BOM Upload
RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FMSW6497EM RELAY SWITCH 12.4 GHZ 28 V TY |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Reflective | - | 0Hz ~ 12.4GHz | 70dB | 0.2dB | 12GHz | - | - | - | 50Ohm | 28V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
|
FMSW6295EM RELAY SWITCH 22 GHZ 12 V SMA |
0 |
|
Datasheet |
- | - | Bag | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
R574402640IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R574403640IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6233PIN DIODE SWITCH SMA SPST 8GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SPST | 4GHz ~ 8GHz | 75dB (min) | 1.8dB | 8GHz | - | - | - | 50Ohm | -15V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R573483385IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573802485IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573803425IC RF SWITCH SP4T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573802615IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573802605IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573803605IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573423645IC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573822310IC RF SWITCH SP3T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573823310IC RF SWITCH SP3T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R573482420IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R573F23605IC RF SWITCH SP6T 26.5GHZ |
0 |
|
- |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574G03410IC RF SWITCH SP4T 18GHZ |
0 |
|
- |
RAMSES | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP4T | DC ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R574G02400IC RF SWITCH SP4T 18GHZ |
0 |
|
- |
RAMSES | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP4T | DC ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R573803645IC RF SWITCH SP6T 40GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 40GHz | 50dB (min) | 1.1dB (max) | 40GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW8008PIN DIODE SWITCH SMA SPDT 3GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | Radar | Reflective | SPDT | 500MHz ~ 3GHz | 65dB | 0.9dB | 3GHz | - | - | - | 50Ohm | 5V, 15V | -20°C ~ 70°C | - | - | Chassis Mount | - |
RF Switches Electronic Components
Explore RF Switches electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
