RF Directional Coupler
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Coupler Type | Frequency | Coupling Factor | Applications | Insertion Loss | Power - Max | Isolation | Return Loss | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CP10208A-62 GHz - 8 GHz, 6 dB Coupling |
2 |
|
Datasheet |
- | Box | Active | Standard | 2GHz ~ 8GHz | 6dB | General Purpose | 1.7dB | 50W | 29dB | 23dB | Module |
|
PEWCP1038WR-34 Waveguide 50 dB Crossguide |
5 |
|
Datasheet |
- | Retail Package | Active | Standard | 22GHz ~ 33GHz | 50dB | General Purpose | 0.1dB | - | - | - | - |
|
|
PE2242-10Directional 10 dB SMA Coupler Fr |
15 |
|
Datasheet |
- | Retail Package | Active | Standard | 500MHz ~ 3GHz | 10 ± 1.5dB | General Purpose | 1dB | 50W | - | - | Module |
|
PE2CP004-6CPLR 6DBSMA 2-8GHZ 50W |
9 |
|
Datasheet |
- | Bag | Active | Standard | 2GHz ~ 8GHz | 6 ± 1dB | General Purpose | 0.5dB | 50W | - | - | Module |
|
|
AM500-20000DC1410500-20000 MHz Directional Couple |
5 |
|
Datasheet |
- | Retail Package | Active | Standard | 500MHz ~ 20GHz | 10 ± 1.2dB | General Purpose | 1.6dB | 30W | - | - | Module |
|
PE2CP1121-30CPLR 30DBSMA 18-26GHZ 30W |
2 |
|
Datasheet |
- | Bag | Active | Standard | 18GHz ~ 26GHz | 30dB | 5G, GSM, LTE | 1dB | 30W | - | - | Module |
|
|
PEWCP1057WR-90 Waveguide 40 dB Crossguide |
8 |
|
Datasheet |
- | Retail Package | Active | Standard | 8.2GHz ~ 12.4GHz | 40dB | General Purpose | 0.1dB | - | - | - | Module |
|
|
WMC-2-8-10dB-SCOUPLER 10 DB 2-8 GHZ SMA |
5 |
|
Datasheet |
Single Coupler | Retail Package | Active | Standard | 2GHz ~ 8GHz | 10dB | Cellular, WiMAX | 1dB | 50W | 32dB | 23dB | Module |
|
|
WMC-2-8-6dB-SCOUPLER 6 DB 2-8 GHZ SMA |
5 |
|
Datasheet |
Single Coupler | Retail Package | Active | Standard | 2GHz ~ 8GHz | 6dB | Cellular, WiMAX | 2.2dB | 4W | 28.5dB | 24dB | Module |
|
|
WMC-2-8-20dB-SCOUPLER 20 DB 2-8 GHZ SMA |
5 |
|
Datasheet |
Single Coupler | Retail Package | Active | Standard | 2GHz ~ 8GHz | 20dB | Cellular, WiMAX | 0.45dB | 50W | 42dB | 24dB | Module |
|
|
WMC-2-8-30DB-SCOUPLER 30 DB 2-8 GHZ SMA |
5 |
|
Datasheet |
- | Retail Package | Active | Standard | 2GHz ~ 8GHz | 30dB | Cellular, GSM, ISM, Military, PCN, Wi-Fi, WiMAX | 0.37dB | 50W | -53dB | 25dB | Module |
|
CP20710P150-207 GHz - 10 GHz, 20 dB Coupling |
6 |
|
Datasheet |
- | Box | Active | Standard | 7GHz ~ 10GHz | 20dB | General Purpose | 0.35dB | 150W | 42dB | 23dB | Module |
|
|
PEWCP1037WR-34 Waveguide 40 dB Crossguide |
10 |
|
Datasheet |
- | Retail Package | Active | Standard | 22GHz ~ 33GHz | 40dB | General Purpose | 0.1dB | - | - | - | - |
|
|
PEWCP1040WR-42 Waveguide 30 dB Crossguide |
3 |
|
Datasheet |
- | Retail Package | Active | Standard | 18GHz ~ 26.5GHz | 30dB | General Purpose | 0.1dB | - | - | - | - |
|
PE2CP1120-10CPLR 10DBSMA 6-26.5GHZ 30W |
21 |
|
Datasheet |
- | Bag | Active | Standard | 6GHz ~ 26.5GHz | 10dB | 5G, GSM, LTE | 1dB | 30W | - | - | Module |
|
PE2CP1101CPLR 6DBSMA 7-12.4GHZ 50W |
5 |
|
Datasheet |
- | Bag | Active | Standard | 7GHz ~ 12.4GHz | 6dB | CDMA, GSM, LTE | 0.2dB | 50W | - | - | Module |
|
|
WMQH-2-4-SQUADRATURE HYBRID 2-4GHZ SMA |
5 |
|
Datasheet |
Quadrature Hybrid | Retail Package | Active | Standard | 2GHz ~ 4GHz | 3dB | General Purpose | 3.15dB | 50W | 23dB | 24dB | Module |
|
|
WMQH-1-2-SQUADRATURE HYBRID 1-2GHZ SMA |
5 |
|
Datasheet |
Quadrature Hybrid | Retail Package | Active | Standard | 1GHz ~ 2GHz | 3dB | General Purpose | 3.15dB | 50W | 24dB | 24dB | Module |
|
PE2CP1120-30CPLR 30DBSMA 6-26.5GHZ 30W |
2 |
|
Datasheet |
- | Bag | Active | Standard | 6GHz ~ 26.5GHz | 30dB | 5G, GSM, LTE | 1dB | 30W | - | - | Module |
|
|
PEWCP1052AWR-75 Waveguide 30 dB Crossguide |
2 |
|
Datasheet |
- | Retail Package | Active | Standard | 10GHz ~ 15GHz | 30dB | General Purpose | 0.1dB | - | 25dB | - | - |
