RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R574413010IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574492820IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574493880IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574493820IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574F03000IC RF SWITCH SP10T 22GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 22GHz | 55dB (min) | 0.8dB (max) | 22GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R585J62500IC RF SWITCH SPDT 50GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 50GHz | 50dB (min) | 1.1dB (max) | 50GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -25°C ~ 70°C | - | - | - | - |
|
R574423005IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R574423015IC RF SWITCH SP10T 18GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Active | General Purpose | - | SP10T | 0Hz ~ 18GHz | 55dB (min) | 0.7dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMWGS6055WG EM RELAY SWITCH WRD-180 40 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Reflective | SPDT, DPDT | 18GHz ~ 40GHz | 50dB (min) | 0.4dB (max) | - | - | - | - | - | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6053WG EM RELAY SWITCH WRD-180 40 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Reflective | SPDT, DPDT | 18GHz ~ 40GHz | 50dB (min) | 0.4dB (max) | - | - | - | - | - | 21V ~ 32V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMSW6226PIN DIODE SWITCH 2.92MM SPDT 40G |
0 |
|
Datasheet |
- | - | Bag | Obsolete | General Purpose | Reflective | SPDT | 500MHz ~ 40GHz | 55dB (min) | 5.5dB | 40GHz | - | - | - | 50Ohm | -5V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
R594843417IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 60dB (min) | 0.3dB (max) | 40GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
|
FMSW6581EM RELAY SWITCH 52 GHZ 12 V 2.4M |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | - | DC ~ 52GHz | 80dB | 1.2dB | 40GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
R573J03615IC RF SWITCH SP6T 50GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 50GHz | 50dB (min) | 1.2dB (max) | 50GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
R574312225IC RF SWITCH SP12T 3GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP12T | 0Hz ~ 3GHz | 80dB (min) | 0.2dB (max) | 3GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574482885IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574482825IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574483825IC RF SWITCH SP8T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP8T | 0Hz ~ 18GHz | 60dB (min) | 0.6dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6229PIN DIODE SWITCH 2.92MM SP8T 40G |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | SP8T | 500MHz ~ 40GHz | 45dB (min) | 9dB | 40GHz | - | - | - | 50Ohm | -5V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R573F93225IC RF SWITCH SP12T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP12T | 0Hz ~ 18GHz | 50dB (min) | 0.8dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
