Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2530650000SPD TYPE 2 1.5KVDC MCOV 3 POLE |
9 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 3 | 1.5kVDC | 20 kA | 30 kA | 65 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | CE, cURus, VDE |
|
|
2801289SPD 10VAC/15VDC MCOV 1 POLE |
2 |
|
Datasheet |
PT | Bulk | Active | - | Base + Module | 1 | 10VAC, 15VDC | 10 kA | 20 kA | - | - | 900 V | -40°C ~ 70°C | - | DIN Rail | UL |
|
|
SPDN-D277-3YSPD TYPE 1 350V MCOV 1 POLE |
2 |
|
Datasheet |
SPDN-D | Bulk | Active | Type 1 | Module Only | 1 | 350V | 20 kA | 50 kA | 200 kA | 2 kV | - | -35°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
|
SPDN-D120-3YSPD TYPE 1 150V MCOV 1 POLE |
2 |
|
Datasheet |
SPDN-D | Bulk | Active | Type 1 | Module Only | 1 | 150V | 20 kA | 50 kA | 200 kA | 1 kV | - | -35°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
|
1260-2SMG-230SPD 275VAC MCOV 1 POLE |
9 |
|
Datasheet |
1260 | Box | Active | - | Base + Module | 1 | 275VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1250A-3S-600SPD TYP 2/TYP 4 690V MCOV 3 POLE |
10 |
|
Datasheet |
1250A | Box | Active | Type 2, Type 4 | Base + Module | 3 | 690V | 20 kA | 40 kA | 200 kA | 2.5 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
1260-2NSMG-120SPD 150VAC MCOV 1 POLE |
10 |
|
Datasheet |
1260 | Box | Active | - | Base + Module | 1 | 150VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1250A-3S-480SPD TYP 2/TYP 4 550V MCOV 3 POLE |
6 |
|
Datasheet |
1250A | Box | Active | Type 2, Type 4 | Base + Module | 3 | 550V | 20 kA | 50 kA | 200 kA | 1.8 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
|
1093400000SPD 28VAC/40VDC MCOV 1 POLE |
3 |
|
Datasheet |
- | Box | Active | - | Module Only | 1 | 28VAC, 40VDC | 2.5 kA | 10 kA | - | - | - | -40°C ~ 70°C | - | DIN Rail | CE, UL |
|
2910390SPD TYPE 1 750VAC MCOV 1 POLE |
3 |
|
Datasheet |
VAL-US | Bulk | Active | Type 1 | Base + Module | 1 | 750VAC | 15 kA | 30 kA | 25 kA | 4 kV | 2.9 kV | -40°C ~ 80°C | - | DIN Rail | cUL, UL |
|
|
2730550000SPD TYPE 2 300VAC MCOV 3 POLE |
8 |
|
Datasheet |
- | Box | Active | Type 2 | Base + Module | 3 | 300VAC | 20 kA | 50 kA | 200 kA | - | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
|
|
1250A-4S-400SPD TYP 2/TYP 4 420V MCOV 4 POLE |
10 |
|
Datasheet |
1250A | Box | Active | Type 2, Type 4 | Base + Module | 4 | 420V | 20 kA | 50 kA | 200 kA | 1.5 kV | - | -40°C ~ 85°C | Remote Signaling Contacts | DIN Rail | - |
|
2839211SPD 4VAC/6VDC MCOV 1 POLE |
3 |
|
Datasheet |
- | Bulk | Active | - | Base + Module | 1 | 4VAC, 6VDC | 10 kA | 10 kA | - | - | 450 V | -40°C ~ 85°C | - | DIN Rail | cUL, EAC, UL |
|
2804380SPD TYPE 2 640VAC MCOV 2 POLE |
20 |
|
Datasheet |
- | Bulk | Active | Type 2 | Module Only | 2 | 640VAC | 20 kA | 40 kA | 25 kA | - | 1.8 kV | -40°C ~ 80°C | - | DIN Rail | CB, CCA, CSA, cUL, cULus, EAC, KEMA-KEUR, OVE, UL |
|
1352220000SPD TYP1/TYP2 280VAC/230VDC MCOV |
3 |
|
Datasheet |
- | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 280VAC, 230VDC | 25 kA | 50 kA | 25 kA | - | - | -40°C ~ 70°C | Remote Signaling Contacts | DIN Rail | CE, EAC, UL |
|
|
HAW562-8DASPD TYPE 1 33VDC/23.3VAC MCOV |
8 |
|
Datasheet |
HAW562 | Box | Active | Type 1 | Base + Module | 1 | 33VDC, 23.3VAC | 5 kA | - | - | - | 1.4 kV | -40°C ~ 80°C | Visual Life Indicator | DIN Rail | - |
|
|
2905350SPD TYPE 2 350VAC MCOV 1 POLE |
5 |
|
Datasheet |
VAL | Bulk | Active | Type 2 | Base + Module | 1 | 350VAC | 20 kA | 40 kA | 50 kA | - | 850 V | -40°C ~ 80°C | - | DIN Rail | CB, cUR, cURus, EAC, UR |
|
|
2905471SPD TYPE 1/TYPE 2 350VAC MCOV |
2 |
|
Datasheet |
FLT | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 350VAC | 25 kA | - | 25 kA | - | 1.5 kV | -40°C ~ 80°C | - | DIN Rail | CB, cURus, EAC |
|
|
1260-2SMG-120SPD 150VAC MCOV 1 POLE |
10 |
|
Datasheet |
1260 | Box | Active | - | Base + Module | 1 | 150VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
2905472SPD TYPE 1 350VAC MCOV 1 POLE |
3 |
|
Datasheet |
FLT | Bulk | Active | Type 1 | Base + Module | 1 | 350VAC | 100 kA | - | - | 1.2 kV | 1.5 kV | -40°C ~ 80°C | - | DIN Rail | CB, cUR, cURus, EAC, UR |
Surge Protection Devices (SPDs) Electronic Components
Explore Surge Protection Devices (SPDs) electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
