RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TS7226KIC RF SWITCH SPDT 7GHZ 16QFN |
0 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 500MHz ~ 7GHz | 35dB | 0.5dB | 2.6GHz | 42.5dBm | 72dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
TS63410K4T, 1.1 OHM, 100V PEAK RF SWITCH |
0 |
|
Datasheet |
- | 16-VFQFN Exposed Pad | Strip | Active | Cellular | Reflective | SP4T | 1MHz ~ 3GHz | 12dB | 1.4dB | 3GHz | - | 71dBm | DC Blocked | 1.1Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
|
TS7541LIC RF SWITCH SP4T 1.2GHZ 32QFN |
1 |
|
Datasheet |
- | 32-VFQFN Exposed Pad | Strip | Not For New Designs | Cellular | Reflective | SP4T | 30MHz ~ 1.2GHz | 36dB | 0.4dB | 800MHz | - | 70dBm | DC Blocked | - | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (4x4) |
|
|
TS8441LIC RF SWITCH SP4T 4GHZ 32QFN |
0 |
|
Datasheet |
Symmetric | 32-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SP4T | 30MHz ~ 4GHz | 20dB | 1dB | 4GHz | - | 70dBm | - | 50Ohm | 2.6V ~ 5.25V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (4x4) |
|
R570412000LPIC RF SWITCH SPDT 18GHZ MODULE |
0 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -25°C ~ 70°C | - | - | - | Module |
|
R570013005IC RF SWITCH SPDT 3GHZ |
0 |
|
Datasheet |
- | Module | Box | Active | General Purpose | - | SPDT | 0Hz ~ 3GHz | 75dB | 0.25dB | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R570113000IC RF SWITCH SPDT 12.4GHZ MODULE |
0 |
|
Datasheet |
- | Module | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
|
TS7329KIC RF SWITCH SPDT 5GHZ 16QFN |
71 |
|
Datasheet |
Asymmetric | 16-VFQFN Exposed Pad | Strip | Not For New Designs | Cellular, LTE | Reflective | SPDT | 500MHz ~ 5GHz | 30dB | 0.4dB | 2.6GHz | 42dBm | 70dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
|
TS72461KIC RF SWITCH SP4T 3.8GHZ 16QFN |
1 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SP4T | 400MHz ~ 3.8GHz | 45dB | 0.40dB | 800MHz | 40dBm | 70dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
.jpg)
|
R516431100IC RF SWITCH |
0 |
|
Datasheet |
* | - | Strip | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
HMC641ALC4TRIC RF SWITCH SP4T 20GHZ 24QFN |
0 |
|
Datasheet |
- | 24-TFQFN Exposed Pad | Tape & Reel (TR) | Active | VSAT | Absorptive | SP4T | 0Hz ~ 20GHz | 40dB | 2.3dB | 20GHz | 25dBm | 41dBm | - | 50Ohm | - | -40°C ~ 85°C | - | - | Surface Mount | 24-QFN (4x4) |
|
ARD15105QIC RF SWITCH SPDT 18GHZ |
1 |
|
Datasheet |
ARD | Module, Pin Contacts | Bulk | Active | General Purpose | Reflective | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 5V | -55°C ~ 85°C | - | - | - | - |
|
R570863100IC RF SWITCH SPDT 40GHZ MODULE |
0 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 40GHz | 50dB (min) | 0.8dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R591362440IC RF SWITCH SP4T 6GHZ MODULE |
1 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 6GHz | 70dB (min) | 0.3dB (max) | 6GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
BGS15MU14E6327XTSA1IC RF SWITCH SP5T 6GHZ ULGA14-1 |
0 |
|
Datasheet |
- | 14-UFLGA Exposed Pad | Tape & Reel (TR) | Active | General Purpose | - | SP5T | 400MHz ~ 6GHz | 48dB | 1.05dB | 5.925GHz | - | - | - | 50Ohm | 1.65V ~ 1.95V | -40°C ~ 85°C (TA) | - | - | Surface Mount | PG-ULGA-14-1 |
|
BGS14MA11E6327XTSA1IC RF SWITCH SP4T 6GHZ ATSLP11-1 |
0 |
|
Datasheet |
- | 11-UFLGA | Tape & Reel (TR) | Active | LTE, W-CDMA | - | SP4T | 100MHz ~ 6GHz | 18dB | 0.85dB | 6GHz | - | - | - | 50Ohm | 1.7V ~ 3.4V | 125°C (TJ) | - | - | Surface Mount | PG-ATSLP-11-1 |
|
BGSA14M2N10E6327XTSA1IC RF SW SP4T 7.125GHZ TSNP10 |
0 |
|
Datasheet |
- | 10-XFQFN | Tape & Reel (TR) | Active | - | - | SP4T | 400MHz ~ 7.125GHz | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | PG-TSNP-10-9 |
|
|
BGS14WMA9E6327XTSA1IC RF SWITCH SP4T 6GHZ ATSLP9-50 |
0 |
|
Datasheet |
- | 9-UFLGA | Tape & Reel (TR) | Active | Bluetooth, LTE, WLAN | - | SP4T | 50MHz ~ 6GHz | 25dB | 1.15dB | 5.925GHz | - | 65dBm | - | 50Ohm | 1.65V ~ 1.95V | -40°C ~ 85°C (TA) | - | - | Surface Mount | PG-ATSLP-9-50 |
|
|
NSG1001MXTAGIC RF SWITCH SPDT 8.5GHZ 6DFN |
0 |
|
Datasheet |
- | 6-PowerXFDFN | Tape & Reel (TR) | Active | 802.11a/b/g/n/ac/ax, Bluetooth, LTE, WLAN | - | SPDT | 100MHz ~ 8.5GHz | 20dB | 0.65dB | 8.5GHz | - | - | - | - | - | -40°C ~ 125°C | - | - | Surface Mount, Wettable Flank | 6-DFN (1x1) |
|
|
NSVG1001MXTAGIC RF SWITCH SPDT 8.5GHZ 6DFN |
0 |
|
Datasheet |
- | 6-PowerXFDFN | Tape & Reel (TR) | Active | 802.11a/b/g/n/ac/ax, Bluetooth, LTE, WLAN | - | SPDT | 100MHz ~ 8.5GHz | 20dB | 0.65dB | 8.5GHz | - | - | - | - | - | -40°C ~ 125°C | Automotive | AEC-Q100 | Surface Mount, Wettable Flank | 6-DFN (1x1) |
