RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R573493585IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573493525IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
FMSW6423EM RELAY SWITCH 26.5 GHZ 12 V SM |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | - | SP4T | 0Hz ~ 26.5GHz | 80dB | 0.40dB | 26.5GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
R573933600IC RF SWITCH SP6T 2.5GHZ |
0 |
|
- |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 2.5GHz | 70dB (min) | 0.3dB (max) | 2.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW6354EM RELAY SWITCH 18 GHZ 12 V SMA |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SPDT | 0Hz ~ 18GHz | 85dB | 0.15dB | 18GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
|
FMSW6296EM RELAY SWITCH 22 GHZ 28 V SMA |
0 |
|
Datasheet |
- | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R574F03610IC RF SWITCH SP6T 26.5GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574F03600IC RF SWITCH SP6T 26.5GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6176EM RELAY SWITCH 12.4 GHZ 12 V TY |
0 |
|
Datasheet |
- | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
R573403800IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R573403810IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573933420IC RF SWITCH SP4T 2.5GHZ |
0 |
|
- |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 2.5GHz | 70dB (min) | 0.3dB (max) | 2.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW6434EM RELAY SWITCH 12 GHZ 12 V TYPE |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | - | SP4T | 0Hz ~ 12GHz | 90dB | 0.3dB | 12GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
R573833600IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMWGS6061WG EM RELAY SWITCH WR-90 12.4 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT, DPDT | 8.2GHz ~ 12.4GHz | 85dB | 0.05dB | - | - | - | - | 50Ohm | 25.2V ~ 30.8V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6060WG EM RELAY SWITCH WR-90 12.4 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT, DPDT | 8.2GHz ~ 12.4GHz | 85dB | 0.05dB | - | - | - | - | 50Ohm | 10.8V ~ 13.2V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
R583F33121IC RF SWITCH SP6T 22GHZ |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 22GHz | 50dB (min) | 0.7dB (max) | 22GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R595863415IC RF SWITCH DP3T 40GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | DP3T | 0Hz ~ 40GHz | 55dB (min) | 0.2dB (max) | 40GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
R595867315IC RF SWITCH 40GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | - | 0Hz ~ 40GHz | 55dB (min) | 0.2dB (max) | 40GHz | - | - | - | 50Ohm | 12V ~ 20V | -25°C ~ 75°C | - | - | - | - |
|
|
R574352620IC RF SWITCH SP6T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
