Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
P278SU104M480ACAP FILM 0.1UF 20% 480VAC RADIAL |
3,457 |
|
Datasheet |
Radial | 0.1 µF | ±20% | 480V | - | Paper, Metallized | - | -40°C ~ 110°C | Through Hole | 1.063" L x 0.394" W (27.00mm x 10.00mm) | - | - | 0.886" (22.50mm) | EMI, RFI Suppression | X1 | - |
|
SMP253MA4250MTR24CAP FILM 2500PF 20% 1.5KVDC SMD |
555 |
|
Datasheet |
Nonstandard SMD | 2500 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.264" (6.70mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
|
SMP253MA4100MTR24CAP FILM 1000PF 20% 1.5KVDC SMD |
2,937 |
|
Datasheet |
Nonstandard SMD | 1000 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.264" (6.70mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
FKP1T023306D00JSSDFKP 1 0.033 F 1600 VDC 13X24X31. |
943 |
|
Datasheet |
Radial | 0.033 µF | ±5% | 650V | 1600V (1.6kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.240" L x 0.512" W (31.50mm x 13.00mm) | 0.945" (24.00mm) | PC Pins | 1.083" (27.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT | AEC-Q200 | - |
|
|
FKP1U024707E00JSSDFKP 1 0.047 UF 2000 VDC 17X29X41 |
9,128 |
|
Datasheet |
Radial | 0.047 µF | ±5% | 700V | 2000V (2kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.634" L x 0.669" W (41.50mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT | AEC-Q200 | - |
|
|
SMP253MA4390MTR24CAP FILM 3900PF 20% 1.5KVDC SMD |
200 |
|
Datasheet |
Nonstandard SMD | 3900 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.264" (6.70mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
PME271E522MR30CAP FILM 0.022UF 20% 630VDC RAD |
1,241 |
|
Datasheet |
Radial | 0.022 µF | ±20% | 300V | 630V | Paper, Metallized | - | -40°C ~ 110°C | Through Hole | 0.748" L x 0.287" W (19.00mm x 7.30mm) | 0.512" (13.00mm) | PC Pins | 0.598" (15.20mm) | EMI, RFI Suppression | X1 | - |
|
SMDIC03470TB00MQ00CAP FILM 0.47UF 20% 63VDC 2824 |
167 |
|
Datasheet |
2824 (7260 Metric) | 0.47 µF | ±20% | 40V | 63V | Polyphenylene Sulfide (PPS), Metallized | - | -55°C ~ 140°C | Surface Mount | 0.283" L x 0.240" W (7.20mm x 6.10mm) | 0.209" (5.30mm) | Solder Pads | - | General Purpose | - | - |
|
|
WMF6P15K-FCAP FILM 0.15UF 10% 630VDC AXIAL |
2,549 |
|
Datasheet |
Axial | 0.15 µF | ±10% | - | 630V | Polyester | - | -55°C ~ 125°C | Through Hole | 0.685" Dia x 1.374" L (17.40mm x 34.90mm) | - | PC Pins | - | General Purpose | - | - |
|
JS211126-AACAP FILM 12UF 10% 210VAC CHAS MT |
1,483 |
|
Datasheet |
Rectangular Box | 12 µF | ±10% | 210V | - | Polypropylene (PP), Metallized | - | -25°C ~ 70°C | Chassis Mount | 1.555" L x 1.051" W (39.50mm x 26.70mm) | 1.280" (32.50mm) | Quick Connect - 0.187" (4.7mm) | - | Motor Run | - | - |
|
|
SMP253MA4220MTR24CAP FILM 2200PF 20% 1.5KVDC SMD |
1,214 |
|
Datasheet |
Nonstandard SMD | 2200 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.264" (6.70mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
|
SMDND04100TB00MQ00CAP FILM 1UF 20% 100VDC 2824 |
146 |
|
Datasheet |
2824 (7260 Metric) | 1 µF | ±20% | 63V | 100V | Polyester, Polyethylene Naphthalate (PEN), Metallized | - | -55°C ~ 125°C | Surface Mount | 0.283" L x 0.240" W (7.20mm x 6.10mm) | 0.209" (5.30mm) | Solder Pads | - | General Purpose | - | - |
|
|
R49AR422050B1MCAP FILM SAFETY/EMI SUPP RAD |
8,374 |
|
Datasheet |
Radial | 2.2 µF | ±20% | 330V | 800V | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.303" (33.10mm) | PC Pins | 1.083" (27.50mm) | EMI, RFI Suppression | X1 | - |
|
|
SMP253MA4330MTR24CAP FILM 3300PF 20% 1.5KVDC SMD |
128 |
|
Datasheet |
Nonstandard SMD | 3300 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.453" W (12.70mm x 11.50mm) | 0.264" (6.70mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
MPX21W3100FH00MSSDCAP FILM 0.1UF 20% 275VAC RAD |
130 |
|
Datasheet |
Radial | 0.1 µF | ±20% | 275V | - | Paper, Metallized | - | -40°C ~ 110°C | Through Hole | 1.102" L x 0.315" W (28.00mm x 8.00mm) | 0.787" (20.00mm) | PC Pins | 0.886" (22.50mm) | EMI, RFI Suppression | X2 | - |
|
X2P2684KT1B0265170085ES0X2 275VAC 0.68UF 10% P=22.5MM W2 |
996 |
|
Datasheet |
Radial | 0.68 µF | ±10% | 275V | - | Polypropylene (PP), Metallized | - | -40°C ~ 110°C | Through Hole | 1.043" L x 0.335" W (26.50mm x 8.50mm) | 0.689" (17.50mm) | PC Pins | 0.886" (22.50mm) | EMI, RFI Suppression | X2 | - |
|
|
FKP1T026807D00JSSDFKP 1 0.068 UF 1600 VDC 15X26X41 |
492 |
|
Datasheet |
Radial | 0.068 µF | ±5% | 650V | 1600V (1.6kV) | Polypropylene (PP), Metallized | - | -55°C ~ 105°C | Through Hole | 1.634" L x 0.591" W (41.50mm x 15.00mm) | 1.024" (26.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; High Frequency, Switching; High Pulse, DV/DT | AEC-Q200 | - |
|
|
FKP4G034706G00JSSDFKP 4 0.47 UF 400 VDC 17X29X31.5 |
472 |
|
Datasheet |
Radial | 0.47 µF | ±5% | 250V | 400V | Polypropylene (PP) | - | -55°C ~ 105°C | Through Hole | 1.240" L x 0.669" W (31.50mm x 17.00mm) | 1.142" (29.00mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
SMP253MA4470MTV24CAP FILM 4700PF 20% 1.5KVDC SMD |
1,588 |
|
Datasheet |
Nonstandard | 4700 pF | ±20% | 250V | 1500V (1.5kV) | Paper, Metallized | - | -40°C ~ 100°C | Surface Mount | 0.500" L x 0.449" W (12.70mm x 11.40mm) | 0.256" (6.50mm) | Solder Pads | - | EMI, RFI Suppression | Y2 | - |
|
QAK2G474KTPCAP FILM 0.47UF 10% 400VDC AXIAL |
137 |
|
Datasheet |
Axial | 0.47 µF | ±10% | - | 400V | Polyester, Metallized | - | -40°C ~ 85°C | Through Hole | 0.669" W, 0.295" T x 0.906" L (17.00mm, 7.50mm x 23.00mm) | - | PC Pins | - | General Purpose | - | - |
Film Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Film Capacitors?
This category includes related Film Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Film Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Film Capacitors and other electronic components.
