RF Antennas
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LCANLP10081920-2170 MHZ, 10 DBI, GAIN, V-P |
0 |
|
- |
LCAN | Bag | Active | Cellular, WiFi | Wide Band | 2.045GHz | 1.92GHz ~ 2.17GHz | Log Periodic | 1 | 1.5 | - | 10dBi | 100 W | Cable - 238.76mm | N Type Female | - | - | - | Bracket Mount | 5.900" (149.86mm) | 4G, 5G, CBRS, CMDA, GSM, IoT, LoRa, LPWAN, LTE, LTE-M, M2M, NB-IoT, Wi-Fi |
|
|
OD350-6000S1NFANT DAS OMNI UHF(TETRA) 5G LTE |
0 |
|
Datasheet |
- | Box | Active | Cellular | Wide Band | 435MHz, 780MHz, 1.45GHz, 2.195GHz, 3.75GHz, 5.45GHz | 350MHz ~ 520MHz, 600MHz ~ 960MHz, 1.35GHz ~ 1.55GHz, 1.69GHz ~ 2.7GHz, 3.3GHz ~ 4.2GHz, 4.9GHz ~ 6GHz | Module | 6 | 1.8, 2 | - | 3dBi, 3dBi, 4dBi, 4dBi, 5dBi, 5dBi | 50 W | Cable - 300mm | N Type Female | IP50 | - | - | Through Hole | 0.394" (10.00mm) | 4G, 5G, TETRA |
|
|
HG142PSGI-NMOANT 2 DBI POLY SPRING VEHICULAR |
0 |
|
- |
HG | Bag | Active | General ISM | VHF (f < 300MHz) | 159MHz | 144MHz ~ 174MHz | Whip, Straight | 1 | 2 | - | 2dBi | 150 W | - | NMO | - | - | - | Connector Mount | 1.063" (27.00mm) | General Purpose |
|
|
37133-001ANTENNA,2.4 GHZ, 5.0 DBI |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
CWB1503SRF ANT 156MHZ WHIP STR NMO BASE |
0 |
|
Datasheet |
- | Bulk | Obsolete | - | VHF (f < 300MHz) | 156MHz | 150MHz ~ 162MHz | Whip, Straight | 1 | 2 | - | 3dB | 200 W | - | NMO | - | - | - | Base Mount | 48.500" (123.19cm) | - |
|
|
C30RF ANT 33MHZ WHIP STR NMO BASE |
0 |
|
Datasheet |
- | Bulk | Active | - | VHF (f < 300MHz) | 33MHz | 30MHz ~ 35MHz | Whip, Straight | 1 | 2 | - | 0dB | - | - | NMO | - | - | - | Base Mount | 52.500" (133.35cm) | - |
|
|
C34RF ANT 36MHZ WHIP STR NMO BASE |
0 |
|
Datasheet |
- | Bulk | Active | - | VHF (f < 300MHz) | 36MHz | 34MHz ~ 37MHz | Whip, Straight | 1 | 2 | - | 0dB | - | - | NMO | - | - | - | Base Mount | 52.500" (133.35cm) | - |
|
C37RF ANT 39MHZ WHIP STR NMO BASE |
0 |
|
Datasheet |
- | Bulk | Active | - | VHF (f < 300MHz) | 39MHz | 37MHz ~ 40MHz | Whip, Straight | 1 | 2 | - | 0dB | - | - | NMO | - | - | - | Base Mount | 52.500" (133.35cm) | - |
|
CLS69273P-30D43FRF ANT 700MHZ/850MHZ MODULE CAB |
0 |
|
Datasheet |
- | Bulk | Active | Cellular, WiFi | Wide Band | 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz | 698MHz ~ 960MHz, 1.695GHz ~ 2.7GHz | Module | 8 | 1.8, 1.6, 1.7, 1.9, 1.9, 1.9, 1.7, 1.5, 1.3 | - | 3dBi, 3dBi, 4.1dBi, 5.6dBi, 7dBi, 7dBi, 6.7dBi, 7.3dBi | 50 W | Cable - 305mm | N Type Female | - | - | - | Panel Mount | 1.870" (47.50mm) | DCS, GSM, LTE, UMTS, WiMax™ |
|
|
B4065CNSRF ANT 418MHZ WHIP STR NMO BASE |
0 |
|
Datasheet |
- | Bulk | Active | - | UHF (300MHz ~ 1GHz) | 418MHz | 406MHz ~ 430MHz | Whip, Straight | 1 | 2 | - | 5dBi | - | - | NMO | - | - | - | Base Mount | 39.500" (100.33cm) | - |
|
|
ST0326-41-301-URF ANTENNA STICK N TYPE JACK WID |
0 |
|
Datasheet |
- | Bag | Active | Cellular | Wide Band | 829MHz, 1.94GHz, 2.495GHz | 698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz | Whip, Straight | 3 | - | -6dB, -5dB | 5.8dBi, 4.6dBi, 5.9dBi | 5 W | - | N Type | IP67 | - | - | Connector Mount | 21.654" (550.00mm) | 4G, LTE |
|
|
LCANMOB1007-RSP144/430 MHZ OMNI ANTENNA 5.5 DBI |
0 |
|
Datasheet |
