TVS Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SA11AGTVS DIODE 11VWM 18.2VC AXIAL |
4,375 |
|
Datasheet |
DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 11V | 12.2V | 18.2V | 27.4A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
GSM4F40CATVS, BI-DIR, 400W, 40V, ESGA (SO |
6,000 |
|
Datasheet |
SOD-123F | - | Tape & Reel (TR) | Active | Zener | - | 1 | 40V | 44.4V | 64.5V | 6.2A | 400W | No | Telecom | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
GSMF58CATVS, BI-DIR, 200W, 58V, ESGA (SO |
5,890 |
|
Datasheet |
SOD-123F | GSMF58CA | Tape & Reel (TR) | Active | Zener | - | 1 | 58V | 64.4V | 93.6V | 2.14A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
GSMF3.3CATVS, BI-DIR, 200W, 3.3V, ESGA (S |
5,624 |
|
Datasheet |
SOD-123F | - | Tape & Reel (TR) | Active | Zener | - | 1 | 3.3V | 4.22V | 8.8V | 22.7A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
SMAJ5.0CATVS, BI-DIR, 400W, 5V, DO-214AC |
5,315 |
|
Datasheet |
DO-214AC, SMA | SMAJx | Cut Tape (CT) | Active | Zener | - | 1 | 5V | 6.4V | 9.2V | 43.5A | 400W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
GSMF13CATVS, BI-DIR, 200W, 13V, ESGA (SO |
5,060 |
|
Datasheet |
SOD-123F | GSMF13CA | Tape & Reel (TR) | Active | Zener | - | 1 | 13V | 14.4V | 21.5V | 9.3A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
1SMA22CAT3TVS DIODE 22VWM 35.5VC SMA |
8,519 |
|
Datasheet |
DO-214AC, SMA | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 22V | 24.4V | 35.5V | - | 400W | No | General Purpose | 280pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMA |
|
|
SA45ARLTVS DIODE 45VWM 72.7VC AXIAL |
5,000 |
|
Datasheet |
DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 45V | 50V | 72.7V | 6.9A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
SA16ARLTRANS VOLTAGE SUPPRESSOR DIODE |
5,000 |
|
Datasheet |
- | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
GSMF3.3ATVS, UNI-DIR, 200W, 3.3V, ESGA ( |
4,532 |
|
Datasheet |
SOD-123F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 3.3V | 4.22V | 8.8V | 22.7A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
1SMA51CAT3GTRANS VOLTAGE SUPPRESSOR DIODE |
4,165 |
|
Datasheet |
- | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SA28ATVS DIODE 28VWM 45.4VC DO204AC |
4,000 |
|
Datasheet |
DO-204AC, DO-15, Axial | SA | Bulk | Obsolete | Zener | 1 | - | 28V | 31.1V | 45.4V | 11.2A | 500W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | DO-204AC (DO-15) |
|
|
SA120AGTVS DIODE 120VWM 193VC AXIAL |
3,471 |
|
Datasheet |
DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 120V | 133V | 193V | 2.5A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
CM1215-02SRTVS DIODE 4.8VC SOT143 |
5,799 |
|
Datasheet |
TO-253-4, TO-253AA | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 2 | - | - | - | 4.8V (Typ) | 1A (8/20µs) | - | No | General Purpose | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SOT-143-4 |
|
CM1215-02SOTVS DIODE 4.8VC SOT23-5 |
8,581 |
|
Datasheet |
SC-74A, SOT-753 | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 2 | - | - | - | 4.8V (Typ) | 1A (8/20µs) | - | No | General Purpose | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SOT-23-5 |
|
1SMB51CAT3TVS DIODE 51VWM 82.4VC SMB |
7,511 |
|
Datasheet |
DO-214AA, SMB | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 51V | 56.7V | 82.4V | 7.3A | 600W | No | General Purpose | 175pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
.jpg)
|
SD36TVS DIODE 36VWM 60VC SOD323 |
2,980 |
|
Datasheet |
SC-76, SOD-323 | - | Cut Tape (CT) | Active | Zener | 1 | - | 36V (Max) | 40V | 75V | 5A | 350W | No | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
SL24T1TVS LO CAP 300W 24V ESD SOT23 |
9,813 |
|
Datasheet |
- | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1SMB60CAT3TVS DIODE 60VWM 96.8VC SMB |
8,531 |
|
Datasheet |
DO-214AA, SMB | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 60V | 66.7V | 96.8V | 6.2A | 600W | No | General Purpose | 150pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SRV05-4TVS DIODE 5V VBR MIN 6V SOT-23 |
1,956 |
|
Datasheet |
SOT-23-6 | - | Cut Tape (CT) | Active | Steering (Rail to Rail) | 4 | - | 5V (Max) | 6V | 17.5V | 12A (8/20µs) | 300W | Yes | General Purpose | 3pF @ 1MHz | 125°C (TJ) | - | - | Surface Mount | SOT-23-6 |
TVS Diodes Electronic Components
Frequently Asked Questions
Q1: What products are included in TVS Diodes?
This category includes related TVS Diodes subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for TVS Diodes components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for TVS Diodes and other electronic components.
