Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0277.375MFUSE BRD MT 375MA 125VAC/VDC AXL |
9,419 |
|
Datasheet |
PICO® 277 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 375 mA | 125 V | 125 V | - | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
0253010.MFUSE BOARD MOUNT 10A 125VAC/VDC |
6,852 |
|
Datasheet |
PICO® II 253 | Bulk | Discontinued at Digi-Key | Through Hole | Board Mount (Cartridge Style Excluded) | 10 A | 32 V | 32 V | Fast Blow | 50A AC, 300A DC | 25.5 | CSA, QPL, TUV, UR | -55°C ~ 125°C | - | 0.103" Dia x 0.280" L (2.61mm x 7.11mm) | |
|
0277.250NRT1FUSE BRD MT 250MA 125VAC/VDC AXL |
4,004 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 250 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
|
0277.375NRT1FUSE BRD MT 375MA 125VAC/VDC AXL |
5,464 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 375 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.280" L (2.36mm x 7.11mm) | |
|
3298125.HFUSE BRD MT 125A 32VDC MOD 100PC |
5,309 |
|
Datasheet |
ZCASE® SMZ | Box | Active | Bolt Mount | Board Mount (Cartridge Style Excluded) | 125 A | - | 32 V | - | 2kA | 45000.0 | - | -40°C ~ 125°C | - | - | |
|
|
3298225.HFUSE BRD MT 225A 32VDC MOD 100PC |
8,154 |
|
Datasheet |
ZCASE® SMZ | Box | Active | Bolt Mount | Board Mount (Cartridge Style Excluded) | 225 A | - | 32 V | - | 2kA | 95000.0 | - | -40°C ~ 125°C | - | - | |
|
S520-16-RFUSE CERAMIC 16A 420VAC 5X20MM |
6,842 |
|
Datasheet |
S520 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 16 A | 420 V | - | Fast Blow | 1.5kA | 280.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
S520-15-RFUSE CERAMIC 15A 420VAC 5X20MM |
7,747 |
|
Datasheet |
S520 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 15 A | 420 V | - | Fast Blow | 1.5kA | 220.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
S520-10-RFUSE CERAMIC 10A 420VAC 5X20MM |
8,213 |
|
Datasheet |
S520 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 10 A | 420 V | - | Fast Blow | 1.5kA | 155.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
S520-12-5-RFUSE CERAMIC 12.5A 420VAC 5X20MM |
7,822 |
|
Datasheet |
S520 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 12.5 A | 420 V | - | Fast Blow | 1.5kA | 160.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
S520-20-RFUSE CERAMIC 20A 420VAC 5X20MM |
4,472 |
|
Datasheet |
S520 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 20 A | 420 V | - | Fast Blow | 1.5kA | 420.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
BK/MDQ-9FUSE GLASS 9A 32VAC 3AB 3AG |
4,894 |
|
Datasheet |
MDQ | Bulk | Active | Requires Holder | Cartridge, Glass | 9 A | 32 V | - | Slow Blow | 1kA | - | CSA, UL | - | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
|
0277.062NRT1FUSE BRD MNT 62MA 125VAC/VDC AXL |
9,054 |
|
- |
PICO® 277 | Tape & Reel (TR) | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 62 mA | 125 V | 125 V | Fast Blow | - | - | - | - | - | 0.093" Dia x 0.281" L (2.36mm x 7.14mm) | |
|
|
7940119314FUSE 5X20MM 2A 250V FST GL |
4,590 |
|
Datasheet |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
AMX-150FUSE AUTO 150A 125VDC AUTO LINK |
9,789 |
|
Datasheet |
AMX | Box | Active | Bolt Mount | Automotive | 150 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
AMX-250FUSE AUTO 250A 125VDC AUTO LINK |
9,174 |
|
Datasheet |
AMX | Box | Active | Bolt Mount | Automotive | 250 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
AMX-80FUSE AUTO 80A 125VDC AUTO LINK |
6,506 |
|
Datasheet |
AMX | Box | Active | Bolt Mount | Automotive | 80 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
AMX-300FUSE AUTO 300A 125VDC AUTO LINK |
3,006 |
|
Datasheet |
AMX | Box | Active | Bolt Mount | Automotive | 300 A | - | 125 V | - | 3kA | - | cURus, UL | -40°C ~ 105°C | - | 0.630" L x 0.472" W x 0.335" H (16.00mm x 12.00mm x 8.50mm) | |
|
|
0313.062VXPFUSE GLASS 62MA 250VAC 3AB 3AG |
9,514 |
|
Datasheet |
313 | Bulk | Active | Requires Holder | Cartridge, Glass | 62 mA | 250 V | - | Slow Blow | 35A | 0.021 | CE, CSA, UL | -55°C ~ 125°C | - | 0.250" Dia x 1.250" L (6.35mm x 31.75mm) | |
|
282-452FUSE CERAMIC 6.3A 250VAC |
4,551 |
|
Datasheet |
- | Box | Active | Requires Holder | Cartridge, Ceramic | 6.3 A | 250 V | - | Slow Blow | - | - | - | - | - | - |
