Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PEG130KJ4300QE4CAP ALUM 3000UF 40V AXIAL TH |
2,712 |
|
Datasheet |
PEG130 | Tray | Active | 3000 µF | -10%, +30% | 40 V | 42mOhm @ 100Hz | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.85 A @ 100 Hz | 10.7 A @ 5 kHz | - | - | 0.787" Dia x 1.457" L (20.00mm x 37.00mm) | - | - | Through Hole | |
|
381LR681M250K032CAP ALUM 680UF 20% 250V SNAP TH |
898 |
|
Datasheet |
381LR | Bulk | Active | 680 µF | ±20% | 250 V | 219mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.42 A @ 120 Hz | 3.45 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
LGG2D102MELB30CAP ALUM 1000UF 20% 200V SNAP TH |
158 |
|
Datasheet |
LGG | Bulk | Active | 1000 µF | ±20% | 200 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.04 A @ 120 Hz | 3.06 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
LGX2G391MELA50CAP ALUM 390UF 20% 400V SNAP TH |
248 |
|
Datasheet |
LGX | Bulk | Active | 390 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.44 A @ 120 Hz | 2.0592 A @ 50 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
LGU2Z122MELACAP ALUM 1200UF 20% 180V SNAP TH |
172 |
|
Datasheet |
LGU | Bulk | Active | 1200 µF | ±20% | 180 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.55 A @ 120 Hz | 3.825 A @ 50 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.969" (50.00mm) | - | Through Hole | |
|
381LR331M400K042CAP ALUM 330UF 20% 400V SNAP TH |
1,078 |
|
Datasheet |
381LR | Bulk | Active | 330 µF | ±20% | 400 V | 402mOhm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.71 A @ 120 Hz | 2.44 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
TE1509CAP ALUM 20UF 150V AXIAL TH |
369 |
|
Datasheet |
TE | Bulk | Active | 20 µF | -10%, +50% | 150 V | - | 2000 Hrs @ 85°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 0.354" Dia x 1.496" L (9.00mm x 38.00mm) | - | - | Through Hole | |
|
B43545B5227M000CAP ALUM 220UF 20% 450V SNAP TH |
318 |
|
Datasheet |
B43545 | Tray | Active | 220 µF | ±20% | 450 V | 410mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.47 A @ 100 Hz | - | 630 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
500MXH120MEFCSN25X35CAP ALUM 120UF 20% 500V SNAP TH |
139 |
|
Datasheet |
MXH | Bulk | Active | 120 µF | ±20% | 500 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.02 A @ 120 Hz | 1.428 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
LGZ2W820MELB25CAP ALUM 82UF 20% 450V SNAP TH |
237 |
|
Datasheet |
LGZ | Bulk | Active | 82 µF | ±20% | 450 V | - | 20000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 560 mA @ 120 Hz | 800.8 mA @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
450LXW150MEFR16X50CAP ALUM 150UF 20% 450V RADIAL |
176 |
|
Datasheet |
LXW | Bulk | Active | 150 µF | ±20% | 450 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.02 A @ 120 Hz | 2.04 A @ 100 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
B43544B2108M000CAP ALUM 1000UF 20% 200V SNAP TH |
285 |
|
Datasheet |
B43544 | Tray | Active | 1000 µF | ±20% | 200 V | 85mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.71 A @ 100 Hz | - | 120 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
500VXG120MEFCSN25X35CAP ALUM 120UF 20% 500V SNAP TH |
212 |
|
Datasheet |
VXG | Bulk | Active | 120 µF | ±20% | 500 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.02 A @ 120 Hz | 1.428 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
LGN2H181MELC30CAP ALUM 180UF 20% 500V SNAP TH |
141 |
|
Datasheet |
LGN | Bulk | Active | 180 µF | ±20% | 500 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 900 mA @ 120 Hz | 1.287 A @ 50 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
25MXG10000MEFCSN25X30CAP ALUM 10000UF 20% 25V SNAP TH |
196 |
|
Datasheet |
MXG | Bulk | Active | 10000 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.65 A @ 120 Hz | 3.0475 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
EGPA101ELL751MM40SCAP ALUM 750UF 20% 100V RADIAL |
209 |
|
Datasheet |
GPA | Bulk | Active | 750 µF | ±20% | 100 V | 39mOhm @ 100kHz | 5000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.728 A @ 120 Hz | 2.88 A @ 100 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.634" (41.50mm) | - | Through Hole | |
|
LLG2C152MELZ50CAP ALUM 1500UF 20% 160V SNAP TH |
490 |
|
Datasheet |
LLG | Bulk | Active | 1500 µF | ±20% | 160 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.4 A @ 120 Hz | 5.1 A @ 50 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
PEH534VDC3220M2CAP ALUM 220UF 20% 400V SNAP TH |
586 |
|
Datasheet |
PEH534 | Bulk | Active | 220 µF | ±20% | 400 V | 460mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.1 A @ 100 Hz | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
B41252A6129M000CAP ALUM 12000UF 20% 50V SNAP TH |
228 |
|
Datasheet |
B41252 | Bulk | Active | 12000 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.78 A @ 120 Hz | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
B43505A5227M000CAP ALUM 220UF 20% 450V SNAP TH |
310 |
|
Datasheet |
B43505 | Bulk | Not For New Designs | 220 µF | ±20% | 450 V | 620mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.3 A @ 100 Hz | - | 730 mOhms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole |
