Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCB-1-RFUSE BRD MT 1A 250VAC 450VDC RAD |
8,215 |
|
Datasheet |
PC-Tron® | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 1 A | 250 V | 450 V | Fast Blow | 50A AC, 5.9kA DC | 0.02 | CSA, UL | - | - | 0.350" L x 0.184" W x 0.345" H (8.89mm x 4.67mm x 8.76mm) | |
|
PCC-1-RFUSE BRD MT 1A 250VAC 450VDC RAD |
9,422 |
|
Datasheet |
PC-Tron® | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 1 A | 250 V | 450 V | Fast Blow | 50A AC, 5.9kA DC | 0.02 | CSA, UL | - | - | 0.350" L x 0.184" W x 0.345" H (8.89mm x 4.67mm x 8.76mm) | |
|
|
PCD-5-RFUSE BRD MT 5A 125VAC 400VDC RAD |
4,467 |
|
Datasheet |
PC-Tron® | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 5 A | 125 V | 400 V | Fast Blow | 10kA AC, 4.2kA DC | 5.0 | CSA, UL | - | - | 0.350" L x 0.184" W x 0.345" H (8.89mm x 4.67mm x 8.76mm) | |
|
0217.160VXPFUSE GLASS 160MA 250VAC 5X20MM |
8,070 |
|
Datasheet |
217 | Bulk | Active | Requires Holder | Cartridge, Glass | 160 mA | 250 V | - | Fast Blow | 35A | 0.01 | CCC, CE, CSA,KC, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0217.200VXPFUSE GLASS 200MA 250VAC 5X20MM |
8,950 |
|
Datasheet |
217 | Bulk | Active | Requires Holder | Cartridge, Glass | 200 mA | 250 V | - | Fast Blow | 35A | 0.02 | CCC, CE, CSA,KC, SEMKO, UL, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
0253.250VXLFUSE BRD MT 250MA 125VAC/VDC AXL |
2,539 |
|
Datasheet |
PICO® II 253 | Bulk | Obsolete | Through Hole | Board Mount (Cartridge Style Excluded) | 250 mA | 125 V | 125 V | Fast Blow | 50A AC, 300A DC | 0.0116 | CSA, QPL, UR | -55°C ~ 125°C | - | 0.103" Dia x 0.280" L (2.61mm x 7.11mm) | |
|
0473004.VXLFUSE BRD MNT 4A 125VAC/VDC AXIAL |
7,847 |
|
Datasheet |
PICO® II 473 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 4 A | 125 V | 125 V | Slow Blow | 50A | 35.0 | CSA, PSE, UR | -55°C ~ 125°C | - | 0.135" Dia x 0.280" L (3.43mm x 7.11mm) | |
|
|
0473003.VXLFUSE BRD MNT 3A 125VAC/VDC AXIAL |
5,619 |
|
Datasheet |
PICO® II 473 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 3 A | 125 V | 125 V | Slow Blow | 50A | 21.0 | CSA, PSE, UR | -55°C ~ 125°C | - | 0.135" Dia x 0.280" L (3.43mm x 7.11mm) | |
|
0326.100VXPFUSE CERM 100MA 250VAC 3AB 3AG |
2,553 |
|
Datasheet |
326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 100 mA | 250 V | - | Slow Blow | 100A | 0.087 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
|
0326.125VXPFUSE CERM 125MA 250VAC 3AB 3AG |
9,910 |
|
Datasheet |
326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 125 mA | 250 V | - | Slow Blow | 100A | 0.1 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
|
0326.150VXPFUSE CERM 150MA 250VAC 3AB 3AG |
7,892 |
|
Datasheet |
326 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 150 mA | 250 V | - | Slow Blow | 100A | 0.143 | CE | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
AMXL-150FUSE AUTO 150A 125VDC AUTO LINK |
7,728 |
|
Datasheet |
AMXL | Box | Active | Bolt Mount | Automotive | 150 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
FLG-50FUSE AUTOMOTIVE 50A AUTO LINK |
4,967 |
|
Datasheet |
FLG | Bulk | Active | Requires Holder | Automotive | 50 A | - | - | - | - | - | - | - | Red | - | |
|
|
FLG-60FUSE AUTOMOTIVE 60A AUTO LINK |
7,649 |
|
Datasheet |
FLG | Bulk | Active | Requires Holder | Automotive | 60 A | - | - | - | - | - | - | - | Yellow | - | |
|
|
FLG-80FUSE AUTOMOTIVE 80A AUTO LINK |
5,346 |
|
Datasheet |
FLG | Bulk | Active | Requires Holder | Automotive | 80 A | - | - | - | - | - | - | - | - | - | |
|
|
AGU-40BUSS MIDGET FUSE FAST ACTING |
9,784 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
AMXL-80FUSE AUTO 80A 125VDC AUTO LINK |
6,880 |
|
Datasheet |
AMXL | Box | Active | Bolt Mount | Automotive | 80 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
AMXL-100FUSE AUTO 100A 125VDC AUTO LINK |
3,049 |
|
Datasheet |
AMXL | Box | Active | Bolt Mount | Automotive | 100 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
BK/FLS-30FUSE AUTOMOTIVE 30A AUTO LINK |
8,608 |
|
Datasheet |
FLS | Bulk | Active | Requires Holder | Automotive | 30 A | - | - | - | - | - | - | - | Pink | - | |
|
|
BK/FLS-40FUSE AUTOMOTIVE 40A AUTO LINK |
7,891 |
|
- |
FLS | Bulk | Active | Requires Holder | Automotive | 40 A | - | - | - | - | - | - | - | Green | - |
Fuses Electronic Components
Explore Fuses electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
