Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
688TTA035MCAP ALUM 6800UF 20% 35V AXIAL TH |
77 |
|
Datasheet |
TTA | Bulk | Active | 6800 µF | ±20% | 35 V | 63.4mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.76 A @ 120 Hz | 3.5328 A @ 50 kHz | - | - | 0.866" Dia x 2.010" L (22.00mm x 51.00mm) | - | - | Through Hole | |
|
LGNW6471MELB45CAP ALUM 470UF 20% 420V SNAP TH |
59 |
|
Datasheet |
LGN | Bulk | Active | 470 µF | ±20% | 420 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.86 A @ 120 Hz | 2.6598 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
ALA7DA301CC450CAP ALUM 300UF 20% 450V SNAP TH |
26 |
|
Datasheet |
ALA7D | Bulk | Active | 300 µF | ±20% | 450 V | 504.2mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 2.12 A @ 100 Hz | 4.12 A @ 10 kHz | 481.2 mOhms | - | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
LGX2H271MELB50CAP ALUM 270UF 20% 500V SNAP TH |
81 |
|
Datasheet |
LGX | Bulk | Active | 270 µF | ±20% | 500 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.5 A @ 120 Hz | 2.145 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
450USG470MEFCSN35X40CAP ALUM 470UF 20% 450V SNAP TH |
68 |
|
Datasheet |
USG | Bulk | Active | 470 µF | ±20% | 450 V | - | 3000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 2.66 A @ 120 Hz | 3.724 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
MAL225652472E3CAP ALUM 4700UF 20% 80V SNAP TH |
45 |
|
Datasheet |
256 PMG-SI | Bulk | Active | 4700 µF | ±20% | 80 V | 71mOhm | 2000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | - | 3.168 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
ELXS201VSN152MR45SCAP ALUM 1500UF 20% 200V SNAP TH |
43 |
|
Datasheet |
LXS | Bulk | Active | 1500 µF | ±20% | 200 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 3.34 A @ 120 Hz | 5.01 A @ 50 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.870" (47.50mm) | - | Through Hole | |
|
400MXK560MEFCSN35X30CAP ALUM 560UF 20% 400V SNAP TH |
37 |
|
Datasheet |
MXK | Tray | Active | 560 µF | ±20% | 400 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.75 A @ 120 Hz | 2.45 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
450MXK330MEFCFA30X30CAP ALUM 330UF 20% 450V SNAP TH |
41 |
|
Datasheet |
MXK | Bulk | Active | 330 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.58 A @ 120 Hz | 2.212 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
EKMH350VSN153MR45UCAP ALUM 15000UF 20% 35V SNAP TH |
14 |
|
Datasheet |
KMH | Bulk | Active | 15000 µF | ±20% | 35 V | 28mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.72 A @ 120 Hz | 4.0176 A @ 100 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
450VXG330MEFCSN35X35CAP ALUM 330UF 20% 450V SNAP TH |
99 |
|
Datasheet |
VXG | Bulk | Active | 330 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.65 A @ 120 Hz | 2.31 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
ALC10A121CC550CAP ALUM 120UF 20% 550V SNAP TH |
9 |
|
Datasheet |
ALC10 | Bulk | Active | 120 µF | ±20% | 550 V | 2.874Ohm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.14 A @ 100 Hz | 1.86 A @ 10 kHz | 2.506 Ohms | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.457" (37.00mm) | - | Through Hole | |
|
160MXG3300MEFCSN35X55CAP ALUM 3300UF 20% 160V SNAP TH |
100 |
|
Datasheet |
MXG | Bulk | Active | 3300 µF | ±20% | 160 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.24 A @ 120 Hz | 4.86 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 2.244" (57.00mm) | - | Through Hole | |
|
TVA1420-E3CAP ALUM 100UF 150V AXIAL TH |
66 |
|
Datasheet |
TVA ATOM® | Bulk | Active | 100 µF | - | 150 V | - | - | -20°C ~ 85°C | Polar | - | Audio | - | - | - | - | 0.625" Dia x 1.750" L (15.88mm x 44.45mm) | - | - | Through Hole | |
|
ALT22A103CB040CAP ALUM 10000UF 20% 40V SNAP TH |
31 |
|
Datasheet |
ALT22 | Box | Active | 10000 µF | ±20% | 40 V | - | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.850" (47.00mm) | - | Through Hole | |
|
LGM2W271MELB25CAP ALUM 270UF 20% 450V SNAP TH |
92 |
|
Datasheet |
LGM | Bulk | Active | 270 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 650 mA @ 120 Hz | - | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.083" (27.50mm) | - | Through Hole | |
|
450VXG390MEFCSN30X50CAP ALUM 390UF 20% 450V SNAP TH |
20 |
|
Datasheet |
VXG | Bulk | Active | 390 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.98 A @ 120 Hz | 2.772 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
450MXK390MEFCSN35X30CAP ALUM 390UF 20% 450V SNAP TH |
40 |
|
Datasheet |
MXK | Tray | Active | 390 µF | ±20% | 450 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.68 A @ 120 Hz | 2.352 A @ 10 kHz | - | 0.394" (10.00mm) | 1.378" Dia (35.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
500MXH330MEFCSN30X50CAP ALUM 330UF 20% 500V SNAP TH |
47 |
|
Datasheet |
MXH | Bulk | Active | 330 µF | ±20% | 500 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.81 A @ 120 Hz | 2.534 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole | |
|
|
ALA7DA471CF450CAP ALUM 470UF 20% 450V SNAP TH |
9 |
|
Datasheet |
ALA7D | Bulk | Active | 470 µF | ±20% | 450 V | 322.4mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 1.99 A @ 100 Hz | 4.77 A @ 10 kHz | 506.4 mOhms | - | 1.181" Dia (30.00mm) | 2.047" (52.00mm) | - | Through Hole |
Aluminum Electrolytic Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Aluminum Electrolytic Capacitors?
This category includes related Aluminum Electrolytic Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Aluminum Electrolytic Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Aluminum Electrolytic Capacitors and other electronic components.
