RF Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | RF Type | Topology | Circuit | Frequency Range | Isolation | Insertion Loss | Test Frequency | P1dB | IIP3 | Features | Impedance | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
R573433500IC RF SWITCH SP5T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP5T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
FMSW6465EM RELAY SWITCH 12 GHZ 12 V TYPE |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | - | SP6T | 0Hz ~ 12GHz | 80dB | 0.2dB | 12GHz | - | - | - | 50Ohm | 11V ~ 13V | -25°C ~ 65°C | - | - | Chassis Mount | - |
|
R573F23600IC RF SWITCH SP6T 26.5GHZ |
0 |
|
- |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 50dB (min) | 0.7dB (max) | 26.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
FMSW6209PIN DIODE SWITCH SMA SPST 18GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | General Purpose | Absorptive | SPST | 500MHz ~ 18GHz | 55dB (min) | 3.5dB | 18GHz | - | - | - | 50Ohm | -15V, 5V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
R574432315IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
R574433315IC RF SWITCH SP3T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Obsolete | General Purpose | - | SP3T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
|
R573423400LPIC RF SWITCH SP6T 18GHZ |
0 |
|
Datasheet |
SPnT | Module | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 24V ~ 30V | -40°C ~ 85°C | - | - | - | - |
|
R591723600IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 21V ~ 30V | -40°C ~ 85°C | - | - | - | Module |
|
R591722600IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R591722610IC RF SWITCH SP6T 26.5GHZ MODULE |
0 |
|
Datasheet |
SPnT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SP6T | 0Hz ~ 26.5GHz | 55dB (min) | 0.6dB (max) | 26.5GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | Module |
|
R574422445IC RF SWITCH SP4T 18GHZ |
0 |
|
Datasheet |
- | Module | Bulk | Obsolete | General Purpose | - | SP4T | 0Hz ~ 18GHz | 60dB (min) | 0.5dB (max) | 18GHz | - | - | - | 50Ohm | 10.2V ~ 13V | -40°C ~ 85°C | - | - | - | - |
|
|
R595343215RIC RF SWITCH SPDT 6GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 6GHz | 85dB (min) | 0.3dB (max) | 6GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
R573923300IC RF SWITCH SP3T 2.5GHZ |
0 |
|
Datasheet |
RAMSES | Module | Bulk | Active | General Purpose | - | SP3T | 0Hz ~ 2.5GHz | 70dB (min) | 0.3dB (max) | 2.5GHz | - | - | - | 50Ohm | 24V ~ 30V | -25°C ~ 70°C | - | - | - | - |
|
R595357325IC RF SWITCH 6GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | - | 0Hz ~ 6GHz | 85dB (min) | 0.2dB (max) | 6GHz | - | - | - | 50Ohm | 12V ~ 20V | -25°C ~ 75°C | - | - | - | - |
|
R595363415IC RF SWITCH DP3T 6GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | DP3T | 0Hz ~ 6GHz | 85dB (min) | 0.2dB (max) | 6GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
|
R595F43110RIC RF SWITCH SPDT 26.5GHZ |
0 |
|
Datasheet |
DP3T/SPDT | Module, SMA Connectors | Bulk | Active | General Purpose | - | SPDT | 0Hz ~ 26.5GHz | 60dB (min) | 0.65dB (max) | 26.5GHz | - | - | - | 50Ohm | 20V ~ 32V | -25°C ~ 75°C | - | - | - | - |
|
|
FMWGS6025WG EM RELAY SWITCH WR-137 8.2 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT | 5.85GHz ~ 8.2GHz | 105dB | 0.012dB | - | - | - | - | 50Ohm | 21V ~ 32V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6023WG EM RELAY SWITCH WR-112 10 GHZ |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT | 7.05GHz ~ 10GHz | 85dB | 0.02dB | - | - | - | - | 50Ohm | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6027WG EM RELAY SWITCH WR-137 8.2 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT | 5.85GHz ~ 8.2GHz | 105dB | 0.012dB | - | - | - | - | 50Ohm | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
|
|
FMWGS6007WG EM RELAY SWITCH WR-42 26.5 GH |
0 |
|
Datasheet |
- | - | Bag | Active | Radar, VSAT | Absorptive | SPDT | 18GHz ~ 26.5GHz | 90dB | 0.013dB | - | - | - | - | 50Ohm | 10V ~ 20V | -40°C ~ 85°C | - | - | Chassis Mount | - |
