 14gf | 0.740" (18.8mm) | 0.157" (4.0mm) | 0.060" (1.5mm) | 0.062" (1.6mm) | -25°C ~ 105°C |
