FET, MOSFET Arrays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPCP8401(TE85L,F)MOSFET N/P-CH 20V/12V 0.1A PS-8 |
9,897 |
|
Datasheet |
- | 8-SMD, Flat Leads | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 20V, 12V | 100mA, 5.5A | 3Ohm @ 10mA, 4V | 1.1V @ 100µA | - | 9.3pF @ 3V | 1W | 150°C (TJ) | - | - | Surface Mount | PS-8 (2.9x2.4) |
|
TPC8212-H(TE12LQ,MMOSFET 2N-CH 30V 6A 8SOP |
4,004 |
|
Datasheet |
- | 8-SOIC (0.173", 4.40mm Width) | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 30V | 6A | 21mOhm @ 3A, 10V | 2.3V @ 1mA | 16nC @ 10V | 840pF @ 10V | 450mW | 150°C (TJ) | - | - | Surface Mount | 8-SOP (5.5x6.0) |
|
|
TPC8213-H(TE12LQ,MMOSFET 2N-CH 60V 5A 8SOP |
4,331 |
|
Datasheet |
- | 8-SOIC (0.173", 4.40mm Width) | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 60V | 5A | 50mOhm @ 2.5A, 10V | 2.3V @ 1mA | 11nC @ 10V | 625pF @ 10V | 450mW | 150°C (TJ) | - | - | Surface Mount | 8-SOP (5.5x6.0) |
|
SI7501DN-T1-GE3MOSFET N/P-CH 30V 5.4A PPAK 1212 |
7,641 |
|
- |
- | PowerPAK® 1212-8 Dual | Cut Tape (CT) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel, Common Drain | Logic Level Gate | 30V | 5.4A, 4.5A | 35mOhm @ 7.7A, 10V | 3V @ 250µA | 14nC @ 10V | - | 1.6W | - | - | - | Surface Mount | PowerPAK® 1212-8 Dual |
|
SIB911DK-T1-GE3MOSFET 2P-CH 20V 2.6A PPAK8X8 |
7,216 |
|
- |
TrenchFET® | PowerPAK® SC-75-6L Dual | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 20V | 2.6A | 295mOhm @ 1.5A, 4.5V | 1V @ 250µA | 4nC @ 8V | 115pF @ 10V | 3.1W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SC-75-6L Dual |
|
FDD8424H_F085MOSFET N/P-CH 40V 9A/6.5A TO252 |
3,155 |
|
- |
PowerTrench® | TO-252-5, DPAK (4 Leads + Tab), TO-252AD | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 40V | 9A, 6.5A | 24mOhm @ 9A, 10V | 3V @ 250µA | 20nC @ 10V | 1000pF @ 20V | 1.3W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
UP04979G0LMOSFET N/P-CH 50V/30V SSMINI6-F2 |
8,127 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 50V, 30V | 100mA | 12Ohm @ 10mA, 4V | 1.5V @ 1µA | - | - | 125mW | 125°C (TJ) | - | - | Surface Mount | SSMini6-F2 |
|
FDG6332C-F085MOSFET N/P-CH 20V 0.7A SC88 |
5,170 |
|
Datasheet |
PowerTrench® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 20V | 700mA, 600mA | 300mOhm @ 700mA, 4.5V | 1.5V @ 250µA | 1.5nC @ 4.5V | 113pF @ 10V | 300mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SC-88 (SC-70-6) |
|
DMP57D5UV-7MOSFET 2P-CH 50V 0.16A SOT563 |
7,469 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 50V | 160mA | 6Ohm @ 100mA, 4V | 1V @ 250µA | - | 29pF @ 25V | 400mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-563 |
|
FDC6036P_F077MOSFET 2P-CH 20V 5A SSOT6 |
3,838 |
|
Datasheet |
PowerTrench® | 6-SSOT Flat-lead, SuperSOT™-6 FLMP | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 20V | 5A | 44mOhm @ 5A, 4.5V | 1.5V @ 250µA | 14nC @ 4.5V | 992pF @ 10V | 900mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SuperSOT™-6 |
