RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R574403440IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574422305IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
- | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574423305IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R591302625IC RF SWITCH SP6T 6GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 6GHz | 70dB (min) | 0.3dB (max) | 6GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R591303625IC RF SWITCH SP6T 6GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 6GHz | 70dB (min) | 0.3dB (max) | 6GHz | - | - | - | 50Ohm | 21V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
|
PE71S6220SPST PIN Diode Switch Operating |
1 |
|
Datasheet |
- | - | Retail Package | Active | General Purpose | Reflective | SPST | 500MHz ~ 18GHz | 55dB (min) | 3dB | - | - | - | - | 50Ohm | -15V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6370EM RELAY SWITCH 26.5 GHZ 12 V SM |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SP4T | 0Hz ~ 26.5GHz | 80dB | 0.15dB | 26.5GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 70°C | - | - | Chassis Mount | - |
|
R591703640IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 21V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R591702640IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R591703630IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 21V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
|
R573F13325IC RF SWITCH SP3T 26.5GHZ |
0 |
|
Datasheet |
RAMSES | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6478EM RELAY SWITCH 40 GHZ 28 V 2.92 |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SPDT | 0Hz ~ 40GHz | 80dB | 0.40dB | 40GHz | - | - | - | 50Ohm | 28V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
R573423405IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573423415IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574303325IC RF SWITCH SP3T 3GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574302325IC RF SWITCH SP3T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574302385IC RF SWITCH SP3T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6556EM RELAY SWITCH 18 GHZ 28 V SMA |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | - | 0Hz ~ 18GHz | 90dB | 0.2dB | 18GHz | - | - | - | 50Ohm | 26V ~ 30V | -54°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6555EM RELAY SWITCH 18 GHZ 28 V SMA |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | - | 0Hz ~ 18GHz | 90dB | 0.2dB | 18GHz | - | - | - | 50Ohm | 26V ~ 30V | -54°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6537EM RELAY SWITCH 18 GHZ 28 V SMA |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SP2T | 0Hz ~ 18GHz | 85dB | 0.2dB | 18GHz | - | - | - | 50Ohm | 26V ~ 30V | -54°C ~ 85°C | - | - | Chassis Mount | - |
