RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HMC241AQS16ETRIC RF SWITCH SP4T 3.5GHZ 16QSOP |
0 |
|
Datasheet |
- | 16-SSOP (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | CATV | Absorptive | SP4T | 0Hz ~ 3.5GHz | 36dB | 0.8dB | 2.5GHz | 29dBm | 48dBm | - | 50Ohm | 5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QSOP |
|
TS7323KIC RF SWITCH SPDT 4GHZ 16QFN |
1 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 1MHz ~ 4GHz | 42dB | 0.25dB | 800MHz | 43dBm | 75dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
RSW-2-25PA+IC RF SWITCH SPDT 2.5GHZ |
1 |
|
Datasheet |
- | 14-SMD, No Lead | Tape & Reel (TR) | Active | General Purpose | Reflective | SPDT | 0Hz ~ 2.5GHz | 33dB | 1.2dB | 2.5GHz | 29dBm | 41dBm | - | 50Ohm | 5V ~ 7V | -55°C ~ 85°C | - | - | Surface Mount | - |
|
HMC252AQS24ETRIC RF SWITCH SP6T 2.5GHZ 24QSOP |
0 |
|
Datasheet |
- | 24-SSOP (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | General Purpose | - | SP6T | 0Hz ~ 3GHz | 32dB | 1.4dB | 3GHz | 28dBm | 47dBm | - | 50Ohm | 3V ~ 5V | -40°C ~ 85°C | - | - | Surface Mount | 24-QSOP |
|
|
HMC252AQS24EIC RF SWITCH SP6T 2.5GHZ 24QSOP |
0 |
|
Datasheet |
- | 24-SSOP (0.154", 3.90mm Width) | Strip | Active | General Purpose | - | SP6T | 0Hz ~ 3GHz | 32dB | 1.4dB | 3GHz | 28dBm | 47dBm | - | 50Ohm | 3V ~ 5V | -40°C ~ 85°C | - | - | Surface Mount | 24-QSOP |
|
TS7423LIC RF SWITCH SPDT 3GHZ 32QFN |
4 |
|
Datasheet |
Symmetric | 32-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 1MHz ~ 3GHz | 44dB | 0.30dB | 800MHz | 46dBm | 74dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (4x4) |
|
|
TS7441LIC RF SWITCH SP4T 2.7GHZ 32QFN |
1 |
|
Datasheet |
Symmetric | 32-VFQFN Exposed Pad | Strip | Not For New Designs | Cellular, LTE | Reflective | SP4T | 1MHz ~ 2.7GHz | 36dB | 0.40dB | 800MHz | 45dBm | 70dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (4x4) |
|
TS8043NIC RF SWITCH SP4T 1GHZ 32QFN |
0 |
|
- |
Symmetric | 32-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SP4T | 30MHz ~ 1GHz | 36dB | 0.37dB | 1GHz | - | - | - | 50Ohm | 2.6V ~ 5.25V | -40°C ~ 85°C | - | - | Surface Mount | 32-QFN (5x5) |
|
|
ADRF5050BCCZNIC RF SWITCH SP4T 20GHZ 24LGA |
0 |
|
Datasheet |
- | 24-WFLGA Exposed Pad | Strip | Active | General Purpose | Absorptive | SP4T | 100MHz ~ 20GHz | 47dB | 1.2dB | 20GHz | - | 55dB | Single Line Control | - | -3.3V ~ 3.3V | -40°C ~ 105°C | - | - | Surface Mount | 24-LGA (3x3) |
|
|
ADRF5080BCCZNSILICON SP8T SWITCH, 20GHZ, 1 WA |
0 |
|
Datasheet |
- | 36-VFLGA Exposed Pad | Strip | Active | - | Reflective | SP8T | 100MHz ~ 20GHz | 40dB | 1.85dB | 20GHz | 33.5dBm | 55dBm | DC Blocked | 50Ohm | 3.15V ~ 3.45V | -40°C ~ 85°C (TC) | - | - | Surface Mount | 36-LGA (5.5x5.5) |
