Surge Protection Devices (SPDs)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MA4IMA12SPD TYPE 2 320V MCOV 1 POLE |
4,428 |
|
Datasheet |
- | Box | Active | Type 2 | Module Only | 1 | 320V | 20 kA | 120 kA | 200 kA | - | - | 65°C | - | Panel Mount | - |
|
|
MA8IMA12SPD TYPE 2 420V MCOV 1 POLE |
7,290 |
|
Datasheet |
- | Box | Active | Type 2 | Module Only | 1 | 420V | 20 kA | - | 200 kA | - | - | - | - | Panel Mount | - |
|
|
MA4IMA121SPD TYPE 1 320V MCOV 1 POLE |
5,167 |
|
Datasheet |
- | Box | Active | Type 1 | Module Only | 1 | 320V | 20 kA | - | 200 kA | - | - | - | - | Panel Mount | - |
|
|
CVX050-480LSPD TYP 1/TYP 2 1.1KV MCOV 1POLE |
9,966 |
|
- |
CVX | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 1.1kV | 10 kA | 50 kA | 100 kA | 4 kV | - | -25°C ~ 60°C | Visual Life Indicator | Chassis Mount | CE, CSA, UL |
|
|
CVX050-240SSPD TYP 1/TYP 2 300V MCOV 1 POLE |
8,329 |
|
- |
CVX | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 300V | 20 kA | 50 kA | 100 kA | 1.2 kV | - | -25°C ~ 60°C | Visual Life Indicator | Chassis Mount | CE, CSA, UL |
|
|
CVX050-230LSPD TYP 1/TYP 2 640V MCOV 1 POLE |
9,748 |
|
- |
CVX | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 640V | 20 kA | 50 kA | 100 kA | - | 1.2 kV | -25°C ~ 60°C | Visual Life Indicator | Chassis Mount | CE, CSA, UL |
|
|
MA1IMA16SPD TYPE 2 150V MCOV 1 POLE |
5,754 |
|
Datasheet |
- | Box | Active | Type 2 | Module Only | 1 | 150V | 20 kA | 160 kA | 200 kA | - | - | - | - | Panel Mount | - |
|
|
SPODU550MTRSPD TYP 1/TYP 2 550V MCOV 1 POLE |
5,526 |
|
- |
SPOD | Bulk | Obsolete | Type 1, Type 2 | Module Only | 1 | 550V | 20 kA | - | 200 kA | - | - | -25°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | PCB Mount | cURus |
|
|
SPODU550S2SPD TYP 1/TYP 2 550V MCOV 1 POLE |
8,369 |
|
- |
SPOD | Bulk | Obsolete | Type 1, Type 2 | Module Only | 1 | 550V | 20 kA | - | 200 kA | - | - | -25°C ~ 85°C | - | PCB Mount | cURus |
|
|
HFNF120ICSE005SPD 1 POLE |
7,269 |
|
Datasheet |
- | Box | Active | - | Module Only | 1 | - | - | - | - | - | - | - | - | Chassis Mount | - |
|
2024880000SPD TYPE 2 180VAC MCOV 1 POLE |
9,235 |
|
- |
VPU | Box | Obsolete | Type 2 | Base + Module | 1 | 180VAC | 20 kA | 40 kA | 200 kA | 800 V | - | -40°C ~ 70°C | Remote Signaling Contacts | - | cURus |
|
2024860000SPD TYPE 1 385VAC MCOV 1 POLE |
6,372 |
|
- |
VPU | Box | Obsolete | Type 1 | Base + Module | 1 | 385VAC | 20 kA | 40 kA | 25 kA | - | - | -40°C ~ 70°C | - | Chassis Mount | CE, cURus |
|
|
HFNF240ICSE002SPD 1 POLE |
2,154 |
|
Datasheet |
- | Box | Active | - | Module Only | 1 | - | - | - | - | - | - | - | - | Chassis Mount | - |
|
|
CVX050-208YSPD TYP 1/TYP 2 640V MCOV 1 POLE |
5,654 |
|
- |
CVX | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 640V | 20 kA | 50 kA | 100 kA | - | 1.2 kV | -25°C ~ 60°C | Visual Life Indicator | Chassis Mount | CE, CSA, UL |
|
|
SP200-T2F-1201P-LCSPD TYPE 2 150VAC MCOV 1 POLE |
3,808 |
|
Datasheet |
SP200 | Bulk | Active | Type 2 | Base + Module | 1 | 150VAC | 20 kA | - | 200 kA | - | - | -40°C ~ 75°C | Visual Life Indicator | Chassis Mount | - |
|
|
MA4IMA16SPD 140V MCOV 1 POLE |
8,079 |
|
Datasheet |
- | Box | Active | - | - | 1 | 140V | 100 kA | - | 1.5 kA | 1.2 kV | - | 60°C | - | Panel Mount | - |
|
|
MA8IMA161SPD TYPE 1 420VAC MCOV 1 POLE |
2,970 |
|
Datasheet |
- | Box | Active | Type 1 | Module Only | 1 | 420VAC | 20 kA | - | 200 kA | - | - | - | - | Chassis Mount | - |
|
|
MA8IMA16SPD TYPE 2 420V MCOV 1 POLE |
4,614 |
|
Datasheet |
- | Box | Active | Type 2 | Module Only | 1 | 420V | 20 kA | - | 200 kA | - | - | - | - | Panel Mount | - |
|
|
MA3IMA16SPD TYPE 2 150VAC MCOV 1 POLE |
4,162 |
|
Datasheet |
- | Box | Active | Type 2 | Module Only | 1 | 150VAC | 20 kA | - | - | - | - | 65°C | - | Chassis Mount | - |
|
|
MA4IMA161SPD TYPE 1 320V MCOV 1 POLE |
4,966 |
|
Datasheet |
- | Box | Active | Type 1 | Module Only | 1 | 320V | 20 kA | - | 200 kA | - | - | - | - | Panel Mount | - |
Surge Protection Devices (SPDs) Electronic Components
Explore Surge Protection Devices (SPDs) electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
