Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TF2720B-152Y5R0-01CMC 5A 2LN TH |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | - | 5A | - | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
PL8220TPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 400 µH @ 10 kHz | 6A | 9.4mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
HCTC-2.5-12.5CMC 2.5MH 12.5A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | 2.5 mH @ 1 kHz | 12.5A | 11mOhm | - | - | -55°C ~ 105°C | - | - | - | - | - |
|
|
PL8213NLTPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 800 µH @ 10 kHz | 3A | 30mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
PL8216POWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 280 µH @ 10 kHz | 4A | 13.2mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
PL8213TPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 800 µH @ 10 kHz | 3A | 30mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
DSHP-6148-D6D1CMC 600MALN TH |
0 |
|
Datasheet |
Radial | - | - | - | - | 600mA | 550mOhm | 600V | - | -40°C ~ 125°C | - | - | - | - | - |
|
|
PL8212NLPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 1.125 mH @ 10 kHz | 1.8A | 55mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
PL8212POWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 1.125 mH @ 10 kHz | 1.8A | 55mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
PL8215NLTPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 536 µH @ 10 kHz | 3.8A | 17.1mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
PL8215TPOWER |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 536 µH @ 10 kHz | 3.8A | 17.1mOhm | - | - | -55°C ~ 130°C | - | - | - | - | - |
|
|
TF3524V-402Y6R0-01CMC 6A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 6A | 35mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-502Y5R0-01CMC 5A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 5A | 50mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-750Y12R0-1HCMC 75UH 12A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | 75 µH @ 10 kHz | 12A | 10mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-601Y15R0-01CMC 15A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 15A | 7mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-702Y4R0-01CMC 4A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 4A | 100mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-450Y15R0-1HCMC 15A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 15A | 7mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-121Y8R0-1HCMC 120UH 8A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | 120 µH @ 10 kHz | 8A | 20mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF3524V-301Y20R0-01CMC 20A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | Power Line | 2 | - | - | 20A | 5mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
|
|
TF2720B-502Y3R0-01CMC 3A 2LN TH |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | - | 3A | 150mOhm | - | - | -20°C ~ 120°C | - | - | - | - | - |
Common Mode Chokes Electronic Components
Explore Common Mode Chokes electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
