Trimmer Potentiometers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Resistance | Power (Watts) | Tolerance | Temperature Coefficient | Number of Turns | Adjustment Type | Resistive Material | Mounting Type | Termination Style | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3296W-1-104ALFTRIMMER 100K OHM 0.5W PC PIN TOP |
1,290 |
|
Datasheet |
Trimpot® 3296 - Sealed | Cut Tape (CT) | Active | 100 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
|
3296W-1-104RLFTRIMMER 100K OHM 0.5W PC PIN TOP |
881 |
|
Datasheet |
Trimpot® 3296 - Sealed | Tape & Reel (TR) | Active | 100 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
|
3296W-1-102ALFTRIMMER 1K OHM 0.5W PC PIN TOP |
810 |
|
Datasheet |
Trimpot® 3296 - Sealed | Cut Tape (CT) | Active | 1 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
|
3296W-1-203ALFTRIMMER 20K OHM 0.5W PC PIN TOP |
760 |
|
Datasheet |
Trimpot® 3296 - Sealed | Cut Tape (CT) | Active | 20 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
|
3296W-1-202RLFTRIMMER 2K OHM 0.5W PC PIN TOP |
732 |
|
Datasheet |
Trimpot® 3296 - Sealed | Tape & Reel (TR) | Active | 2 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
|
3296W-1-503ALFTRIMMER 50K OHM 0.5W PC PIN TOP |
705 |
|
Datasheet |
Trimpot® 3296 - Sealed | Cut Tape (CT) | Active | 50 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 25.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.190" Face (9.53mm x 4.83mm) |
|
RJ-5EW103TRIMMER 10K OHM 0.25W PC PIN TOP |
601 |
|
Datasheet |
RJ-5 | Bulk | Active | 10 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 14.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.236" x 0.169" Face (6.00mm x 4.30mm) |
|
SM-43TW202TRIMMER 2K OHM 0.25W J LEAD TOP |
5,429 |
|
Datasheet |
SM43 | Tape & Reel (TR) | Active | 2 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 5.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.189" x 0.138" Face (4.80mm x 3.50mm) |
|
SM-43TW103TRIMMER 10K OHM 0.25W J LEAD TOP |
330 |
|
Datasheet |
SM43 | Tape & Reel (TR) | Active | 10 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 5.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.189" x 0.138" Face (4.80mm x 3.50mm) |
|
66WR1KLFTRIMMER 1K OHM 0.5W PC PIN TOP |
907 |
|
Datasheet |
66 | Bulk | Active | 1 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 20.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.375" x 0.200" Face (9.53mm x 5.08mm) |
|
SM-31TW104TRIMMER 100K OHM 0.125W J LEAD |
1,928 |
|
Datasheet |
SM31 | Tape & Reel (TR) | Active | 100 kOhms | 0.125W, 1/8W | ±20% | ±100ppm/°C | 5.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.154" x 0.126" Face (3.90mm x 3.20mm) |
|
|
SM-31TW502TRIMMER 5K OHM 0.125W J LEAD TOP |
1,000 |
|
Datasheet |
SM31 | Tape & Reel (TR) | Active | 5 kOhms | 0.125W, 1/8W | ±20% | ±100ppm/°C | 5.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.154" x 0.126" Face (3.90mm x 3.20mm) |
|
3266P-1-503LFTRIMMER 50KOHM 0.25W PC PIN SIDE |
8,312 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 50 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.174" Face (6.35mm x 4.42mm) |
|
3266X-1-203LFTRIMMER 20KOHM 0.25W PC PIN SIDE |
2,626 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 20 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
|
3266X-1-202LFTRIMMER 2K OHM 0.25W PC PIN SIDE |
1,881 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 2 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
3266W-1-105LFTRIMMER 1M OHM 0.25W PC PIN TOP |
1,387 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 1 MOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
3266Y-1-502LFTRIMMER 5K OHM 0.25W PC PIN TOP |
752 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 5 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
|
3266W-1-253LFTRIMMER 25K OHM 0.25W PC PIN TOP |
716 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 25 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
|
3266W-1-204LFTRIMMER 200KOHM 0.25W PC PIN TOP |
690 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 200 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
93PR200KLFTRIMMER 200K OHM 1W PC PIN TOP |
444 |
|
Datasheet |
93 | Bulk | Active | 200 kOhms | 1W | ±10% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Round - 0.500" Dia (12.70mm) |
