RF Transceiver ICs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Type | RF Family/Standard | Protocol | Modulation | Frequency | Data Rate (Max) | Power - Output | Sensitivity | Memory Size | Serial Interfaces | GPIO | Voltage - Supply | Current - Receiving | Current - Transmitting | Operating Temperature | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ADRV9002BBCZIC RF TXRX 196CSPBGA |
30 |
|
Datasheet |
- | 196-TFBGA, CSPBGA | Tray | Active | Not Verified | TxRx Only | - | - | - | 30MHz ~ 6GHz | - | 7.8dBm | - | - | SPI | 12 | - | - | - | -40°C ~ 110°C | - | - | 196-CSPBGA (12x12) |
|
ADRV9026BBCZIC RF TXRX 289CSPBGA |
9 |
|
Datasheet |
- | 289-LFBGA, CSPBGA | Tray | Active | Not Verified | TxRx Only | - | - | - | 650MHz ~ 6GHz | 491.52MSps | - | - | - | - | - | 0.95V ~ 1.89V | - | - | -40°C ~ 110°C | - | - | 289-CSPBGA (14x14) |
|
ESP8285H16IC RF TXRX+MCU WIFI 32QFN |
25,950 |
|
Datasheet |
ESP8285 | 32-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | WiFi | 802.11b/g/n | - | 2.4GHz | 54Mbps | 20dBm | -91dBm | - | I2C, I2S, SPI, UART | 8 | 2.7V ~ 3.6V | 50mA ~ 56mA | 120mA ~ 170mA | - | - | - | 32-QFN (5x5) |
|
ESP8685H4IC RF TXRX+MCU BLE 28QFN |
2,604 |
|
Datasheet |
ESP8685 | 28-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth, WiFi | 802.11b/g/n, Bluetooth v5.0 | - | 2.4GHz | 150Mbps | 21dBm | -98.4dBm | 4MB Flash, 384kB RAM, 400kB SRAM | ADC, GPIO, I2C, I2S, PWM, SPI, UART, USB | 15 | 3V ~ 3.6V | 84mA ~ 87mA | 276mA ~ 335mA | -40°C ~ 105°C (TA) | - | - | 28-QFN (4x4) |
|
ESP32-C6IC RF TXRX BLE 40QFN |
172 |
|
Datasheet |
ESP32-C6 | 40-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | TxRx Only | Bluetooth, WiFi | Bluetooth v5.0, Thread, Zigbee® | 16-QAM, CCK, DSSS, OFDM, O-QPSK | 2.412GHz ~ 2.484GHz | 250kbps | 21dBm | -106dBm | - | GPIO, I2C, I2S, IrDA, JTAG, PCM, PWM, SDIO, SPI, UART, USB | 30 | 3V ~ 3.6V | 71mA ~ 82mA | 82mA ~ 354mA | -40°C ~ 105°C (TA) | - | - | 40-QFN (5x5) |
|
ESP32-D0WDR2-V3IC RF TXRX+MCU BLE 48QFN |
1,875 |
|
Datasheet |
ESP32 | 48-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth, WiFi | 802.11b/g/n, Bluetooth v4.2 + EDR, Class 1, 2 and 3 | 8DPSK, DSSS, DQPSK, OFDM | 2.4GHz | 150Mbps | 19.5dBm | -98dBm | 2MB PSRAM, 448kB ROM, 536kB SRAM | ADC, GPIO, I2C, I2S, SDIO, SPI, PWM, UART | 34 | 2.3V ~ 3.6V | 95mA ~ 100mA | 130mA ~ 240mA | -40°C ~ 125°C | - | - | 48-QFN (5x5) |
|
ESP32-S3R2IC RF TXRX+MCU BLE 56QFN |
1,041 |
|
