Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MJG--MN-5121--T2SPDT Enclosed Basic Switch |
4,000 |
|
- |
MN | Bulk | Active | SPDT | On-Mom | 10A (AC), 0.5A (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | Actuator Seal Boot | 180gf | 50gf | - | 0.433" (11.0mm) | 0.094" (2.4mm) | 0.118" (3.0mm) | -10°C ~ 80°C |
|
|
MJG--MN-5141--T2SPDT Enclosed Basic Switch |
4,000 |
|
- |
MN | Bulk | Active | SPDT | On-Mom | 10A (AC), 0.5A (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | Actuator Seal Boot | 240gf | 80gf | - | 0.256" (6.5mm) | 0.060" (1.5mm) | 0.079" (2.0mm) | -10°C ~ 80°C |
|
|
MJG--MJ2-1534 PH-20--T2SPDT Snap-Act Basic Switch |
16,500 |
|
- |
MJ2 | Bulk | Active | SPDT | On-Mom | 20A (AC), 0.5A (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | Oil Resist Boot Seal | 110gf | 25gf | - | 0.252" (6.4mm) | 0.062" (1.6mm) | 0.157" (4.0mm) | -25°C ~ 80°C |
|
|
MJG--MJ2-1533 PH-20--T2SPDT Snap-Act Basic Switch |
16,500 |
|
- |
MJ2 | Bulk | Active | SPDT | On-Mom | 20A (AC), 0.5A (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | Oil Resist Boot Seal | 170gf | 42gf | - | 0.106" (2.7mm) | 0.020" (0.51mm) | 0.094" (2.4mm) | -25°C ~ 80°C |
|
MJ3-512109SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Lever, Roller | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | 166gf | 128gf | - | 0.138" (3.5mm) | 0.016" (0.4mm) | 0.178" (4.5mm) | -25°C ~ 80°C |
|
MJ3-522134SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Lever, Roller | Chassis Mount | Quick Connect - 0.250" (6.3mm) | IP65 - Dust Tight, Water Resistant | One Way Action Roller | 166gf | 128gf | - | 0.138" (3.5mm) | 0.016" (0.4mm) | 0.178" (4.5mm) | -25°C ~ 80°C |
|
MJ3-512110SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Lever, Roller | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | 109gf | 84gf | - | 0.209" (5.3mm) | 0.025" (0.6mm) | 0.224" (5.7mm) | -25°C ~ 80°C |
|
MJ3-512102SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | 400gf | 300gf | - | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.079" (2.0mm) | -25°C ~ 80°C |
|
MJ3-512111SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Lever, Roller | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | 76gf | 58gf | - | 0.303" (7.7mm) | 0.035" (0.9mm) | 0.350" (8.9mm) | -25°C ~ 80°C |
|
MJ3-521104SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Round (Pin Plunger) | Chassis Mount | Quick Connect - 0.250" (6.3mm) | IP40 | - | 400gf | 300gf | - | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.079" (2.0mm) | -25°C ~ 80°C |
|
MJ3-512103SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | 400gf | 300gf | - | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.079" (2.0mm) | -25°C ~ 80°C |
|
MJ3-522113SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Round (Pin Plunger) | Chassis Mount | Quick Connect - 0.250" (6.3mm) | IP65 - Dust Tight, Water Resistant | - | 400gf | 300gf | - | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.079" (2.0mm) | -25°C ~ 80°C |
|
MJ3-522125SWITCH SNAP ACTION SPDT 5A 250V |
700 |
|
Datasheet |
MJ3 | Bulk | Active | SPDT | On-Mom | 5A (AC), 400mA | 250 V | 250 V | Lever, Adjustable Plunger | Chassis Mount | Quick Connect - 0.250" (6.3mm) | IP65 - Dust Tight, Water Resistant | - | 76gf | 58gf | - | 0.303" (7.7mm) | 0.035" (0.9mm) | 0.327" (8.3mm) | -25°C ~ 80°C |
|
MJ2-1306 PH-20SWITCH SNAP ACTION SPDT 20A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 20A (AC), 500mA (DC) | 250 V | 125 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP40 | - | 450gf | 114gf | - | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.063" (1.6mm) | -25°C ~ 80°C |
|
MJ2-1500 PHSWITCH SNAP ACTION SPDT 15A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 250 V | 125 V | Lever, Straight | Chassis Mount | Screw Terminal | IP40 | - | 10gf | 5.000gf | - | 0.394" (10.0mm) | 0.118" (3.0mm) | 0.158" (4.0mm) | -25°C ~ 80°C |
|
MJ2-1703 PH-20SWITCH SNAP ACTION SPDT 20A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 20A (AC), 500mA (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | - | 100gf | 21gf | - | 0.280" (7.1mm) | 0.062" (1.6mm) | 0.158" (4.0mm) | -25°C ~ 80°C |
|
MJ2-1708 PH-20SWITCH SNAP ACTION SPDT 20A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 20A (AC), 500mA (DC) | 250 V | 125 V | - | Chassis Mount | Screw Terminal | IP40 | - | 180gf | 40gf | - | 0.236" (6.0mm) | 0.060" (1.5mm) | 0.055" (1.4mm) | -25°C ~ 80°C |
|
MJ2-1504 PHSWITCH SNAP ACTION SPDT 15A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | - | 110gf | 25gf | - | 0.252" (6.4mm) | 0.062" (1.6mm) | 0.158" (4.0mm) | -25°C ~ 80°C |
|
|
MJ2-1500SWITCH SNAP ACTION SPDT 15A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 250 V | 125 V | Lever, Straight | Chassis Mount | Screw Terminal | IP40 | - | 10gf | 5.000gf | - | 0.394" (10.0mm) | 0.118" (3.0mm) | 0.158" (4.0mm) | -25°C ~ 80°C |
|
MJ2-1704 PH-20SWITCH SNAP ACTION SPDT 20A 250V |
4,000 |
|
Datasheet |
MJ2 | Retail Package | Active | SPDT | On-Mom | 20A (AC), 500mA (DC) | 250 V | 125 V | Lever, Roller | Chassis Mount | Screw Terminal | IP40 | - | 160gf | 42gf | - | 0.138" (3.5mm) | 0.020" (0.5mm) | 0.094" (2.4mm) | -25°C ~ 80°C |
