BOM Upload
RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FMSW6210PIN DIODE SWITCH SMA SPDT 18GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SPDT | 500MHz ~ 18GHz | 55dB (min) | 3.75dB | 18GHz | - | - | - | 50Ohm | -15V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R595357415IC RF SWITCH DP3T 6GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | DP3T | 0Hz ~ 6GHz | 85dB (min) | 0.2dB (max) | 6GHz | - | - | - | 50Ohm | 12V ~ 20V | -25°C ~ 75°C | - | - | - | - |
|
R595357315IC RF SWITCH 6GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | - | 0Hz ~ 6GHz | 85dB (min) | 0.2dB (max) | 6GHz | - | - | - | 50Ohm | 12V ~ 20V | -25°C ~ 75°C | - | - | - | - |
|
|
FMSW6427EM RELAY SWITCH 26.5 GHZ 12 V SM |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 80dB | 0.40dB | 26.5GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
|
R574402320IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574403320IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574313415IC RF SWITCH SP4T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP4T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574313405IC RF SWITCH SP4T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP4T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574393300IC RF SWITCH SP3T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574392300IC RF SWITCH SP3T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574423400IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Obsolete | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6154EM RELAY SWITCH 12.4 GHZ 12 V TY |
0 |
|
Datasheet |
- | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R573413615IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6126EM RELAY SWITCH 22 GHZ 12 V SMA |
0 |
|
Datasheet |
- | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
R573502610IC RF SWITCH SP6T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R585863610IC RF SWITCH 40GHZ MODULE |
0 |
|
Datasheet |
BYPASS | Module | Bulk | Active | General Purpose | - | - | 0Hz ~ 40GHz | 50dB (min) | 0.8dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573422445IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574402500IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Obsolete | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574403510IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574403500IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
RF Switches Electronic Components
Explore RF Switches electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