Datasheet |
ESP32-S3 | 56-VFQFN Exposed Pad | Strip | Active | Not Verified | TxRx + MCU | Bluetooth, WiFi | 802.11b/g/n, Bluetooth v5.0 | - | 2.412GHz ~ 2.484GHz | 150Mbps | 21dBm | -98.4dBm | 2MB PSRAM | I2C, I2S, SPI, UART, USB | 30 | 3.3V | - | - | -40°C ~ 85°C | - | - | 56-QFN (7x7) |
|
|
STM32WB05KNV6TRULTRA-LOW-POWER, 2.4 GHZ NETWORK |
2,770 |
|
Datasheet |
STM32WB | 32-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | TxRx + MCU | Bluetooth | Bluetooth v5.4 | GFSK | - | 2Mbps | 8dBm | -104dBm | - | GPIO, I2S, SPI, UART | 20 | 1.7V ~ 3.6V | 3.4mA | 4.3mA | -40°C ~ 105°C (TA) | - | - | 32-VFQFPN (5x5) |
|
NRF52810-CAAA-R7IC RF TXRX+MCU BLE 33WLCSP |
2,621 |
|
Datasheet |
- | 33-UFBGA, WLCSP | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.0 | - | 2.4GHz | 2Mbps | 4dBm | -96dBm | 192kB Flash, 24kB RAM | ADC, PDM, PWM, SPI, UART | - | 1.7V ~ 3.6V | 4.6mA | 4.6mA ~ 7mA | - | - | - | 33-WLCSP (2.48x2.46) |
|
NRF52810-QCAA-TIC RF TXRX+MCU BLE 32QFN |
8,961 |
|
Datasheet |
- | 32-VFQFN Exposed Pad | Tray | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.0 | - | 2.4GHz | 2Mbps | 4dBm | -96dBm | 192kB Flash, 24kB RAM | I2C, UART | 32 | 1.7V ~ 3.6V | 4.6mA | 4.6mA ~ 25mA | -40°C ~ 85°C | - | - | 32-QFN (5x5) |
|
|
NRF52810-QCAA-E-R7IC RF TXRX+MCU BLE 32QFN |
1,747 |
|
Datasheet |
- | 32-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth, Thread | FSK | 2.4GHz | 2Mbps | -96dBm | -96dBm | 192kB Flash, 24kB RAM | I2C, PCM, PWM, SPI, UART | 21 | 1.7V ~ 3.6V | 4.6mA | 4.6mA ~ 7mA | -40°C ~ 85°C (TA) | - | - | 32-QFN (5x5) |
|
|
ESP32-S3R8IC RF TXRX+MCU BLE 56QFN |
3,511 |
|
Datasheet |
ESP32-S3 | 56-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth, WiFi | 802.11b/g/n, Bluetooth v5.0 | - | 2.412GHz ~ 2.484GHz | 150Mbps | 21dBm | -98.4dBm | 8MB PSRAM | I2C, I2S, SPI, UART, USB | 30 | 3.3V | - | - | -40°C ~ 85°C | - | - | 56-QFN (7x7) |
|
|
STM32WB05KZV6TRULTRA-LOW-POWER, ARM CORTEX-M0+ |
2,875 |
|
Datasheet |
STM32WB | 32-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | TxRx + MCU | Bluetooth | Bluetooth v5.4 | GFSK | - | 2Mbps | 8dBm | -104dBm | 192kB Flash, 24kB SRAM | ADC, GPIO, I2C, I2S, IrDA, JTAG, PWM, SPI, UART, USART | 20 | 1.7V ~ 3.6V | 3.4mA | 4.3mA | -40°C ~ 105°C (TA) | - | - | 32-VFQFPN (5x5) |
|
|
ESP32-S3R8VIC RF TXRX+MCU BLE 56QFN |
1,568 |
|
Datasheet |
