Common Mode Chokes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
CMF4-5003VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 500 µH @ 10 kHz | 10A | 6mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-7504VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 7.5 mH @ 10 kHz | 1.4A | 300mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-2504VMLFVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 2.5 mH @ 10 kHz | 2.8A | 73mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-5004VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 5 mH @ 10 kHz | 2A | 150mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-2504VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 2.5 mH @ 10 kHz | 2.8A | 73mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-3304VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 3.3 mH @ 10 kHz | 2.2A | 125mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-5003VMLFVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 500 µH @ 10 kHz | 10A | 6mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-1004HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 1 mH @ 10 kHz | 5.7A | 18mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-7503HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 750 µH @ 10 kHz | 6.7A | 13mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-1704HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 1.7 mH @ 10 kHz | 3.1A | 60mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-2504HCLFHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 2.5 mH @ 10 kHz | 2.8A | 73mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-3304HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 3.3 mH @ 10 kHz | 2.2A | 125mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-2504HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 2.5 mH @ 10 kHz | 2.8A | 73mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF3-1004SMLFCOMMON MODE TRANSFORMER CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | - | 1 mH @ 1 kHz | 4A | 45mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-5003HCLFHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 500 µH @ 10 kHz | 8.6A | 8mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-5003HCHRZ COMMON MODE CHOKE |
0 |
|
Datasheet |
Horizontal, 4 PC Pin | Power Line | 2 | - | 500 µH @ 10 kHz | 8.6A | 8mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
CMF4-1005VMVERTICAL MOUNT COMMON MODE CHOKE |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 10 mH @ 10 kHz | 1.2A | 390mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
|
T60405S6123X2256123X225 |
0 |
|
- |
Horizontal, 6 PC Pin | - | 3 | 1.7 kOhms @ 100 kHz | 2 mH @ 100 kHz | 25A | 5.3mOhm | - | - | -40°C ~ 130°C | - | - | - | - | - |
|
CM7560-563CMC 56UH 5.5A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 56 µH @ 1 kHz | 5.5A | 13mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
|
CM7560-683CMC 68UH 5.5A 2LN TH |
0 |
|
Datasheet |
Vertical, 4 PC Pin | - | 2 | - | 68 µH @ 1 kHz | 5.5A | 13mOhm | - | - | -55°C ~ 125°C | - | - | - | - | - |
Common Mode Chokes Electronic Components
Explore Common Mode Chokes electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
