Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2822HC100-RTRFUSE BOARD MOUNT 100A 72VDC 2SMD |
1,237 |
|
Datasheet |
2822HC | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 100 A | - | 72 V | - | 500A | - | cURus, UL | - | - | 0.303" L x 0.236" W x 0.181" H (7.70mm x 6.00mm x 4.60mm) | |
|
0298060.ZXBFUSE AUTO 60A 32VDC AUTO LINK |
556 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 60 A | - | 32 V | Slow Blow | 2kA | - | UL | -40°C ~ 125°C | - | 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
0508.315MXEPFUSE CERM 315MA 1KVAC 1000VDC |
1,062 |
|
Datasheet |
508 | Bulk | Active | Through Hole | Cartridge, Ceramic | 315 mA | 1 kV | 1000 V | Fast Blow | 10kA | 0.071 | CE, cULus | -55°C ~ 125°C | - | 0.275" Dia x 1.288" L (6.99mm x 32.72mm) | |
|
|
0298080.ZXBFUSE AUTO 80A 32VDC AUTO LINK |
183 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 80 A | - | 32 V | Slow Blow | 2kA | - | UL | -40°C ~ 125°C | Red | 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
|
0298040.ZXBFUSE AUTO 40A 32VDC AUTO LINK |
156 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 40 A | - | 32 V | Slow Blow | 2kA | - | UL | -40°C ~ 125°C | - | 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
3298600.ZXSTAFUSE AUTO 600A 32VDC MODULE |
337 |
|
Datasheet |
ZCASE® SMZ | Bulk | Active | Bolt Mount | Automotive | 600 A | - | 32 V | - | 2kA | 3000000.0 | - | -40°C ~ 125°C | - | 1.185" L x 1.047" W x 0.634" H (30.10mm x 26.60mm x 16.10mm) | |
|
3298500.ZXSTAFUSE AUTO 500A 32VDC MODULE |
285 |
|
Datasheet |
ZCASE® SMZ | Bulk | Active | Bolt Mount | Automotive | 500 A | - | 32 V | - | 2kA | 1550000.0 | - | -40°C ~ 125°C | - | 1.185" L x 1.047" W x 0.634" H (30.10mm x 26.60mm x 16.10mm) | |
|
0977016.MXEPFUSE CERM 16A 500VAC 450VDC 5X20 |
352 |
|
Datasheet |
977 | Bulk | Active | Through Hole | Cartridge, Ceramic | 16 A | 500 V | 450 V | Slow Blow | 100A AC, 200A DC | 725.0 | CE, PSE | -55°C ~ 125°C | - | 0.228" Dia x 0.886" L (5.80mm x 22.50mm) | |
|
0977.800MXPFUSE CERM 800MA 500VAC 450VDC |
233 |
|
Datasheet |
977 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 800 mA | 500 V | 450 V | Slow Blow | 100A AC, 200A DC | 0.8 | CE, SEMKO | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0298300.ZXHFUSE AUTO 300A 32VDC AUTO LINK |
445 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 300 A | - | 32 V | Slow Blow | 2kA | - | - | -40°C ~ 125°C | Gray | 1.149" L x 0.750" W x 0.422" H (29.20mm x 19.05mm x 10.72mm) | |
|
153.5395.6301FUSE AUTO 300A 32VDC AUTO LINK |
200 |
|
Datasheet |
BF2 | Bulk | Active | Bolt Mount | Automotive | 300 A | - | 32 V | Slow Blow | 2kA | 486000.0 | - | - | Gray | 1.142" L x 0.740" W x 0.382" H (29.00mm x 18.80mm x 9.70mm) | |
|
BK/GDA-50MAFUSE CERAMIC 50MA 250VAC 5X20MM |
282 |
|
Datasheet |
GDA | Bulk | Active | Requires Holder | Cartridge, Ceramic | 50 mA | 250 V | - | Fast Blow | 1.5kA | 0.0017 | CCC, CSA, IMQ, SEMKO, UL | - | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
0527050.UXTHPFUSE CERM 50A 305VAC 305VDC RAD |
110 |
|
Datasheet |
527 | Tray | Active | Through Hole | Cartridge, Ceramic | 50 A | 305 V | 305 V | Fast Blow | 10kA | 2460.0 | cURus | -55°C ~ 125°C | - | 0.293" Dia x 1.352" L (7.45mm x 34.35mm) | |
|
|
0298350.ZXHFUSE AUTO 350A 32VDC AUTO LINK |
279 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 350 A | - | 32 V | Slow Blow | 2kA | - | - | -40°C ~ 125°C | Green | 1.149" L x 0.750" W x 0.422" H (29.20mm x 19.05mm x 10.72mm) | |
|
|
0298500.ZXHFUSE AUTO 500A 32VDC AUTO LINK |
170 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 500 A | - | 32 V | Slow Blow | 2kA | - | - | -40°C ~ 125°C | Brown | 1.149" L x 0.750" W x 0.422" H (29.20mm x 19.05mm x 10.72mm) | |
|
0607063.UXTH500PFUSE CERM 63A 500VAC 500VDC RAD |
773 |
|
Datasheet |
607 | Tray | Active | Through Hole | Cartridge, Ceramic | 63 A | 500 V | 500 V | - | 5kA AC, 10kA DC | 7060.0 | cURus, TUV | -55°C ~ 125°C | - | 0.482" Dia x 1.315" L (12.25mm x 33.40mm) | |
|
0998200.UX-2M6FUSE AUTO 200A 70VDC AUTO LINK |
351 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 200 A | - | 70 V | Slow Blow | 2.5kA | 123600.0 | - | -40°C ~ 125°C | Blue | 1.150" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
|
0998250.UX-2M6FUSE AUTO 250A 70VDC AUTO LINK |
320 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 250 A | - | 70 V | Slow Blow | 2.5kA | 220000.0 | - | -40°C ~ 125°C | Pink | 1.150" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
|
0998200.UX-2M8FUSE AUTO 200A 70VDC AUTO LINK |
239 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 200 A | - | 70 V | Slow Blow | 2.5kA | 123600.0 | - | -40°C ~ 125°C | Blue | 1.150" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
|
0998500.UX-2M8FUSE AUTO 500A 70VDC AUTO LINK |
112 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 500 A | - | 70 V | Slow Blow | 2.5kA | 1800000.0 | - | -40°C ~ 125°C | Brown | 1.150" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) |