|
HMC253ALC4TRIC RF SWITCH SP8T 3.5GHZ 24CQFN |
0 |
|
Datasheet |
- | 24-TFCQFN Exposed Pad | Tape & Reel (TR) | Active | WiMax | Absorptive | SP8T | 0Hz ~ 3.5GHz | 43dB | 1.1dB | 2GHz | 24dBm | 43dBm | - | 50Ohm | 5V | -40°C ~ 85°C | - | - | Surface Mount | 24-CQFN (4x4) |
|
R570412100IC RF SWITCH SPDT 18GHZ MODULE |
0 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 18GHz | 60dB (min) | 0.35dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
|
ZASWA2-50DR-FA+ABSORPTIVE SPDT, SSS, DC -50 GHZ |
0 |
|
Datasheet |
- | Module, SMA Connectors | Tray | Active | Cellular, ISM, WCDMA, WiMAX | Absorptive | SPDT | 0Hz ~ 5GHz | 65dB | 3dB | 5GHz | 23dBm | - | - | 50Ohm | -5V, 5V | -20°C ~ 85°C | - | - | Chassis Mount | - |
|
|
ZSWA4-63DR+ABSSP4T, SSS, 1 - 6000 MHZ, 50 |
0 |
|
Datasheet |
- | - | Tray | Active | 3G/4G | Absorptive | SP4T | 1MHz ~ 6GHz | 35dB | 2.2dB | 6GHz | - | 58dBm | - | 50Ohm | 2.3V ~ 3.6V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
ZSWA4-63DRB+SOLID STATE SWITCH, 1 - 6000 MHZ |
0 |
|
Datasheet |
- | Module, SMA Connectors | Tray | Active | 3G/4G | Absorptive | SP4T | 1MHz ~ 6GHz | 35dB | 2.2dB | 6GHz | - | 58dBm | - | 50Ohm | 2.3V ~ 3.6V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
MSP4TA-18+ABSORPTIVE SP4T, MECH. SWITCH |
0 |
|
Datasheet |
- | Module, SMA Connectors | Bulk | Active | ATE | Absorptive | SP4T | 0Hz ~ 18GHz | 80dB | 0.5dB | 18GHz | - | - | - | 50Ohm | 24V | -15°C ~ 45°C | - | - | Chassis Mount | - |
|
HMC194AMS8ETRIC RF SWITCH SPDT 3GHZ 8MSOP |
0 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | Tape & Reel (TR) | Active | General Purpose | - | SPDT | 0Hz ~ 3GHz | 38dB | 0.5dB | 2.5GHz | 29dBm | 53dBm | - | 50Ohm | 3V ~ 7V | -40°C ~ 85°C | - | - | Surface Mount | 8-MSOP |
|
SKY12209-478LFIC RF SWITCH SPDT 4GHZ 16QFN |
0 |
|
Datasheet |
- | 16-LQFN Exposed Pad | Tape & Reel (TR) | Active | LTE, WiMax | - | SPDT | 900MHz ~ 4GHz | 36dB | 0.7dB | 3.5GHz | - | 76dBm | - | 50Ohm | 28V | -55°C ~ 175°C | - | - | Surface Mount | 16-QFN (4x4) |
|
|
TS7224FKIC RF SWITCH SPDT 6GHZ 16QFN |
10 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Active | Cellular, LTE | Reflective | SPDT | 30MHz ~ 6GHz | 45dB | 0.35dB | 800MHz | 42dBm | 73dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
|
|
TS7242FKIC RF SWITCH SP4T 3GHZ 16QFN |
3 |
|
Datasheet |
Symmetric | 16-VFQFN Exposed Pad | Strip | Not For New Designs | Cellular, LTE | Reflective | SP4T | 10MHz ~ 3GHz | 40dB | 0.45dB | 800MHz | 42dBm | 70dBm | - | 50Ohm | 2.6V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-QFN (3x3) |
