RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BGS16MA12E6327XTSA1IC RF SWITCH SP6T 6GHZ ATSLP12 |
442 |
|
Datasheet |
- | 12-UFQFN Exposed Pad | Tape & Reel (TR) | Last Time Buy | LTE, W-CDMA | - | SP6T | 100MHz ~ 6GHz | 27dB | 1.3dB | 6GHz | - | - | DC Blocked | 50Ohm | 1.65V ~ 1.95V | -40°C ~ 85°C | - | - | - | ATSLP-12-10 |
|
|
TS8423KIC RF SWITCH SPDT 5GHZ 16QFN |
6 |
|
- |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 30MHz ~ 5GHz | 22dB | 0.5dB | 5GHz | - | 77dBm | - | 50Ohm | 2.6V ~ 5.25V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
|
ZSW2-63DR+REFLECTIVE SPDT, SSS, 5-6000 MHZ |
6 |
|
- |
- | - | Tray | Active | General Purpose | Reflective | SPDT | 5MHz ~ 6GHz | 24dB | 1.1dB | 6GHz | - | 75dBm | - | 50Ohm | 2.3V ~ 4.8V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R570442000IC RF SWITCH SPDT 18GHZ MODULE |
2 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
BGSA12GN10E6327XTSA1IC RF SWITCH SPDT 5GHZ TSNP10-1 |
94 |
|
Datasheet |
- | 10-XFQFN | Tape & Reel (TR) | Active | Cellular, 3G, 4G | - | SPDT | 100MHz ~ 5GHz | 20dB | 0.39dB | 2.69GHz | - | - | DC Blocked, Single Line Control | 50Ohm | 1.8V ~ 3.6V | -30°C ~ 85°C | - | - | Surface Mount | PG-TSNP-10-1 |
|
|
NJG1818K75-TE1IC RF SWITCH SPDT 7.125GHZ 6DFN |
703 |
|
Datasheet |
- | 6-XFDFN Exposed Pad | Tape & Reel (TR) | Active | 802.11a/b/n/ac/ax/WiFi | - | SPDT | 1GHz ~ 7.125GHz | 23dB | 0.55dB | 7.125GHz | 31dBm | - | - | - | 1.6V ~ 5V | - | - | - | Surface Mount | 6-DFN (1x1) |
|
TS72250KIC RF SWITCH SPDT 6GHZ 16QFN |
71 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 10MHz ~ 6GHz | 45dB | 0.35dB | 800MHz | 42dBm | 73dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
ADRF5250BCPZIC RF SWITCH SP5T 6GHZ 24LFCSP |
57 |
|
Datasheet |
- | 24-WFQFN Exposed Pad, CSP | Strip | Active | General Purpose | Absorptive | SP5T | 100MHz ~ 6GHz | 46dB | 1.8dB | 6GHz | - | 57dBm | - | 50Ohm | 3V ~ 5.25V | -40°C ~ 105°C (TC) | - | - | Surface Mount | 24-LFCSP (4x4) |
|
HMC536LP2IC RF SWITCH SPDT 6GHZ 6DFN |
52 |
|
Datasheet |
- | 6-TDFN Exposed Pad | Strip | Active | Cellular | - | SPDT | 0Hz ~ 6GHz | 29dB | 1dB | 6GHz | 33dBm | 52dBm | - | 50Ohm | 5V | -40°C ~ 85°C | - | - | Surface Mount | 6-DFN (2x2) |
|
|
TS7246KIC RF SWITCH SP4T 3GHZ 16QFN |
46 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Not For New Designs | Cellular, LTE | Reflective | SP4T | 1MHz ~ 3GHz | 40dB | 0.45dB | 800MHz | 42dBm | 73dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
HMC784AMS8GEIC RF SWITCH SPDT 4GHZ 8MSOP |
33 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | Strip | Active | WiMAX / WiBro | Reflective | SPDT | 0Hz ~ 4GHz | 30dB | 1.3dB | 4GHz | 41dBm | 60dBm | - | 50Ohm | 5V | -40°C ~ 85°C | - | - | Surface Mount | 8-MSOP |
|
TS74230LIC RF SWITCH SPDT 3GHZ 32QFN |
45 |
|
Datasheet |
Symmetric | 32-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 1MHz ~ 3GHz | 45dB | 0.40dB | 800MHz | 46dBm | 74dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (4x4) |
|
MMS006PP3IC RF SWITCH SPDT 20GHZ DIE |
21 |
|
Datasheet |
- | Die | Tray | Active | Radar | Absorptive | SPDT | 0Hz ~ 20GHz | 40dB | 2dB | 20GHz | 25dBm | 43dBm | - | 50Ohm | - | -40°C ~ 85°C | - | - | - | Die |
|
MA8334-004IC RF SWITCH SP3T 1GHZ 844-004 |
22 |
|
Datasheet |
MA8334 | 844-004 | Tray | Active | General Purpose | - | SP3T | 10MHz ~ 1GHz | 24dB (min) | 0.35dB (max) | 1GHz | - | - | - | 50Ohm | - | -65°C ~ 125°C | - | - | Chassis Mount | 844-004 |
|
HMC244AG16IC RF SWITCH SP4T 4GHZ 16SMT |
6 |
|
Datasheet |
- | 16-LQFP | Strip | Active | Radar | - | SP4T | 0Hz ~ 4GHz | 28dB | 1.2dB | 4GHz | 28dBm | 45dBm | - | 50Ohm | 5V | -40°C ~ 85°C | - | - | Surface Mount | 16-SMT (5.84x5.84) |
|
R516433100IC RF SWITCH SPDT 18GHZ MODULE |
5 |
|
Datasheet |
- | Module | Strip | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 40dB (min) | 1dB (max) | 18GHz | - | - | - | 50Ohm | 20.5V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R570423000IC RF SWITCH SPDT 18GHZ MODULE |
3 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
HMC641A-SXIC RF SWITCH SP4T 18GHZ DIE |
4 |
|
Datasheet |
- | Die | Tray | Active | VSAT | Absorptive | SP4T | 0Hz ~ 18GHz | 38dB | 2.1dB | 8GHz | - | 41dBm | - | 50Ohm | - | -40°C ~ 85°C | - | - | - | Die |
|
SW-314-PINIC RF SWITCH SP4T 3GHZ CR-14 |
24 |
|
Datasheet |
- | CR-14 | Bulk | Active | General Purpose | Absorptive | SP4T | 0Hz ~ 3GHz | 30dB (min) | - | 3GHz | 27dBm | - | - | 50Ohm | - | -55°C ~ 125°C | - | - | - | CR-14 |
|
SW-313-PINIC RF SWITCH SPDT 3GHZ CR-9 |
10 |
|
Datasheet |
- | CR-9 | Bulk | Active | General Purpose | Absorptive | SPDT | 0Hz ~ 3GHz | 35dB (min) | - | 3GHz | 30dBm | - | - | 50Ohm | - | -55°C ~ 125°C | - | - | - | CR-9 |
RF Switches Electronic Components
Explore RF Switches electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
