BOM Upload
RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FMSW6143EM RELAY SWITCH 40 GHZ 28 V 2.92 |
0 |
|
Datasheet |
- | - | Bag | Obsolete | General Purpose | Reflective | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -35°C ~ 85°C | - | - | Chassis Mount | - |
|
|
R574413080IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574413020IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMWGS6003WG EM RELAY SWITCH WR-28 40 GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT | 26.5GHz ~ 40GHz | 90dB | 0.012dB | - | - | - | - | 50Ohm | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R573J23610IC RF SWITCH SP6T 50GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
FMSW6160EM RELAY SWITCH 12.4 GHZ 12 V TY |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SPDT | 0Hz ~ 12.4GHz | 60dB (Min) | 0.6dB (max) | 12.4GHz | - | - | - | 50Ohm | 12V | -55°C ~ 85°C | - | - | Chassis Mount | - |
|
R574412025IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574413025IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R594873627IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 60dB (min) | 0.3dB (max) | 40GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
|
FMSW1117PIN DIODE SWITCH FIELD REPLACEAB |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SPDT | 18GHz ~ 40GHz | 60dB | 3.5dB | - | - | 40dBm | - | 50Ohm | -5V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
SW-262-PINIC RF SWITCH SP4T 2GHZ FP-17 |
0 |
|
- |
- | FP-17 | Bulk | Active | General Purpose | - | SP4T | 5MHz ~ 2GHz | 35dB | 2.2dB | 2GHz | 27dBm | 46dBm | - | 50Ohm | 5V | -55°C ~ 85°C | - | - | Surface Mount | FP-17 |
|
|
FMWGS6018WG EM RELAY SWITCH WR-90 12.4 GH |
0 |
|
Datasheet |
- | - | Bag | Obsolete | Radar, VSAT | Absorptive | SPDT | 8.2GHz ~ 12.4GHz | 105dB | 0.05dB | - | - | - | - | 50Ohm | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6566EM RELAY SWITCH 52 GHZ 28 V 2.4M |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SP4T | DC ~ 52GHz | 80dB | 1.5dB | 40GHz | - | - | - | 50Ohm | 26V ~ 30V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
R573J23615IC RF SWITCH SP6T 50GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
|
R574F11801IC RF SWITCH SP8T 26.5GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 26.5GHz | 55dB (min) | 1.1dB (max) | 26.5GHz | - | - | - | 50Ohm | 5V | -25°C ~ 75°C | - | - | - | - |
|
|
FMSW2034PIN DIODE SWITCH SMA SP12T 20GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SP12T | 100MHz ~ 20GHz | 65dB (min) | 6dB | 20GHz | - | - | - | 50Ohm | -12V, 5V | -55°C ~ 85°C | - | - | Chassis Mount | - |
|
R574482025IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R594873617RIC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
PLATINUM | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 60dB (min) | 0.9dB (max) | 40GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
R574402225IC RF SWITCH SP12T 12.4GHZ |
0 |
|
Datasheet |
- | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 12.4GHz | 60dB (min) | 0.7dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574402285IC RF SWITCH SP12T 12.4GHZ |
0 |
|
Datasheet |
- | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 12.4GHz | 60dB (min) | 0.7dB (max) | 12.4GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
RF Switches Electronic Components
Explore RF Switches electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