|
2N7002DW L6327MOSFET 2N-CH 60V 0.3A SOT363 |
2,781 |
|
Datasheet |
OptiMOS™ | 6-VSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 60V | 300mA | 3Ohm @ 500mA, 10V | 2.5V @ 250µA | 0.6nC @ 10V | 20pF @ 25V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-SOT363-PO |
|
|
BSD223P L6327MOSFET 2P-CH 20V 0.39A SOT363 |
8,392 |
|
Datasheet |
OptiMOS™ | 6-VSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 20V | 390mA | 1.2Ohm @ 390mA, 4.5V | 1.2V @ 1.5µA | 0.62nC @ 4.5V | 56pF @ 15V | 250mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-SOT363-PO |
|
|
BSD235C L6327MOSFET N/P-CH 20V 0.95A SOT363 |
7,620 |
|
Datasheet |
OptiMOS™ | 6-VSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 20V | 950mA, 530mA | 350mOhm @ 950mA, 4.5V | 1.2V @ 1.6µA | 0.34nC @ 4.5V | 47pF @ 10V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-SOT363-PO |
|
|
BSD235N L6327MOSFET 2N-CH 20V 0.95A SOT363 |
2,922 |
|
Datasheet |
OptiMOS™ 2 | 6-VSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 20V | 950mA | 350mOhm @ 950mA, 4.5V | 1.2V @ 1.6µA | 0.32nC @ 4.5V | 63pF @ 10V | 500mW | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PG-SOT363-PO |
|
BSL205NL6327HTSA1MOSFET 2N-CH 20V 2.5A TSOP6-6 |
5,752 |
|
Datasheet |
OptiMOS™ | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 20V | 2.5A | 50mOhm @ 2.5A, 4.5V | 1.2V @ 11µA | 3.2nC @ 4.5V | 419pF @ 10V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSOP6-6 |
|
|
BSL214NL6327HTSA1MOSFET 2N-CH 20V 1.5A TSOP6-6 |
9,996 |
|
Datasheet |
OptiMOS™ | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 20V | 1.5A | 140mOhm @ 1.5A, 4.5V | 1.2V @ 3.7µA | 0.8nC @ 5V | 143pF @ 10V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSOP6-6 |
|
|
BSL215CL6327HTSA1MOSFET N/P-CH 20V 1.5A TSOP6-6 |
6,722 |
|
Datasheet |
OptiMOS™ | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 20V | 1.5A | 140mOhm @ 1.5A, 4.5V | 1.2V @ 3.7µA | 0.73nC @ 4.5V | 143pF @ 10V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSOP6-6 |
|
|
BSL315PL6327HTSA1MOSFET 2P-CH 30V 1.5A TSOP6-6 |
9,622 |
|
Datasheet |
OptiMOS™ | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 30V | 1.5A | 150mOhm @ 1.5A, 10V | 2V @ 11µA | 2.3nC @ 5V | 282pF @ 15V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSOP6-6 |
|
|
BSL316CL6327HTSA1MOSFET N/P-CH 30V 1.4A TSOP6-6 |
9,943 |
|
Datasheet |
OptiMOS™ | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 30V | 1.4A, 1.5A | 160mOhm @ 1.4A, 10V | 2V @ 3.7µA | 0.6nC @ 5V | 94pF @ 15V | 500mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TSOP6-6 |
|
MTM763200LBFMOSFET N/P-CH 20V 1.9A WSMINI6 |
2,852 |
|
- |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Obsolete | MOSFET (Metal Oxide) | N and P-Channel | - | 20V | 1.9A, 1.2A | 105mOhm @ 1A, 4V | 1.3V @ 1mA | - | 280pF @ 10V | 700mW | 150°C (TJ) | - | - | Surface Mount | WSMini6-F1-B |