LCAN | Bulk | Active | General ISM | Wide Band | 287MHz | 144MHz ~ 430MHz | Whip, Straight | 1 | 1.5 | - | 5.5dBi | 50 W | Cable - 3.05m | RP-SMA Male | - | - | - | Magnetic | 34.400" (873.76mm) | General Purpose |
|
|
S5153WBPX36NMRF ANT 5.5GHZ WHIP STR BRKT MT |
0 |
|
Datasheet |
- | Bulk | Active | WiFi | SHF (f > 4GHz) | 5.5GHz | 5.15GHz ~ 5.875GHz | Whip, Straight | 1 | 2 | - | 6dBi | 10 W | Cable - 914mm | N Type Male | - | - | - | Bracket Mount | 11.500" (292.10mm) | WiMax™, WLAN |
|
|
S5153WBPX36RSMRF ANT 5.5GHZ WHIP STR BRKT MT |
0 |
|
Datasheet |
- | Bulk | Active | WiFi | SHF (f > 4GHz) | 5.5GHz | 5.15GHz ~ 5.875GHz | Whip, Straight | 1 | 2 | - | 6dBi | 10 W | Cable - 914mm | RP-SMA Male | - | - | - | Bracket Mount | 11.500" (292.10mm) | WiMax™, WLAN |
|
33-2643P-07ANTENNA IRIDIUM/GNSS ANTENNA |
0 |
|
Datasheet |
Accutenna® | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.5925GHz | 1.559GHz ~ 1.626GHz | Dome | 1 | 1.8 | - | 4.5dBic | - | LNA | - | IP67 | - | - | Magnetic | 0.591" (15.00mm) | Beidou, Galileo, GLONASS, GPS |
|
MA111.W.C.LB.001RF ANT 850MHZ/900MHZ DOME PNL MT |
0 |
|
Datasheet |
Ultima | Bag | Active | Cellular, Navigation | UHF (300MHz ~ 1GHz), UHF (1GHz ~ 2GHz) | 850MHz, 900MHz, 1.575GHz, 1.602GHz, 1.8GHz, 1.9GHz, 2.1GHz | 824MHz ~ 960MHz, 1.574GHz ~ 1.606GHz, 1.71GHz ~ 2.17GHz | Dome | 7 | 2.5, 2, 2, 3.5, 3, 3 | - | 1.5dBi, 3dBi, -1.4dB, -1.3dBi, 2dBi, 4dBi, 2.5dBi | - | Cable - 3m, LNA, Filter | SMA Male (2) | IP67, IP69K | - | - | Panel Mount | 0.772" (19.60mm) | CDMA, GLONASS, GPS, GSM, UMTS |
|
RI.02.01.3000WRF ANT 915MHZ DOME SMB MALE ADH |
0 |
|
Datasheet |
- | Box | Obsolete | - | UHF (300MHz ~ 1GHz) | 915MHz | 902MHz ~ 928MHz | Dome | 1 | - | -18dB | 3.2dBi | 10 W | - | SMB Male | IP67 | - | - | Adhesive | 0.693" (17.60mm) | - |
|
|
GNSS4GDPSM-1MGNSS, 2X LTE, 1 METER MSMA RG-17 |
0 |
|
Datasheet |
4GDPSM | Bulk | Obsolete | Cellular, Navigation | Wide Band | 829MHz, 1.592GHz, 2.205GHz | 698MHz ~ 960MHz, 1.575GHz ~ 1.61GHz, 1.71GHz ~ 2.7GHz | Dome | 3 | 2 | - | -8.85dBi, -10.97dBi | - | Cable - 1m, LNA | SMA Male | IP67 | - | - | Connector Mount | 1.575" (40.00mm) | GLONASS, GNSS, GPS, LTE |
|
|
GNSS4GDPSM-W-1MGNSS, 2X LTE, 1 METER MSMA RG-17 |
0 |
|
Datasheet |
4GDPSM | Bulk | Obsolete | Cellular, Navigation | Wide Band | 829MHz, 1.592GHz, 2.205GHz | 698MHz ~ 960MHz, 1.575GHz ~ 1.61GHz, 1.71GHz ~ 2.7GHz | Dome | 3 | 2 | - | -8.85dBi, -10.97dBi | - | Cable - 1m, LNA | SMA Male | IP67 | - | - | Connector Mount | 1.575" (40.00mm) | GLONASS, GNSS, GPS, LTE |
|
|
CFSA69594P1-B30NFOMNI,CEILING,30CM,BULK |
0 |
|
- |
- | Bulk | Active | Cellular | Wide Band | 761MHz, 859MHz, 920MHz, 1.45GHz, 1.785GHz, 1.92GHz, 2.055GHz, 2.5GHz, 3.65GHz, 4.1GHz, 5.537GHz | 698MHz ~ 824MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.35GHz ~ 1.55GHz, 1.69GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.91GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz, 3.3GHz ~ 4GHz, 4GHz ~ 4.2GHz, 5.15GHz ~ 5.925GHz | Module | 11 | 1.7, 2, 2.5 | - | 3.7dBi, 3.4dBi, 3.2dBi, 4.5dBi, 5.4dBi, 5.6dBi, 5.6dBi, 5.6dBi, 4.3dBi, 4.1dBi, 4.9dBi | 50 W | Cable - 304.8mm | N Type Female | - | - | - | Ceiling Mount | 0.300" (7.62mm) | 5G, 802.11 a/b/g/n/ac/ad, Bluetooth, Wi-Fi, Zigbee™ |
