Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0468003.NRFUSE BRD MNT 3A 32VAC 32VDC 1206 |
19,288 |
|
Datasheet |
SlimLine™ 468 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 3 A | 32 V | 32 V | Slow Blow | 50A | 1.27 | CSA, UL | -55°C ~ 90°C | - | 0.125" L x 0.060" W x 0.023" H (3.18mm x 1.52mm x 0.58mm) | |
|
0438001.WRFUSE BRD MNT 1A 32VAC 63VDC 0603 |
7,517 |
|
Datasheet |
438 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 1 A | 32 V | 63 V | Fast Blow | 50A | 0.0593 | CSA, UL | -55°C ~ 150°C | - | 0.061" L x 0.033" W x 0.020" H (1.54mm x 0.85mm x 0.50mm) | |
|
0230003.HXPFUSE GLASS 3A 250VAC 125VDC AXL |
4,025 |
|
Datasheet |
230 | Bulk | Active | Through Hole | Cartridge, Glass | 3 A | 250 V | 125 V | Slow Blow | 35A AC, 10kA DC | 77.0 | CE, CSA, PSE, UL | -55°C ~ 125°C | - | 0.177" Dia x 0.571" L (4.50mm x 14.50mm) | |
|
0218001.HXPFUSE GLASS 1A 250VAC 5X20MM |
3,749 |
|
Datasheet |
218 | Bulk | Active | Requires Holder | Cartridge, Glass | 1 A | 250 V | - | Slow Blow | 35A | 6.73 | CCC, CE, CSA, K-MARK, PSE, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0218002.HXPFUSE GLASS 2A 250VAC 5X20MM |
2,379 |
|
Datasheet |
218 | Bulk | Active | Requires Holder | Cartridge, Glass | 2 A | 250 V | - | Slow Blow | 35A | 14.45 | CCC, CE, CSA, K-MARK, PSE, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0218004.HXPFUSE GLASS 4A 250VAC 5X20MM |
2,013 |
|
Datasheet |
218 | Bulk | Active | Requires Holder | Cartridge, Glass | 4 A | 250 V | - | Slow Blow | 40A | 69.1 | CCC, CE, CSA, K-MARK, PSE, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
02183.15HXPFUSE GLASS 3.15A 250VAC 5X20MM |
1,947 |
|
Datasheet |
218 | Bulk | Active | Requires Holder | Cartridge, Glass | 3.15 A | 250 V | - | Slow Blow | 35A | 38.15 | CCC, CE, CSA, K-MARK, PSE, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0218.500HXPFUSE GLASS 500MA 250VAC 5X20MM |
293 |
|
Datasheet |
218 | Bulk | Active | Requires Holder | Cartridge, Glass | 500 mA | 250 V | - | Slow Blow | 35A | 2.825 | CCC, CE, CSA, K-MARK, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
F0603G0R07FNTRFUSE BOARD MOUNT 70MA 63VAC 0603 |
403 |
|
Datasheet |
Accu-Guard® II | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 70 mA | 63 V | - | Fast Blow | 50A | 4.0E-6 | cUL, UL | -55°C ~ 125°C | - | 0.063" L x 0.032" W x 0.024" H (1.60mm x 0.81mm x 0.61mm) | |
|
TR/3216FF30-RFUSE BOARD MOUNT 30A 24VDC 1206 |
17,366 |
|
Datasheet |
Chip 3216FF | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 30 A | - | 24 V | Fast Blow | 300A | 43.0 | cURus, UR | -55°C ~ 125°C | - | 0.126" L x 0.063" W x 0.035" H (3.20mm x 1.60mm x 0.90mm) | |
|
3403.0274.23FUSE BRD MT 1A 277VAC 250VDC SMD |
56,474 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 1 A | 277 V | 250 V | Slow Blow | 1.5kA | 3.44 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0281.23FUSE BRD MT 5A 277VAC 125VDC SMD |
14,444 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 5 A | 277 V | 125 V | Slow Blow | 1.5kA | 99.0 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0282.23FUSE BRD MNT 6.3A 277VAC/125VDC |
10,411 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 6.3 A | 277 V | 125 V | Slow Blow | 1.5kA | 165.0 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0277.23FUSE BRD MT 2A 277VAC 250VDC SMD |
10,076 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 2 A | 277 V | 250 V | Slow Blow | 1.5kA | 11.8 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0271.23FUSE BRD MNT 500MA 277VAC 250VDC |
4,454 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 500 mA | 277 V | 250 V | Slow Blow | 1.5kA | 0.45 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0284.23FUSE BRD MNT 10A 250VAC/125VDC |
2,623 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 10 A | 250 V | 125 V | Slow Blow | 1.5kA | 198.0 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0274.11FUSE BRD MT 1A 277VAC 250VDC SMD |
1,657 |
|
Datasheet |
UMT-H | Strip | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 1 A | 277 V | 250 V | Slow Blow | 1.5kA | 3.44 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
|
3403.0279.23FUSE BRD MNT 3.15A 277VAC 125VDC |
1,487 |
|
Datasheet |
UMT-H | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 3.15 A | 277 V | 125 V | Slow Blow | 1.5kA | 43.0 | CQC, cURus, VDE | -55°C ~ 125°C | - | 0.606" L x 0.211" W x 0.211" H (15.40mm x 5.35mm x 5.35mm) | |
|
0467001.NRFUSE BRD MNT 1A 32VAC 32VDC 0603 |
40,683 |
|
Datasheet |
467 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 1 A | 32 V | 32 V | Fast Blow | 50A | 0.0212 | CSA, UL | -55°C ~ 90°C | - | 0.063" L x 0.032" W x 0.012" H (1.60mm x 0.81mm x 0.31mm) | |
|
|
0467005.NRFUSE BRD MNT 5A 32VAC 32VDC 0603 |
16,251 |
|
Datasheet |
467 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 5 A | 32 V | 32 V | Fast Blow | 35A | 0.9 | CSA, UL | -55°C ~ 90°C | - | 0.063" L x 0.032" W x 0.012" H (1.60mm x 0.81mm x 0.31mm) |
