RF Antennas
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RE04U-NMANTMAGMNT 2.4GHZ 4DBI NM 4' |
0 |
|
- |
RE | Bag | Active | Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.4GHz | - | Whip, Straight | 1 | - | - | 4dBi | - | Cable - 1.2192m | N Type Male | - | - | - | Magnetic | 7.900" (200.66mm) | 802.11b/g/n, Bluetooth, ISM, Wi-Fi, WLAN |
|
|
LCANLP1013698-4200, 10-11 DBI GAIN, LOG PE |
0 |
|
- |
LCAN | Bag | Active | Cellular, WiFi | Wide Band | 2.449GHz | 698MHz ~ 4.2GHz | Log Periodic | 1 | 2 | - | 11dBi | 100 W | Cable - 200mm | N Type Female | - | - | - | Bracket Mount | 16.100" (408.94mm) | 3G, 4G, 5G, 802.11a/b/g/n/ac/ad/ah/ax, CBRS, CMDA, GSM, IoT, LoRa, LPWAN, LTE, LTE-M, M2M, NB-IoT, Wi-Fi, WLAN |
|
|
HG74205DPCUPR-NF698 MHZ - 4200 MHZ, INDOOR 4G/5G |
0 |
|
- |
HG | Bag | Active | Cellular | Wide Band | 752MHz, 883MHz, 2.205GHz, 3.8GHz | 698MHz ~ 806MHz, 806MHz ~ 960MHz, 1.71GHz ~ 2.7GHz, 3.4GHz ~ 4.2GHz | Module | 4 | 2 | - | 3dBi, 3.5dBi, 4.5dBi, 5dBi | 50 W | Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m | N Type Female (2) | - | - | - | Ceiling Mount | 1.580" (40.13mm) | 5G, CDMA, GSM, IoT, LoRa, LPWAN, LTE |
|
|
KG470UDANTENNA ONGLS 2.5DB 470-490 MHZ |
0 |
|
Datasheet |
- | Bag | Active | - | UHF (1GHz ~ 2GHz) | 480MHz | 470MHz ~ 490MHz | Whip, Straight | 1 | - | -10dB | 2dBi | 100 W | Cable - 355.6mm | - | - | - | - | Glass | 15.000" (381.00mm) | - |
|
|
Q27SRF ANT 40MHZ WHIP STR NMO 102" |
0 |
|
Datasheet |
- | Bulk | Obsolete | - | VHF (f < 300MHz) | 40MHz | 27MHz ~ 54MHz | Whip, Straight | 1 | - | - | 0dBi | - | - | NMO | - | - | - | Base Mount | 102.000" (259.08cm) | - |
|
|
OM420CKANTENNA COIL-WHP 5DB 420-440 MHZ |
0 |
|
Datasheet |
- | Bag | Active | - | UHF (300MHz ~ 1GHz) | 430MHz | 420MHz ~ 440MHz | Whip, Straight | 1 | - | -10dB | 5.5dBi | 100 W | Cable - 431.8mm | UHF | - | - | - | Magnetic | 35.500" (901.70mm) | - |
|
|
CRS3RF ANT 38MHZ WHIP STR UHF FEM |
0 |
|
Datasheet |
- | Bulk | Obsolete | - | VHF (f < 300MHz) | 38MHz | 33MHz ~ 44MHz | Whip, Straight | 1 | 1.5 | - | 2dB | 250 W | - | UHF Female | - | - | - | Bracket Mount | 168.000" (426.73cm) | - |
|
|
CRS4RF ANT 47MHZ WHIP STR UHF FEM |
0 |
|
Datasheet |
- | Bulk | Obsolete | - | VHF (f < 300MHz) | 47MHz | 44MHz ~ 50MHz | Whip, Straight | 1 | 1.5 | - | 2dB | 250 W | - | UHF Female | - | - | - | Bracket Mount | 127.200" (323.09cm) | - |
|
|
HG909Y-NMANTYAGI 900MHZ 9DBI |
0 |
|
- |
HG | Bag | Active | Cellular, General ISM, WiFi | UHF (300MHz ~ 1GHz) | 925MHz | 890MHz ~ 960MHz | Yagi | 1 | 1.5 | - | 9dBi | 100 W | - | N Type Female | - | - | - | Mast Mount | 19.600" (497.84mm) | GSM, ISM, WLAN |
|
|
33-3710-02-11-0610RF ANT 1.561/1.575GHZ DOME PANEL |
0 |
|
Datasheet |
Accutenna® | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.561GHz, 1.575GHz, 1.602GHz | 1.557GHz ~ 1.606GHz | Dome | 1 | 1.5 | - | 28dB | - | Cable - 610mm, LNA, Filter | MCX Male | IP67 | - | - | Panel Mount | 0.827" (21.00mm) | Beidou, Galileo, GLONASS, GPS |
