FET, MOSFET Arrays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DMN62D2UVQ-13MOSFET 2N-CH 60V 0.45A SOT563 |
4,098 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 60V | 450mA (Ta) | 2Ohm @ 50mA, 5V | 1V @ 250µA | 0.8nC @ 4.5V | 41pF @ 30V | 500µW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
DMG6302UDW-7MOSFET 2P-CH 25V 0.15A SOT363 |
2,614 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 25V | 150mA (Ta) | 10Ohm @ 140mA, 4.5V | 1.5V @ 250µA | 0.34nC @ 4.5V | 30.7pF @ 10V | 310mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-363 |
|
|
DMN67D8LDW-13MOSFET 2N-CH 60V 0.23A SOT363 |
6,779 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 60V | 230mA | 5Ohm @ 500mA, 10V | 2.5V @ 250µA | 0.82nC @ 10V | 22pF @ 25V | 320mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-363 |
|
|
DMN3350LDWQ-13MOSFET 2N-CH 30V 0.89A SOT363 |
8,051 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 30V | 890mA (Ta) | 400mOhm @ 590mA, 10V | 1.6V @ 250µA | 1.1nC @ 10V | 38.4pF @ 15V | 340mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMC3350LDWQ-13MOSFET N/P-CH 30V 0.9A SOT363 |
9,919 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 30V | 900mA (Ta), 600mA (Ta) | 400mOhm @ 590mA, 10V, 900mOhm @ 420mA, 10V | 1.6V @ 250µA, 2.6V @ 250µA | 1.1nC @ 10V, 800pC @ 10V | 38.4pF @ 15V, 19pF @ 15V | 350mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMN62D0UV-13MOSFET 2N-CH 60V 0.49A SOT563 |
7,444 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 60V | 490mA (Ta) | 2Ohm @ 100mA, 4.5V | 1V @ 250µA | 0.5nC @ 4.5V | 32pF @ 30V | 470mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
|
DMN3401LDWQ-13MOSFET 2N-CH 30V 0.8A SOT363 |
5,461 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 30V | 800mA (Ta) | 400mOhm @ 590mA, 10V | 1.6V @ 250µA | 1.2nC @ 10V | 50pF @ 15V | 290mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMP58D1LVQ-13MOSFET 2P-CH 50V 0.22A SOT563 |
2,977 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel | - | 50V | 220mA (Ta) | 8Ohm @ 100mA, 5V | 2V @ 250µA | 1.2nC @ 10V | 37pF @ 25V | 490mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
|
DMN62D2UDWQ-13MOSFET 2N-CH 60V 0.34A SOT363 |
4,499 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 60V | 340mA (Ta) | 2Ohm @ 50mA, 5V | 1V @ 250µA | 0.8nC @ 4.5V | 41pF @ 30V | 300mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMN52D0UDWQ-13MOSFET 2N-CH 50V 0.35A SOT363 |
3,566 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 50V | 350mA (Ta) | 2Ohm @ 50mA, 5V | 1V @ 250µA | 1.5nC @ 10V | 42.3pF @ 25V | 300mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMN63D1LV-13MOSFET 2N-CH 60V 0.55A SOT563 |
2,335 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 60V | 550mA (Ta) | 2Ohm @ 500mA, 10V | 2.5V @ 1mA | 0.392nC @ 4.5V | 30pF @ 25V | 940mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-563 |
|
|
MMFTN620KD-AQMOSFET 2N-CH 60V 0.35A SOT26 |
6,977 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Bulk | Active | MOSFET (Metal Oxide) | 2 N-Channel | Logic Level Gate | 60V | 350mA | 1.5Ohm @ 500mA, 10V | 1.5V @ 250µA | 1.3nC @ 10V | 35pF @ 25V | 500mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-26 |
|
|
SI3439KU6-TPMOSFET N/P-CH 20V 0.75A 6DFN |
9,879 |
|
- |
- | 6-XFDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 20V | 750mA (Ta), 520mA (Ta) | 250mOhm @ 500mA, 4.5V, 850mOhm @ 500mA, 4.5V | 1.2V @ 250µA | 1.2nC @ 4.5V, 1.4nC @ 4.5V | 33pF @ 16V, 36pF @ 10V | 350mW (Tj) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DFN1010B-6 |
|
|
DMC2710UVQ-13MOSFET N/P-CH 20V 1.1A SOT563 |
2,466 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 20V | 1.1A (Ta), 800mA (Ta) | 400mOhm @ 600mA, 4.5V, 700mOhm @ 430mA, 4.5V | 1V @ 250µA | 0.6nC @ 4.5V, 0.7nC @ 4.5V | 42pF @ 16V, 49pF @ 16V | 460mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
6703MOSFET 20V 2.9A SOT23-6L |
4,693 |
|
Datasheet |
- | SOT-23-6 | Active | MOSFET (Metal Oxide) | - | - | 20V | 2.9A (Ta), 3A (Ta) | 59mOhm @ 2.5A, 2.5V, 110mOhm @ 3A, 4.5V | 1.2V @ 250µA, 1V @ 250µA | - | 300pF @ 10V, 405pF @ 10V | 1.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-6L | |
|
|
DMN33D8LDWQ-13MOSFET 2N-CH 30V 0.25A SOT363 |
6,069 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 30V | 250mA (Ta) | 2.4Ohm @ 250mA, 10V | 1.5V @ 100µA | 1.23nC @ 10V | 48pF @ 5V | 350mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-363 |
|
|
DMN32D4SDW-13MOSFET 2N-CH 30V 0.65A SOT363 |
6,266 |
|
Datasheet |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 30V | 650mA | 400mOhm @ 250mA, 10V | 1.6V @ 250µA | 1.3nC @ 10V | 50pF @ 15V | 290mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-363 |
|
|
DMN3732UVTQ-13MOSFET 2N-CH 30V 1.1A TSOT26 |
3,122 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 30V | 1.1A (Ta) | 460mOhm @ 200mA, 4.5V | 950mV @ 250µA | 0.9nC @ 10V | 40.8pF @ 25V | 500mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-26 |
|
|
DMN32D0LVQ-13MOSFET 2N-CH 30V 0.68A SOT563 |
2,814 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel | - | 30V | 680mA (Ta) | 1.2Ohm @ 100mA, 4V | 1.2V @ 250µA | 0.62nC @ 4.5V | 44.8pF @ 15V | 480mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
|
SSM6P56FE,LMMOSFET 2P-CH 20V 0.8A ES6 |
2,704 |
|
- |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel | - | 20V | 800mA (Ta) | 390mOhm @ 800mA, 4.5V | 1V @ 1mA | 1.6nC @ 4.5V | 100pF @ 10V | 150mW | 150°C | - | - | Surface Mount | ES6 |
FET, MOSFET Arrays Electronic Components
Explore FET, MOSFET Arrays electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
