CPLDs (Complex Programmable Logic Devices)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Programmable Type | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Macrocells | Number of Gates | Number of I/O | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XC95216-20HQ208IIC CPLD 216MC 20NS 208QFP |
0 |
|
Datasheet |
XC9500 | 208-BFQFP Exposed Pad | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.5V ~ 5.5V | 12 | 216 | 4800 | 166 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
XC95216-20PQ160CIC CPLD 216MC 20NS 160QFP |
0 |
|
Datasheet |
XC9500 | 160-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.75V ~ 5.25V | 12 | 216 | 4800 | 133 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 160-PQFP (28x28) |
|
|
XC95216-20PQ160IIC CPLD 216MC 20NS 160QFP |
0 |
|
Datasheet |
XC9500 | 160-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.5V ~ 5.5V | 12 | 216 | 4800 | 133 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 160-PQFP (28x28) |
|
|
XC95288-10BG352CIC CPLD 288MC 10NS 352MBGA |
0 |
|
Datasheet |
XC9500 | 352-LBGA Exposed Pad, Metal | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 16 | 288 | 6400 | 192 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 352-MBGA (35x35) |
|
|
XC95288-10HQ208CIC CPLD 288MC 10NS 208QFP |
0 |
|
Datasheet |
XC9500 | 208-BFQFP Exposed Pad | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 16 | 288 | 6400 | 168 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
|
XC95288-15BG352CIC CPLD 288MC 15NS 352MBGA |
0 |
|
Datasheet |
XC9500 | 352-LBGA Exposed Pad, Metal | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 16 | 288 | 6400 | 192 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 352-MBGA (35x35) |
|
|
XC95288-15BG352IIC CPLD 288MC 15NS 352MBGA |
0 |
|
Datasheet |
XC9500 | 352-LBGA Exposed Pad, Metal | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 16 | 288 | 6400 | 192 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 352-MBGA (35x35) |
|
|
XC95288-15HQ208IIC CPLD 288MC 15NS 208QFP |
0 |
|
Datasheet |
XC9500 | 208-BFQFP Exposed Pad | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 16 | 288 | 6400 | 168 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
|
XC95288-20BG352CIC CPLD 288MC 20NS 352MBGA |
0 |
|
Datasheet |
XC9500 | 352-LBGA Exposed Pad, Metal | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.75V ~ 5.25V | 16 | 288 | 6400 | 192 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 352-MBGA (35x35) |
|
|
XC95288-20BG352IIC CPLD 288MC 20NS 352MBGA |
0 |
|
Datasheet |
XC9500 | 352-LBGA Exposed Pad, Metal | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.5V ~ 5.5V | 16 | 288 | 6400 | 192 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 352-MBGA (35x35) |
|
|
XC95288-20HQ208CIC CPLD 288MC 20NS 208QFP |
0 |
|
Datasheet |
XC9500 | 208-BFQFP Exposed Pad | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.75V ~ 5.25V | 16 | 288 | 6400 | 168 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
|
XC95288-20HQ208IIC CPLD 288MC 20NS 208QFP |
0 |
|
Datasheet |
XC9500 | 208-BFQFP Exposed Pad | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 20 ns | 4.5V ~ 5.5V | 16 | 288 | 6400 | 168 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
XC95288XL-7PQ208CIC CPLD 288MC 7.5NS 208QFP |
0 |
|
Datasheet |
XC9500XL | 208-BFQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 3V ~ 3.6V | 16 | 288 | 6400 | 168 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
XC9536-10CS48CIC CPLD 36MC 10NS 48CSBGA |
0 |
|
Datasheet |
XC9500 | 48-FBGA, CSPBGA | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 48-CSBGA (7x7) |
.jpg)
|
XC9536-10PC44CIC CPLD 36MC 10NS 44PLCC |
0 |
|
Datasheet |
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC9536-10PC44IIC CPLD 36MC 10NS 44PLCC |
0 |
|
Datasheet |
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.5V ~ 5.5V | 2 | 36 | 800 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
XC9536-10VQ44CIC CPLD 36MC 10NS 44VQFP |
0 |
|
Datasheet |
XC9500 | 44-TQFP | Tray | Obsolete | Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-VQFP (10x10) |
|
|
XC9536-10VQ44IIC CPLD 36MC 10NS 44VQFP |
0 |
|
Datasheet |
XC9500 | 44-TQFP | Tray | Obsolete | Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.5V ~ 5.5V | 2 | 36 | 800 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-VQFP (10x10) |
|
|
XC9536-15VQ44IIC CPLD 36MC 15NS 44VQFP |
0 |
|
Datasheet |
XC9500 | 44-TQFP | Tray | Obsolete | Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 2 | 36 | 800 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-VQFP (10x10) |
|
|
XC9536-5CS48CIC CPLD 36MC 5NS 48CSBGA |
0 |
|
Datasheet |
XC9500 | 48-FBGA, CSPBGA | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 5 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 48-CSBGA (7x7) |
