Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
420HXG220MEFCSN35X25CAP ALUM 220UF 20% 420V SNAP TH |
84 |
|
Datasheet |
HXG | Bulk | Active | 220 µF | ±20% | 420 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.74 A @ 120 Hz | 2.436 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
400SXG390MEFCSN35X35CAP ALUM 390UF 20% 400V SNAP TH |
100 |
|
Datasheet |
SXG | Bulk | Active | 390 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.6 A @ 120 Hz | 2.24 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
450USC470MEFCSN35X45CAP ALUM 470UF 20% 450V SNAP TH |
100 |
|
Datasheet |
USC | Bulk | Not For New Designs | 470 µF | ±20% | 450 V | - | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 2.68 A @ 120 Hz | 3.752 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
|
450HXK330MEPASN35X30CAP ALUM 330UF 20% 450V SNAP TH |
99 |
|
Datasheet |
HXK | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.75 A @ 120 Hz | 2.45 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
450HXH330MEPASN35X30CAP ALUM 330UF 20% 450V SNAP TH |
47 |
|
Datasheet |
HXH | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.74 A @ 120 Hz | 2.436 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
420HXK330MEPASN35X25CAP ALUM 330UF 20% 420V SNAP TH |
86 |
|
Datasheet |
HXK | Bulk | Active | 330 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.56 A @ 120 Hz | 2.184 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
400VXG470MEFCSN35X40CAP ALUM 470UF 20% 400V SNAP TH |
48 |
|
Datasheet |
VXG | Bulk | Active | 470 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.95 A @ 120 Hz | 2.73 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
400VXT470MEFCSN35X30CAP ALUM 470UF 20% 400V SNAP TH |
22 |
|
Datasheet |
VXT | Bulk | Active | 470 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.65 A @ 120 Hz | 2.31 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
450GXK390MEFCSN30X40CAP ALUM 450V POLAR |
100 |
|
Datasheet |
GXK | Bulk | Active | 390 µF | ±20% | 450 V | - | 7000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.84 A @ 120 Hz | 2.576 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
450VXT330MEFCSN30X30CAP ALUM 330UF 20% 450V SNAP TH |
38 |
|
Datasheet |
VXT | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.51 A @ 120 Hz | 2.114 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
400HXK390MEPASN30X35CAP ALUM 390UF 20% 400V SNAP TH |
92 |
|
Datasheet |
HXK | Bulk | Active | 390 µF | ±20% | 400 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.89 A @ 120 Hz | 2.646 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
|
450VXT330MEFCSN35X25CAP ALUM 330UF 20% 450V SNAP TH |
97 |
|
Datasheet |
VXT | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.37 A @ 120 Hz | 1.918 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
500MXK270MEFCSN30X30CAP ALUM 270UF 20% 500V SNAP |
94 |
|
Datasheet |
MXK | Bulk | Active | 270 µF | ±20% | 500 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | 1.38 A @ 120 Hz | 1.932 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
420VXT390MEFCSN35X25CAP ALUM 390UF 20% 420V SNAP TH |
76 |
|
Datasheet |
VXT | Bulk | Active | 390 µF | ±20% | 420 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.4 A @ 120 Hz | 1.96 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
861140786024CAP ALUM 10000UF 20% 63V SNAP TH |
45 |
|
Datasheet |
WCAP-AI3H | Tray | Active | 10000 µF | ±20% | 63 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 4.69 A @ 120 Hz | 6.0032 A @ 100 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.126" (54.00mm) | - | Through Hole | |
|
|
450MXT390MEFCSN22X50CAP ALUM 390UF 20% 450V SNAP TH |
16 |
|
Datasheet |
MXT | Bulk | Active | 390 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.76 A @ 120 Hz | 2.464 A @ 10 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
450HXG560MEFCSN35X50CAP ALUM 560UF 20% 450V SNAP TH |
88 |
|
Datasheet |
HXG | Bulk | Active | 560 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3.23 A @ 120 Hz | 4.522 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
200MXC2200MEFCSN35X50CAP ALUM 2200UF 20% 200V SNAP TH |
98 |
|
Datasheet |
MXC | Bulk | Not For New Designs | 2200 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.55 A @ 120 Hz | 5.325 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
400MXT470MEFCSN35X25CAP ALUM 470UF 20% 400V SNAP TH |
60 |
|
Datasheet |
MXT | Bulk | Active | 470 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.4 A @ 120 Hz | 1.96 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
450MXT390MEFCSN35X25CAP ALUM 390UF 20% 450V SNAP TH |
78 |
|
Datasheet |
MXT | Bulk | Active | 390 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.28 A @ 120 Hz | 1.792 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.063" (27.00mm) | - | Through Hole |
Aluminum Electrolytic Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Aluminum Electrolytic Capacitors?
This category includes related Aluminum Electrolytic Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Aluminum Electrolytic Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Aluminum Electrolytic Capacitors and other electronic components.
