RF Antennas
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TWX-721XRS3BANT WIFI 6E BLADE RP-SMA FEMALE |
993 |
|
Datasheet |
721 | Bag | Active | WiFi | Wide Band | 2.45GHz, 5.5GHz, 6.525GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz | Blade, Tilt | 3 | 1.4, 1.9, 1.6 | -15.6dB, -10dB, -12.7dB | 2.4dBi, 3.8dBi, 5dBi | 1 W | - | RP-SMA Female | - | - | - | Connector Mount | 5.906" (150.00mm) | 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E |
|
|
TWX-100BRS3BANT WIFI 6E WHIP RP-SMA FEMALE |
953 |
|
Datasheet |
100 | Bag | Active | WiFi | Wide Band | 2.45GHz, 5.5GHz, 6.525GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz | Whip, Tilt | 3 | 1.5, 1.6, 3 | -14dB, -12.7dB, -6dB | 2.6dBi, 4.3dBi, 4.4dBi | 1 W | - | RP-SMA Female | - | - | - | Connector Mount | 4.870" (123.70mm) | 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E |
|
|
YWX-100BSA2BANT 4G WHIP SMA PLUG MALE |
601 |
|
Datasheet |
100 | Bag | Active | Cellular | Wide Band | 788.5MHz, 1.94GHz, 2.5GHz | 617MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.17GHz ~ 2.69GHz | Whip, Tilt | 3 | 2.4, 2.2, 2.7 | -7.7dB, -8.5dB, -6.8dB | 0dBi, -0.1dBi, 0dBi | 1 W | - | SMA Male | - | - | - | Connector Mount | 4.870" (123.70mm) | 2G, 3G, 4G, LTE |
|
|
GWX-100BSA3BANT LPWA WHIP SMA PLUG MALE |
478 |
|
Datasheet |
100 | Bag | Active | General ISM | UHF (300MHz ~ 1GHz) | 868MHz, 915MHz | 862MHz ~ 876MHz, 902MHz ~ 930MHz | Whip, Tilt | 2 | 1.8, 1.9 | -10.9dB, -10.2dB | 2.3dBi, 2.2dBi | 1 W | - | SMA Male | - | - | - | Connector Mount | 4.870" (123.70mm) | ISM, LoRaWAN, LPWA, SigFox |
|
|
TQ0137AA0000RF ANT 1571MHZ CERAMIC PATCH PIN |
200 |
|
- |
- | Box | Active | - | - | 1.571GHz | - | Ceramic Patch | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
TQ0129AA0000RF ANT 1579MHZ CERAMIC PATCH PIN |
200 |
|
- |
- | Box | Active | - | - | 1.579GHz | - | Ceramic Patch | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
JCG402LR-1868MHZ WHIP ANTENNA WITH FLEXIBL |
412 |
|
Datasheet |
- | Bag | Active | - | UHF (300MHz ~ 1GHz) | 868MHz | 863MHz ~ 873MHz | Whip, Tilt | 1 | 2 | - | 2dBic | - | - | SMA Male | - | - | - | Connector Mount | 4.331" (110.00mm) | - |
|
|
TQ0157AA0000RF ANT 1575MHZ CERAMIC PATCH SMD |
200 |
|
- |
- | Tape & Reel (TR) | Active | - | - | 1.575GHz | - | Ceramic Patch | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
TWX-144XRS3BANT WIFI 7/6E WHIP RP-SMA FEMALE |
1,000 |
|
Datasheet |
144 | Bag | Active | WiFi | Wide Band | 2.45GHz, 5.5GHz, 6.525GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz | Whip, Tilt | 3 | 1.3, 1.6, 2.1 | -17.7dB, -12.7dB, -9dB | 2.5dBi, 4.5dBi, 4.4dBi | 1 W | - | RP-SMA Female | - | - | - | Connector Mount | 5.433" (138.00mm) | 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E |
|
|
TWX-144XSA3BANT WIFI 7/6E WHIP SMA MALE |
976 |
|
Datasheet |
144 | Bag | Active | WiFi | Wide Band | 2.45GHz, 5.5GHz, 6.525GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz | Whip, Tilt | 3 | 1.3, 1.6, 2.1 | -17.7dB, -12.7dB, -9dB | 2.5dBi, 4.5dBi, 4.4dBi | 1 W | - | SMA Male | - | - | - | Connector Mount | 5.433" (138.00mm) | 802.11ax, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E |
|
|
2118016-2PCB ANTENNAS, WLAN DUAL BAND T&R |
9,871 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Bluetooth, WiFi | SHF (f > 4GHz) | 2.441GHz, 5.512GHz | 2.4GHz ~ 2.4835GHz, 5.15GHz ~ 5.875GHz | PCB Trace | 2 | 3 | - | 3dBi | - | - | - | - | - | - | Surface Mount | 0.031" (0.79mm) | 802.11a/b/g/n, Bluetooth, Wi-Fi, ZigBee™ |