ESP32-S3 | 56-VFQFN Exposed Pad | Strip | Active | Not Verified | TxRx + MCU | Bluetooth, WiFi | 802.11b/g/n, Bluetooth v5.0 | - | 2.412GHz ~ 2.484GHz | 150Mbps | 21dBm | -98.4dBm | 8MB PSRAM | I2C, I2S, SPI, UART, USB | 30 | 3.3V | - | - | -40°C ~ 85°C | - | - | 56-QFN (7x7) |
|
NRF52810-QFAA-RIC RF TXRX+MCU BLE 48QFN |
16,047 |
|
Datasheet |
- | 48-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.0 | - | 2.4GHz | 2Mbps | 4dBm | -96dBm | - | I2C, UART | 32 | 1.7V ~ 3.6V | 4.6mA | 4.6mA ~ 25mA | -40°C ~ 85°C | - | - | 48-QFN (6x6) |
|
|
NRF52810-QFAA-R7IC RF TXRX+MCU BLE 48QFN |
10,861 |
|
Datasheet |
- | 48-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.0 | - | 2.4GHz | 2Mbps | 4dBm | -96dBm | - | I2C, UART | 32 | 1.7V ~ 3.6V | 4.6mA | 4.6mA ~ 25mA | -40°C ~ 85°C | - | - | 48-QFN (6x6) |
|
|
STM32WB09KEV6TRULTRA-LOW-POWER, ARM CORTEX-M0+ |
2,887 |
|
Datasheet |
STM32WB | 32-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | TxRx + MCU | Bluetooth | Bluetooth v5.4 | GFSK | - | 2Mbps | 8dBm | -104dBm | 512kB Flash, 64kB RAM | ADC, GPIO, I2C, I2S, IrDA, JTAG, PWM, SPI, UART, USART | 20 | 1.7V ~ 3.6V | 3.6mA ~ 9.1mA | 4.9mA ~ 9.7mA | -40°C ~ 85°C (TA) | - | - | 32-VFQFPN (5x5) |
|
|
CC2340R52E0RKPRIC RF TXRX+MCU BLE 40VQFN |
4,955 |
|
Datasheet |
SimpleLink™ | 40-VFQFN Exposed Pad | Tape & Reel (TR) | Active | - | TxRx + MCU | Bluetooth | Bluetooth v5.3, Wireless M-Bus, Zigbee® | DSSS, GFSK, QPSK | 2.36GHz ~ 2.5GHz | 3Mbps | 8dBm | -102dBm | 512kB Flash, 12kB ROM, 36kB SRAM | GPIO, I2C, PWM, SPI, UART | 26 | 1.71V ~ 3.8V | 5.3mA ~ 9mA | 4mA ~ 19mA | -40°C ~ 125°C (TA) | - | - | 40-VQFN (5x5) |
|
EFR32BG22C112F352GM32-CIC RF TXRX+MCU BLE 32QFN |
4,893 |
|
Datasheet |
EFR32™ Blue Gecko | 32-VFQFN Exposed Pad | Tray | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.2 | 2FSK, GFSK | 2.4GHz ~ 2.4835GHz | 2Mbps | 0dBm | -98.9dBm | 352kB Flash, 32kB RAM | ADC, I2C, I2S, SPI, IrDA, UART, USART | 18 | 1.71V ~ 3.8V | 3.6mA ~ 4.5mA | 4.1mA ~ 4.4mA | -40°C ~ 85°C (TA) | - | - | 32-QFN (4x4) |
|
|
NRF52805-CAAA-B-R7IC RF TXRX+MCU BLE 28WLCSP |
1,468 |
|
Datasheet |
- | 28-UFBGA, WLCSP | Tape & Reel (TR) | Active | Not Verified | TxRx + MCU | Bluetooth | Bluetooth v5.0 | FSK | 2.4GHz | 2Mbps | 4dBm | -97dBm | 192kB Flash, 24kB RAM | ADC, GPIO, I2C, SPI, UART | 10 | 1.7V ~ 3.6V | 4.6mA ~ 11.2mA | 4.6mA ~ 10.1mA | -40°C ~ 85°C (TA) | - | - | 28-WLCSP (2.48x2.46) |
RF Transceiver ICs Electronic Components
Explore RF Transceiver ICs electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
