RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R574413625IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574413685IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574F22320IC RF SWITCH SP3T 26.5GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
FMWGS6064WG EM RELAY SWITCH WR-90 12.4 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT, DPDT | 8.2GHz ~ 12.4GHz | 85dB | 0.05dB | - | - | - | - | 50Ohm | 10.8V ~ 13.2V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6065WG EM RELAY SWITCH WR-90 12.4 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT, DPDT | 8.2GHz ~ 12.4GHz | 85dB | 0.05dB | - | - | - | - | 50Ohm | 25.2V ~ 30.8V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
R574G23605IC RF SWITCH SP6T 18GHZ |
0 |
|
- |
RAMSES | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | DC ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R577J32105IC RF SWITCH DPDT 50GHZ |
0 |
|
Datasheet |
DPDT | Module | Bulk | Active | General Purpose | - | DPDT | 0Hz ~ 50GHz | 50dB (min) | 1.1dB (max) | 50GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -25°C ~ 70°C | - | - | - | - |
|
R573882600IC RF SWITCH SP6T 40GHZ |
0 |
|
- |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6227PIN DIODE SWITCH 2.92MM SP3T 40G |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SP3T | 500MHz ~ 40GHz | 55dB (min) | 5.5dB | 40GHz | - | - | - | 50Ohm | -5V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6444EM RELAY SWITCH 40 GHZ 12 V 2.92 |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | - | SPDT | 0Hz ~ 40GHz | 85dB | 0.40dB | 40GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
|
R574102405IC RF SWITCH SP4T 12.4GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW2011PIN DIODE SWITCH 2.92MM SPST 40G |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SPST | 50MHz ~ 40GHz | 25dB (min) | 6.5dB | 40GHz | - | - | - | 50Ohm | -5V, 5V | -30°C ~ 60°C | - | - | Chassis Mount | - |
|
R573823620IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574122340IC RF SWITCH SP3T 12.4GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 12.4GHz | 60dB (min) | 0.5dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573882420IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574F03615IC RF SWITCH SP6T 26.5GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574803400IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574802400IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
FMWGS6028WG EM RELAY SWITCH WR-187 5.85 G |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Reflective | SPDT, DPDT | 3.95GHz ~ 5.85GHz | 80dB (min) | 0.02dB (max) | - | - | - | - | - | 21V ~ 32V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6032WG EM RELAY SWITCH WR-159 7.05 G |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Reflective | SPDT, DPDT | 4.9GHz ~ 7.05GHz | 70dB (min) | 0.02dB (max) | - | - | - | - | - | 21V ~ 32V | -40°C ~ 85°C | - | - | Chassis Mount | - |
RF Switches Electronic Components
Explore RF Switches electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
