CPLDs (Complex Programmable Logic Devices)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Programmable Type | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Macrocells | Number of Gates | Number of I/O | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XC9572-15PQ100IIC CPLD 72MC 15NS 100QFP |
0 |
|
Datasheet |
XC9500 | 100-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 4 | 72 | 1600 | 72 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 100-PQFP (20x14) |
|
XC9572-15TQ100CIC CPLD 72MC 15NS 100TQFP |
0 |
|
Datasheet |
XC9500 | 100-LQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 72 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
|
XC9572-15TQ100IIC CPLD 72MC 15NS 100TQFP |
0 |
|
Datasheet |
XC9500 | 100-LQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 4 | 72 | 1600 | 72 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
.jpg)
|
XC9572-7PC44CIC CPLD 72MC 7.5NS 44PLCC |
0 |
|
Datasheet |
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
XC9572-7PC84CIC CPLD 72MC 7.5NS 84PLCC |
0 |
|
Datasheet |
XC9500 | 84-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 69 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 84-PLCC (29.31x29.31) |
|
|
XC9572-7TQ100CIC CPLD 72MC 7.5NS 100TQFP |
0 |
|
Datasheet |
XC9500 | 100-LQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 72 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
|
XC9572XL-10PC44CIC CPLD 72MC 10NS 44PLCC |
0 |
|
Datasheet |
XC9500XL | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 3V ~ 3.6V | 4 | 72 | 1600 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC9572XL-10PC44IIC CPLD 72MC 10NS 44PLCC |
0 |
|
Datasheet |
XC9500XL | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 3V ~ 3.6V | 4 | 72 | 1600 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC9572XL-5PC44CIC CPLD 72MC 5NS 44PLCC |
0 |
|
Datasheet |
XC9500XL | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 5 ns | 3V ~ 3.6V | 4 | 72 | 1600 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC9572XL-7PC44CIC CPLD 72MC 7.5NS 44PLCC |
0 |
|
Datasheet |
XC9500XL | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 3V ~ 3.6V | 4 | 72 | 1600 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
XCR3256XL-7PQ208CIC CPLD 256MC 7NS 208QFP |
0 |
|
Datasheet |
CoolRunner XPLA3 | 208-BFQFP | Tray | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 7 ns | 3V ~ 3.6V | 16 | 256 | 6000 | 164 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
XCR3384XL-10FG324IIC CPLD 384MC 9NS 324FBGA |
0 |
|
Datasheet |
CoolRunner XPLA3 | 324-BBGA | Tray | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 9 ns | 2.7V ~ 3.6V | 24 | 384 | 9000 | 220 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 324-FBGA (23x23) |
|
|
XCR3384XL-10PQ208CIC CPLD 384MC 9NS 208QFP |
0 |
|
Datasheet |
CoolRunner XPLA3 | 208-BFQFP | Tray | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 9 ns | 3V ~ 3.6V | 24 | 384 | 9000 | 172 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
|
XCR3384XL-10PQ208IIC CPLD 384MC 9NS 208QFP |
0 |
|
Datasheet |
CoolRunner XPLA3 | 208-BFQFP | Tray | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 9 ns | 2.7V ~ 3.6V | 24 | 384 | 9000 | 172 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
|
XCR3384XL-12PQ208IIC CPLD 384MC 10.8NS 208QFP |
0 |
|
Datasheet |
CoolRunner XPLA3 | 208-BFQFP | Tray | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 10.8 ns | 2.7V ~ 3.6V | 24 | 384 | 9000 | 172 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
|
CY7C375I-125ACIC CPLD 128MC 10NS 160TQFP |
0 |
|
Datasheet |
Ultralogic™ | 160-LQFP | Bag | Obsolete | Not Verified | In-System Reprogrammable™ (ISR™) CMOS | 10 ns | 4.75V ~ 5.25V | 8 | 128 | - | 128 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 160-TQFP (24x24) |
|
CY37064P84-125JCIC CPLD 64MC 10NS 84PLCC |
0 |
|
Datasheet |
Ultra37000™ | 84-LCC (J-Lead) | Tube | Obsolete | Not Verified | In-System Reprogrammable™ (ISR™) CMOS | 10 ns | 4.75V ~ 5.25V | - | 64 | - | 69 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 84-PLCC (29.31x29.31) |
|
|
CY37128P160-125ACIC CPLD 128MC 10NS 160TQFP |
0 |
|
Datasheet |
Ultra37000™ | 160-LQFP | Bag | Obsolete | Not Verified | In-System Reprogrammable™ (ISR™) CMOS | 10 ns | 4.75V ~ 5.25V | - | 128 | - | 133 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 160-TQFP (24x24) |
|
|
CY37192P160-125ACIC CPLD 192MC 10NS 160TQFP |
0 |
|
Datasheet |
Ultra37000™ | 160-LQFP | Bag | Obsolete | Not Verified | In-System Reprogrammable™ (ISR™) CMOS | 10 ns | 4.75V ~ 5.25V | - | 192 | - | 125 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 160-TQFP (24x24) |
|
CY39100V208B-125NTCIC CPLD 1536MC 10NS 208QFP |
0 |
|
- |
Delta 39K™ ISR™ | 208-BFQFP | Bag | Obsolete | Not Verified | In-System Reprogrammable™ (ISR™) Flash | 10 ns | 2.5V, 3.3V | - | 1536 | 144000 | 136 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 208-PQFP (28x28) |
