Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MBN15SS1W01-CABUSHING MOUNT MINIATURE PUSHBUTT |
0 |
|
Datasheet |
MB2000 | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Round, Button | - | Black | - | - | Solder Lug | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
|
MBN25SS4W01BUSHING MOUNT MINIATURE PUSHBUTT |
3 |
|
Datasheet |
MB2000 | Bulk | Active | Panel Mount, Rear | Standard | DPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Plunger for Cap | - | - | - | - | Solder Lug | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
|
MBN15SS1W03-CABUSHING MOUNT MINIATURE PUSHBUTT |
0 |
|
Datasheet |
MB2000 | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-Mom | 3A (AC), 2A (DC) | 125 V | 30 V | Round, Button | - | Black | - | - | PC Pin | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
|
AV12F10E624Q04AV12 SPM 0.1A/24VDC GREEN LED 24 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E724Q04AV12 SPM 0.1A/24VDC BLUE LED 24V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E112Q04AV12 SPM 0.1A/24VDC WHITE LED 12 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E524Q04AV12 SPM 0.1A/24VDC YELLOW LED 2 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E712Q04AV12 SPM 0.1A/24VDC BLUE LED12V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E124Q04AV12 SPM 0.1A/24VDC WHITE LED 24 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | - | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E512Q04AV12 SPM 0.1A/24VDC YELLOW LED 1 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E312Q04AV12 SPM 0.1A/24VDC RED LED 12V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E324Q04AV12 SPM 0.1A/24VDC RED LED 24V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10E612Q04AV12 SPM 0.1A/24VDC GREEN LED 12 |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
MBNR15E1G01-FASNAP-ACTION BUSHING MOUNT PUSHBU |
5 |
|
- |
MB2400 | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | - | Black | - | - | Solder Lug | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
|
MBNR15S1G01-HASNAP-ACTION BUSHING MOUNT PUSHBU |
5 |
|
- |
MB2400 | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | - | Black | - | - | Solder Lug | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
|
AV12F10EA12Q04AV12 SPM 0.1A/24VDC R&G LED 12V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 14 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
AV12F10EA24Q04AV12 SPM 0.1A/24VDC R&G LED 24V |
0 |
|
- |
* | Tray | Active | - | - | - | Off-On | 1A (AC) | - | - | Round, Button | - | Natural | - | 24 VAC | - | IP67 - Dust Tight, Waterproof | - | - | -20°C ~ 55°C |
|
|
MBNR15E1G01-HASNAP-ACTION BUSHING MOUNT PUSHBU |
5 |
|
- |
MB2400 | Bulk | Active | Panel Mount, Rear | Standard | SPDT | On-Mom | 0.4VA (AC/DC) | 28 V | 28 V | Round, Button | - | Black | - | - | Solder Lug | - | - | Circular - 6.50mm Dia | -30°C ~ 85°C |
|
UB16SKW035FSWITCH PUSHBUTTON SPDT 5A 125V |
4 |
|
Datasheet |
UB | Bulk | Active | Through Hole | Standard, Illuminated | SPDT | On-On | 5A (AC/DC) | 125 V | 30 V | Plunger for Cap | No Marking | - | LED, Green | 2.1 VDC | PC Pin | - | Process Sealed | - | -25°C ~ 50°C |
|
A22NN-BNM-NAA-G100-NNSWITCH PUSH SPST-NO 10A 120V |
0 |
|
Datasheet |
A22NN | Bulk | Active | Panel Mount, Front | Standard | SPST-NO | Off-Mom | 10A (AC/DC) | 120 V | 24 V | Round, Button, Flush | No Marking | Blue | - | - | Screw Terminal | IP66 - Dust Tight, Water Resistant | - | Circular - 22.30mm Dia | -25°C ~ 70°C |
