Trimmer Potentiometers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Resistance | Power (Watts) | Tolerance | Temperature Coefficient | Number of Turns | Adjustment Type | Resistive Material | Mounting Type | Termination Style | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3006P-1-501TRIMMER 500OHM 0.75W PC PIN SIDE |
334 |
|
Datasheet |
Trimpot® 3006 - Sealed | Tube | Active | 500 Ohms | 0.75W, 3/4W | ±10% | ±100ppm/°C | 15.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.190" Face (6.35mm x 4.83mm) |
|
|
3006P-1-103TRIMMER 10KOHM 0.75W PC PIN SIDE |
305 |
|
Datasheet |
Trimpot® 3006 - Sealed | Tube | Active | 10 kOhms | 0.75W, 3/4W | ±10% | ±100ppm/°C | 15.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.190" Face (6.35mm x 4.83mm) |
|
3329H-1-102LFTRIMMER 1K OHM 0.5W PC PIN TOP |
302 |
|
Datasheet |
Trimpot® 3329 - Sealed | Tube | Active | 1 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Round - 0.250" Dia (6.35mm) |
|
|
3006P-1-203TRIMMER 20KOHM 0.75W PC PIN SIDE |
266 |
|
Datasheet |
Trimpot® 3006 - Sealed | Tube | Active | 20 kOhms | 0.75W, 3/4W | ±10% | ±100ppm/°C | 15.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.190" Face (6.35mm x 4.83mm) |
|
|
3329H-1-502LFTRIMMER 5K OHM 0.5W PC PIN TOP |
150 |
|
Datasheet |
Trimpot® 3329 - Sealed | Tube | Active | 5 kOhms | 0.5W, 1/2W | ±10% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Round - 0.250" Dia (6.35mm) |
|
PVG5A201C03R00TRIMMER 200 OHM 0.25W J LEAD TOP |
143 |
|
Datasheet |
PVG5 | Tape & Reel (TR) | Active | 200 Ohms | 0.25W, 1/4W | ±10% | ±150ppm/°C | 11.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.189" x 0.138" Face (4.80mm x 3.50mm) |
|
TS53YL501MR10TRIMMER 500 OHM 0.25W GW TOP ADJ |
23,084 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 500 Ohms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | Gull Wing | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
TS53YJ203MR10TRIMMER 20K OHM 0.25W J LEAD TOP |
5,614 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 20 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YJ104MR10TRIMMER 100KOHM 0.25W J LEAD TOP |
3,537 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 100 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YL502MR10TRIMMER 5K OHM 0.25W GW TOP ADJ |
2,904 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 5 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | Gull Wing | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YL103MR10TRIMMER 10K OHM 0.25W GW TOP ADJ |
2,553 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 10 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | Gull Wing | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YJ501MR10TRIMMER 500 OHM 0.25W J LEAD TOP |
1,905 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 500 Ohms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YL102MR10TRIMMER 1K OHM 0.25W GW TOP ADJ |
1,301 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 1 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | Gull Wing | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
|
TS53YL104MR10TRIMMER 100K OHM 0.25W GW TOP |
771 |
|
Datasheet |
TS53 | Tape & Reel (TR) | Active | 100 kOhms | 0.25W, 1/4W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | Gull Wing | Square - 0.197" x 0.197" Face (5.00mm x 5.00mm) |
|
3266X-1-503LFTRIMMER 50KOHM 0.25W PC PIN SIDE |
3,250 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 50 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Side Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
3266W-1-123LFTRIMMER 12K OHM 0.25W PC PIN TOP |
729 |
|
Datasheet |
Trimpot® 3266 - Sealed | Tube | Active | 12 kOhms | 0.25W, 1/4W | ±10% | ±100ppm/°C | 12.0 | Top Adjustment | Cermet | Through Hole | PC Pins | Rectangular - 0.250" x 0.170" Face (6.35mm x 4.32mm) |
|
3312J-1-203ETRIMMER 20K OHM 0.1W J LEAD TOP |
3,691 |
|
Datasheet |
Trimpot® 3312 - Sealed | Tape & Reel (TR) | Active | 20 kOhms | 0.1W, 1/10W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.110" x 0.098" Face (2.80mm x 2.50mm) |
|
|
3312J-1-104ETRIMMER 100K OHM 0.1W J LEAD TOP |
2,552 |
|
Datasheet |
Trimpot® 3312 - Sealed | Tape & Reel (TR) | Active | 100 kOhms | 0.1W, 1/10W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.110" x 0.098" Face (2.80mm x 2.50mm) |
|
|
3312J-1-501ETRIMMER 500 OHM 0.1W J LEAD TOP |
1,894 |
|
Datasheet |
Trimpot® 3312 - Sealed | Tape & Reel (TR) | Active | 500 Ohms | 0.1W, 1/10W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.110" x 0.098" Face (2.80mm x 2.50mm) |
|
|
3312J-1-503ETRIMMER 50K OHM 0.1W J LEAD TOP |
1,179 |
|
Datasheet |
Trimpot® 3312 - Sealed | Tape & Reel (TR) | Active | 50 kOhms | 0.1W, 1/10W | ±20% | ±100ppm/°C | 1.0 | Top Adjustment | Cermet | Surface Mount | J Lead | Rectangular - 0.110" x 0.098" Face (2.80mm x 2.50mm) |
