| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CM150DU-12FIGBT MOD 600V 150A 520W |
6,079 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | Trench | Half Bridge | 600 V | 150 A | 520 W | 2.2V @ 15V, 150A | 1 mA | 41 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
|
FP15R12YT3BOMA1IGBT MOD 1200V 25A 110W |
2,762 |
|
- |
- | Module | Tray | Obsolete | - | Three Phase Inverter | 1200 V | 25 A | 110 W | 2.15V @ 15V, 15A | 5 mA | 1.1 nF @ 25 V | Three Phase Bridge Rectifier | Yes | -40°C ~ 125°C | Chassis Mount | Module |
|
|
CM100E3U-24HIGBT MOD 1200V 100A 650W |
9,574 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | - | Single | 1200 V | 100 A | 650 W | 3.7V @ 15V, 100A | 1 mA | 15 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
|
FP50R12N2T4PB81BPSA2LOW POWER ECONO |
5,584 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
VS-GT100TP60NIGBT MOD 600V 160A INT-A-PAK |
5,200 |
|
- |
- | INT-A-PAK (3 + 4) | Bulk | Obsolete | Trench | Half Bridge | 600 V | 160 A | 417 W | 2.1V @ 15V, 100A | 5 mA | 7.71 nF @ 30 V | Standard | No | 175°C (TJ) | Chassis Mount | INT-A-PAK |
|
|
MWI35-12A7IGBT MODULE 1200V 62A 280W E2 |
7,247 |
|
- |
- | E2 | Box | Obsolete | NPT | Three Phase Inverter | 1200 V | 62 A | 280 W | 2.8V @ 15V, 35A | 2 mA | 2 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | E2 |
|
|
FP15R12KE3BOMA1MOD IGBT LOW PWR EASY2-1 |
2,636 |
|
- |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
F3L200R07W2S5FB56BPSA1LOW POWER EASY |
5,441 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
CM75DU-24HIGBT MOD 1200V 75A 600W |
9,298 |
|
- |
IGBTMOD™ | Module | Bulk | Obsolete | - | Half Bridge | 1200 V | 75 A | 600 W | 3.7V @ 15V, 75A | 1 mA | 11 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
CM100DY-24AIGBT MOD 1200V 100A 672W |
4,168 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | - | Half Bridge | 1200 V | 100 A | 672 W | 3V @ 15V, 100A | 1 mA | 17.5 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
|
APTGF90DA60CT1GIGBT MODULE 600V 110A 416W SP1 |
6,945 |
|
- |
- | SP1 | Bulk | Obsolete | NPT | Single | 600 V | 110 A | 416 W | 2.5V @ 15V, 100A | 250 µA | 4.3 nF @ 25 V | Standard | Yes | - | Chassis Mount | SP1 |
|
|
MWI25-12A7IGBT MODULE 1200V 50A 225W E2 |
4,224 |
|
- |
- | E2 | Box | Obsolete | NPT | Three Phase Inverter | 1200 V | 50 A | 225 W | 2.7V @ 15V, 25A | 2 mA | 1.65 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount | E2 |
|
|
VS-20MT120PFPMODULES IGBT - MTP SWITCH |
6,283 |
|
- |
HEXFRED® | 16-MTP Module | Bulk | Active | Trench Field Stop | Full Bridge | 1200 V | 57 A | 240 W | 2.16V @ 15V, 20A | 200 µA | 1430 pF @ 30 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | 16-MTP |
|
|
FS100R12N2T4BPSA2LOW POWER ECONO AG-ECONO2B-411 |
8,746 |
|
- |
EconoPACK™ 2 | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 100 A | - | 2.1V @ 15V, 100A | 1 mA | 6.3 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | AG-ECONO2B |
|
CM225DX-24S1IGBT MOD 1200V 225A 1250W |
6,880 |
|
- |
- | Module | Tray | Discontinued at Digi-Key | - | Half Bridge | 1200 V | 225 A | 1250 W | 2.35V @ 15V, 225A | 1 mA | 20 nF @ 10 V | Standard | Yes | -40°C ~ 150°C (TJ) | - | Module |
|
CM100DU-24NFHIGBT MOD 1200V 100A 560W |
6,162 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | - | Half Bridge | 1200 V | 100 A | 560 W | 6.5V @ 15V, 100A | 1 mA | 16 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
|
APTGTQ100A65T1GIGBT MODULE 650V 100A 250W SP1 |
8,169 |
|
- |
- | Module | Bulk | Active | - | Half Bridge | 650 V | 100 A | 250 W | 2.2V @ 15V, 100A | 100 µA | 6 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP1 |
|
|
MWI80-12T6KIGBT MODULE 1200V 80A 270W E1 |
4,361 |
|
- |
- | E1 | Box | Obsolete | Trench | Three Phase Inverter | 1200 V | 80 A | 270 W | 2.4V @ 15V, 50A | 1 mA | 3.6 nF @ 25 V | Standard | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | E1 |
|
CM150DY-12NFIGBT MOD 600V 150A 590W |
3,300 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | - | Half Bridge | 600 V | 150 A | 590 W | 2.2V @ 15V, 150A | 1 mA | 23 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
|
CM100DUS-12FIGBT MOD 600V 100A 350W |
9,418 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | Trench | Half Bridge | 600 V | 100 A | 350 W | 2.7V @ 15V, 100A | 1 mA | 27 nF @ 10 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
IGBT Modules Electronic Components
Explore IGBT Modules electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