|
|
33-3710-01-10TW3710 W/FEMALE TNC |
0 |
|
Datasheet |
Accutenna® | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.581GHz | 1.557GHz ~ 1.606GHz | Dome | 1 | 1.5 | - | 4.75dBic | - | LNA, Filter | TNC Female | IP67 | - | - | Panel Mount | 0.827" (21.00mm) | Beidou, Galileo, GLONASS, GPS |
|
|
33-3710-00-10-4000RF ANT 1.561GHZ/1.575GHZ DOME |
0 |
|
Datasheet |
Accutenna® | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.5815GHz | 1.557GHz ~ 1.606GHz | Dome | 1 | 1.8 | - | 4.75dBic | - | Cable - 4m, LNA, Filter | TNC Female | IP67 | - | - | Panel Mount | 0.827" (21.00mm) | Beidou, Galileo, GLONASS, GPS |
|
33-3710-10-10-0200RF ANT 1.561/1.575GHZ DOME PANEL |
0 |
|
Datasheet |
Accutenna® | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.561GHz, 1.575GHz, 1.602GHz | 1.557GHz ~ 1.606GHz | Dome | 1 | 1.5 | - | 28dB | - | Cable - 200mm, LNA, Filter | SMA | IP67 | - | - | Panel Mount | 0.827" (21.00mm) | Beidou, Galileo, GLONASS, GPS |
|
|
HG4958-22EGANTGRID 4.9-5.8GHZ 22DBI |
0 |
|
- |
HG | Bag | Obsolete | General ISM | SHF (f > 4GHz) | 5.375GHz | 4.9GHz ~ 5.85GHz | Parabolic Grid | 1 | 1.5 | - | 22dBi | 100 W | - | N Type Female | - | - | - | Mast Mount | 10.000" (254.00mm) | ISM |
|
WLPD.4958.12.4.A.02RF ANT 5.18GHZ CER PATCH PIN ADH |
0 |
|
Datasheet |
- | Bag | Active | 802.15.4, WiFi | SHF (f > 4GHz) | 5.18GHz | 4.9GHz ~ 5.825GHz | Ceramic Patch | 1 | 1.5 | -10dB | 6dBic | - | - | Pin | - | - | - | Adhesive | 0.197" (5.00mm) | Wi-Fi, Zigbee™ |
|
|
LP160NMOANT BLACK NMO LOW PROFILE UNIT |
0 |
|
Datasheet |
- | Bag | Active | - | VHF (f < 300MHz) | 159.5MHz | 158.33MHz ~ 160.67MHz | Dome | 1 | - | -10dB | 2dBi | 60 W | - | NMO | - | - | - | Magnetic | 3.750" (95.25mm) | - |
|
|
FG4400RF ANT 445MHZ WHIP STR N FEM 26" |
0 |
|
- |
- | Bulk | Active | - | UHF (300MHz ~ 1GHz) | 445MHz | 440MHz ~ 450MHz | Whip, Straight | 1 | - | - | - | - | - | N Type Female | - | - | - | Bracket Mount | - | - |
|
FG8963RF ANT 898MHZ WHIP STR N FEM |
0 |
|
Datasheet |
- | Bulk | Active | - | UHF (300MHz ~ 1GHz) | 898MHz | 896MHz ~ 940MHz | Whip, Straight | 1 | 2 | - | 3dBd | 100 W | - | N Type Female | - | - | - | Bracket Mount | 25.000" (635.00mm) | - |
|
|
YS3606RF ANT 360MHZ YAGI N FEM BRKT MT |
0 |
|
- |
- | Bulk | Obsolete | - | UHF (300MHz ~ 1GHz) | 360MHz | - | Yagi, 6-Element | 1 | 1.5 | - | 10.2dBd | - | - | N Type Female | - | - | - | Bracket Mount | 44.000" (111.76cm) | - |
|
|
HG2458-11PANTFLAT PNL 2.4/5GHZ 9/11DBI |
0 |
|
- |
HG | Bag | Active | WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.45GHz, 5.35GHz | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.8GHz | Panel | 2 | 2 | - | 9dBi, 11dBi | 10 W | - | N Type Female | - | - | - | Pole Mount | 1.200" (30.48mm) | 802.11a/b/g/n, WLAN |
