Chassis Mount Resistors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Resistance | Tolerance | Power (Watts) | Composition | Temperature Coefficient | Operating Temperature | Features | Coating, Housing Type | Mounting Feature | Size / Dimension | Height - Seated (Max) | Lead Style | Failure Rate | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HPK600K1000RRES CHAS MNT 1K OHM 10% 600W |
0 |
|
Datasheet |
HPK600 | Box | Bulk | Obsolete | 1 kOhms | ±10% | 600W | Wirewound | ±150ppm/°C | -55°C ~ 150°C | - | Epoxy Coated | Flanges | 2.560" L x 2.362" W (65.00mm x 60.00mm) | 1.280" (32.50mm) | M4 Threaded | - | - | - |
|
|
HPK600K5000RRES CHAS MNT 5K OHM 10% 600W |
0 |
|
Datasheet |
HPK600 | Box | Bulk | Obsolete | 5 kOhms | ±10% | 600W | Wirewound | ±150ppm/°C | -55°C ~ 150°C | - | Epoxy Coated | Flanges | 2.560" L x 2.362" W (65.00mm x 60.00mm) | 1.280" (32.50mm) | M4 Threaded | - | - | - |
|
|
HPK600K10000RRES CHAS MNT 10K OHM 10% 600W |
0 |
|
Datasheet |
HPK600 | Box | Bulk | Obsolete | 10 kOhms | ±10% | 600W | Wirewound | ±150ppm/°C | -55°C ~ 150°C | - | Epoxy Coated | Flanges | 2.560" L x 2.362" W (65.00mm x 60.00mm) | 1.280" (32.50mm) | M4 Threaded | - | - | - |
|
FSE1200-14-10%-BKTSRES CHAS MNT 14 OHM 10% 1200W |
0 |
|
- |
FSE | Radial, Tubular | Bulk | Obsolete | 14 Ohms | ±10% | 1200W | Wirewound | ±400ppm/°C | -55°C ~ 350°C | - | Silicone Coated | Brackets | 2.500" Dia x 20.000" L (63.50mm x 508.00mm) | - | Solder Lugs | - | - | - |
|
CHF3020CBF101RRES CHAS MNT 100 OHM 5% 10W |
0 |
|
Datasheet |
CHF - RF Power | Axial | Bulk | Obsolete | 100 Ohms | ±5% | 10W | Thick Film | - | -55°C ~ 150°C | RF, High Frequency | Aluminum Oxide | Flanges | 0.300" L x 0.200" W (7.62mm x 5.08mm) | 0.146" (3.70mm) | Tab | - | - | - |
|
NHSC30011RJRES CHAS MNT 11 OHM 5% 300W |
0 |
|
Datasheet |
HS, CGS | Axial, Box | Bulk | Active | 11 Ohms | ±5% | 300W | Wirewound | ±50ppm/°C | -55°C ~ 200°C | - | Aluminum | Flanges | 5.039" L x 2.874" W (128.00mm x 73.00mm) | 1.654" (42.00mm) | Terminal Screw Type | - | - | - |
|
HVR30B8M4JRES CHAS MNT 8.4M OHM 5% 50W |
0 |
|
Datasheet |
HVR, CGS | Radial, Tubular | Bulk | Obsolete | 8.4 MOhms | ±5% | 50W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.205" Dia x 4.724" L (30.60mm x 120.00mm) | - | Solder Lugs | - | - | - |
|
|
HVR30C15MJRES CHAS MNT 15M OHM 5% 50W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 15 MOhms | ±5% | 50W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.110" Dia x 4.724" L (28.20mm x 120.00mm) | - | Ferrule Ends | - | - | - |
|
|
HVR30C5M0KRES CHAS MNT 5M OHM 10% 50W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 5 MOhms | ±10% | 50W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.110" Dia x 4.724" L (28.20mm x 120.00mm) | - | Ferrule Ends | - | - | - |
|
|
HVR50B50MKRES CHAS MNT 50M OHM 10% 100W |
0 |
|
Datasheet |
HVR, CGS | Radial, Tubular | Bulk | Obsolete | 50 MOhms | ±10% | 100W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.205" Dia x 9.449" L (30.60mm x 240.00mm) | - | Solder Lugs | - | - | - |
|
NHSA50128RFRES CHAS MNT 128 OHM 1% 50W |
0 |
|
Datasheet |