|
|
PE51RD10052.4-2.5 GHz and 5.1- 5.8 GHz Dua |
179 |
|
Datasheet |
- | Retail Package | Active | WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.44GHz, 5.5GHz | 2.4GHz ~ 2.483GHz, 5.1GHz ~ 5.9GHz | Whip, Tilt | 2 | 2 | - | 5dBi, 5dBi | - | - | RP-SMA | - | - | - | Connector Mount | 7.700" (195.58mm) | 802.11a/b/g/n/ac |
|
ACAR3705-SBRF ANT LPWA SUBGHZ CHIP SMD |
1,302 |
|
Datasheet |
ACAR | Tape & Reel (TR) | Active | Cellular, General ISM | UHF (300MHz ~ 1GHz) | 698MHz, 800MHz, 850MHz, 868MHz, 900MHz, 960MHz | 698MHz ~ 960MHz | Chip | 1 | 4.5 | - | 0.61dBi | - | - | Solder | - | - | - | Surface Mount | 0.197" (5.00mm) | 2G, 3G, 4G, GSM, ISM, LoRa, LPWAN, LTE, Sigfox |
|
|
2JE71BRICK 5GNR/4GLTE/3G/2G HIGH-PERF |
685 |
|
Datasheet |
- | Cut Tape (CT) | Active | Cellular | Wide Band | 788.5MHz, 2.059GHz, 4.15GHz, 5.538GHz | 617MHz ~ 960MHz, 1.427GHz ~ 2.69GHz, 3.3GHz ~ 5GHz, 5.15GHz ~ 5.925GHz | Chip | 4 | 2, 3.1, 3.5 | -10.3dB, -10.2dB, -6.7dB, -5.7dB | 0.5dBi, 2.7dBi, 3.1dBi, 2.2dBi | 25 W | - | Solder | - | - | - | Surface Mount | 0.118" (3.00mm) | 2G, 3G, 4G, 5G, LTE |
|
2128601011WI-FI/BLUETOOTH HINGED EXT ANTEN |
7,524 |
|
Datasheet |
212860 | Bag | Obsolete | 802.15.4, Bluetooth, WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.45GHz, 5.5GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz | Whip, Tilt | 2 | - | -10dB | 5.3dBi, 4.5dBi | - | - | RP-SMA Male | - | - | - | Connector Mount | 4.268" (108.40mm) | Bluetooth, Wi-Fi, Zigbee™ |
|
2135230001LTE ANTENNA_HINGED_B_M |
869 |
|
Datasheet |
213523 | Bag | Obsolete | Cellular | UHF (300MHz ~ 1GHz), UHF (2GHz ~ 3GHz) | 829MHz, 2.2GHz | 698MHz ~ 960MHz, 1.71GHz ~ 2.69GHz | Blade, Tilt | 2 | - | -10dB, -5dB | 2.3dBi, 4.8dBi | - | - | SMA Male | - | - | - | Connector Mount | 6.752" (171.50mm) | LTE |
|
2195729-1EXTERNAL FULL BAND ANTENNA |
11 |
|
Datasheet |
- | Bulk | Obsolete | Cellular, Navigation | Wide Band | 875MHz, 1.515GHz, 2.205GHz, 3.55GHz, 4.7GHz, 5.5375GHz | 790MHz ~ 960MHz, 1.42GHz ~ 1.61GHz, 1.71GHz ~ 2.7GHz, 3.3GHz ~ 3.8GHz, 4.4GHz ~ 5GHz, 5.15GHz ~ 5.925GHz | Blade, Tilt | 6 | 3 | - | 3dBi, 0.98dBi, 0dBi, 1dBi, 1.5dBi, 2.4dBi | - | - | SMA Male | - | - | - | Connector Mount | 5.350" (135.89mm) | Galileo, GLONASS, GNSS, GPS, LTE, UMTS, WCDMA |
|
SGP.1575.18.4.C.02RF ANT 1.575GHZ CER PATCH SLD |
0 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz | 1.573GHz ~ 1.577GHz | Ceramic Patch | 1 | 1.5 | - | 1dBic | - | - | Solder | - | - | - | Surface Mount | 0.177" (4.50mm) | GPS |
|
AEACAC049009-S2400ANTENNA LOW PROFILE 2.4GHZ WHIP |
964 |
|
Datasheet |
AEAC | Bulk | Active | 802.15.4, Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.44GHz | 2.4GHz ~ 2.4835GHz | Whip, Straight | 1 | 2 | - | 2dBi | - | Cable - 100mm | I-PEX | - | - | - | Connector Mount | 1.941" (49.30mm) | Bluetooth, ISM, Wi-Fi, Zigbee™ |
|
|
2128601001WI-FI/BLUETOOTH HINGED EXT ANTEN |
4,663 |
|
Datasheet |
212860 | Bag | Obsolete | 802.15.4, Bluetooth, WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.45GHz, 5.5GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.85GHz | Whip, Tilt | 2 | - | -10dB | 5.3dBi, 4.5dBi | - | - | SMA Male | - | - | - | Connector Mount | 4.268" (108.40mm) | Bluetooth, Wi-Fi, Zigbee™ |
RF Antennas Electronic Components
Explore RF Antennas electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