HS, CGS | Axial, Box | Tray | Active | 128 Ohms | ±1% | 50W | Wirewound | ±30ppm/°C | -55°C ~ 200°C | - | Aluminum | Flanges | 2.008" L x 1.181" W (51.00mm x 30.00mm) | 0.669" (17.00mm) | Solder Lugs | - | - | - |
|
|
NHSA5016RFRES CHAS MNT 16 OHM 1% 50W |
0 |
|
Datasheet |
HS, CGS | Axial, Box | Tray | Active | 16 Ohms | ±1% | 50W | Wirewound | ±50ppm/°C | -55°C ~ 200°C | - | Aluminum | Flanges | 2.008" L x 1.181" W (51.00mm x 30.00mm) | 0.669" (17.00mm) | Solder Lugs | - | - | - |
|
|
HVR30D5M0KRES CHAS MNT 5M OHM 10% 50W |
0 |
|
- |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 5 MOhms | ±10% | 50W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.181" Dia x 5.512" L (30.00mm x 140.00mm) | - | Ferrule Ends (Ferrule Ends, M5 Thread) | - | - | - |
|
|
HVR10D25MKRES CHAS MNT 25M OHM 10% 10W |
0 |
|
- |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 25 MOhms | ±10% | 10W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 0.394" Dia x 2.756" L (10.00mm x 70.00mm) | - | Ferrule Ends (Ferrule Ends, M5 Thread) | - | - | - |
|
|
HVR50B100MKRES CHAS MNT 100M OHM 10% 100W |
0 |
|
- |
HVR, CGS | Radial, Tubular | Bulk | Obsolete | 100 MOhms | ±10% | 100W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 1.205" Dia x 9.449" L (30.60mm x 240.00mm) | - | Solder Lugs | - | - | - |
|
|
ME1801K25JHFRES CHAS MNT 1.25K OHM 5% 230W |
0 |
|
Datasheet |
ME, CGS | Radial, Tubular | Bulk | Obsolete | 1.25 kOhms | ±5% | 230W | Wirewound | ±400ppm/°C | -55°C ~ 200°C | - | Vitreous Enamel Coated | Brackets (not included) | 1.102" Dia x 8.504" L (28.00mm x 216.00mm) | - | Solder Lugs | - | - | - |
|
|
HVR10D10MKRES CHAS MNT 10M OHM 10% 10W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 10 MOhms | ±10% | 10W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 0.394" Dia x 2.756" L (10.00mm x 70.00mm) | - | Ferrule Ends (Ferrule Ends, M5 Thread) | - | - | - |
|
|
HVR10D100MKRES CHAS MNT 100M OHM 10% 10W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 100 MOhms | ±10% | 10W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 0.394" Dia x 2.756" L (10.00mm x 70.00mm) | - | Ferrule Ends (Ferrule Ends, M5 Thread) | - | - | - |
|
|
HVR20C11MFRES CHAS MNT 11M OHM 1% 30W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 11 MOhms | ±1% | 30W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 0.795" Dia x 4.724" L (20.20mm x 120.00mm) | - | Ferrule Ends | - | - | - |
|
|
HVR20D470KJRES CHAS MNT 470K OHM 5% 30W |
0 |
|
Datasheet |
HVR, CGS | Axial, Tubular | Bulk | Obsolete | 470 kOhms | ±5% | 30W | Thick Film | ±300ppm/°C | - | High Voltage, RF, High Frequency | Aluminum | Brackets (not included) | 0.846" Dia x 5.512" L (21.50mm x 140.00mm) | - | Ferrule Ends (Ferrule Ends, M5 Thread) | - | - | - |
Chassis Mount Resistors Electronic Components
Frequently Asked Questions
Q1: What products are included in Chassis Mount Resistors?
This category includes related Chassis Mount Resistors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Chassis Mount Resistors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Chassis Mount Resistors and other electronic components.
